A basket-style convection air fryer. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
9 top-level lines · 35 rows shown · 61 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Outer Housing 3 parts | air-fryer-housing | 1× | 1 | 6 | assembly |
| 1.1 | Plastic Outer Shell | air-fryer-shell | 1× | 1 | — | part |
| 1.2 | Air Vent Grille | air-fryer-air-vent | 4× | 4 | — | part |
| 1.3 | Base Plate | air-fryer-base-plate | 1× | 1 | — | part |
| 2 | Cooking Chamber 5 parts | air-fryer-cooking-chamber | 1× | 1 | 5 | assembly |
| 2.1 | Metal Cooking Pot | air-fryer-pot | 1× | 1 | — | part |
| 2.2 | Cooking Basket | air-fryer-basket | 1× | 1 | — | part |
| 2.3 | Crisper Plate | air-fryer-crisper-plate | 1× | 1 | — | part |
| 2.4 | Basket Handle | air-fryer-handle | 1× | 1 | — | part |
| 2.5 | Basket Release Button | air-fryer-release-button | 1× | 1 | — | part |
| 3 | Heating & Convection 3 parts | air-fryer-heating-convection | 1× | 1 | 28 | assembly |
| 3.1 | Heating Element | heating-element | 1× | 1 | — | part |
| 3.2 | Convection Fan 2 parts | air-fryer-fan | 1× | 1 | 26 | assembly |
| 3.2.1 | Fan Motor 4 parts + deeper › | air-fryer-fan-motor | 1× | 1 | 25 | assembly |
| 3.2.2 | Fan Blade Impeller | air-fryer-fan-blade | 1× | 1 | — | part |
| 3.3 | Fan Shroud | air-fryer-shroud | 1× | 1 | — | part |
| 4 | Control Board 5 parts | air-fryer-control-board | 1× | 1 | 10 | assembly |
| 4.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 4.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 4.3 | Relay | relay | 2× | 2 | — | part |
| 4.4 | Touchscreen Display 2 parts | air-fryer-touchscreen | 1× | 1 | 2 | assembly |
| 4.4.1 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 4.4.2 | Touch Digitizer | touch-digitizer | 1× | 1 | — | part |
| 4.5 | Connector | connector | 4× | 4 | — | part |
| 5 | Sensor Set 3 parts | air-fryer-sensor-set | 1× | 1 | 3 | assembly |
| 5.1 | NTC Temperature Sensor | air-fryer-ntc-sensor | 1× | 1 | — | part |
| 5.2 | Basket Detect Switch | air-fryer-basket-switch | 1× | 1 | — | part |
| 5.3 | Thermal Cutoff Fuse | air-fryer-thermal-cutoff | 1× | 1 | — | part |
| 6 | Power Cord 3 parts | air-fryer-power-cord | 1× | 1 | 3 | assembly |
| 6.1 | Mains Cable | air-fryer-cord | 1× | 1 | — | part |
| 6.2 | Mains Plug | air-fryer-plug | 1× | 1 | — | part |
| 6.3 | Strain Relief Grommet | air-fryer-strain-relief | 1× | 1 | — | part |
| 7 | Rubber Foot | air-fryer-foot | 4× | 4 | — | part |
| 8 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 9 | Fastener Set | fastener-set | 1× | 1 | — | part |
