Commercial Cold Brew System Product

Overview

A commercial cold brew system is an immersion-based batch brewer that extracts coffee flavor compounds in cold water over 12–24 hours, producing a smooth, low-acid concentrate suitable for high-volume beverage service. Unlike heat-accelerated brewing methods, cold water extraction minimizes bitter compounds, making the concentrate balanced and shelf-stable for weeks under refrigeration.

The system centers on a large stainless steel Steeping Vessel Assembly, typically 20–50 L capacity, which holds coarsely ground coffee submerged in cold water. An internal Steeping Mesh Basket suspends grounds throughout the liquid, maximizing extraction surface area. After steeping, the brew is separated through a multi-stage Filtration Assembly using cloth and mesh media, yielding a clear concentrate ready for dispensing.

To prevent oxidation and microbial growth during the long soak and subsequent storage, the system maintains a Nitrogen Blanket Subsystem that supplies a blanket of inert nitrogen gas inside the sealed vessel. This eliminates dissolved oxygen and inhibits mold.

The concentrate is dispensed via either a Dispensing Unit gravity spigot for manual portion control or an electric peristaltic pump for rapid, metered service. The entire assembly sits on a Frame and Support Structure that elevates the tank above the dispensing area for ergonomic operator access.

How it works

Operators fill the Steeping Vessel Assembly with 30–40 L cold or ambient water, then load coarsely ground coffee (60–100 grams per liter) into the Steeping Mesh Basket. The lid is closed, trapping the grounds and water together.

For the next 12–24 hours, gravity causes the coffee to gradually infuse. Cold water dissolves sugars, oils, and organic acids slowly; the low temperature suppresses extraction of harsh tannins. The mesh basket keeps grounds suspended mid-vessel, avoiding settling and uneven saturation.

After steeping, an operator opens the Sealed Lid Assembly and positions a collection vessel beneath the Filtration Assembly. Via the Valve and Manifold Block, they open isolation valves connecting the tank outlet to the filter inlet. Gravity pulls the liquid through the Cloth Filter Media and Mesh Support Screen, which trap fine particles while allowing clear concentrate to flow into the collection vessel. Depending on system design, this may happen via manual valve opening or via a solenoid-controlled auto-drain.

Once filtration completes, the grounds are removed and composted. The collected concentrate is transferred to a storage container, where a fresh Nitrogen Blanket Subsystem charge is applied via the Nitrogen Regulator to create a 2–5 psi blanket. This nitrogen prevents oxidation and microbial bloom.

During service, a barista uses the Dispensing Unit to draw concentrate directly into a cup, then adds water or milk. The gravity spigot allows simple portion control; electric pump systems can meter exact 1–2 oz shots into cups automatically.

Key engineering considerations

Immersion efficiency: Cold water extraction is slower than heat but achieves 18–22% extraction yield (vs. 20–25% for hot espresso). The trade-off is taste smoothness; cold extraction sidesteps astringency. Coarse grind (4–6 mm) is critical; finer grinds clog filtration or become powdery.

Cloth durability: The Cloth Filter Media is the system bottleneck. Nylon or cotton media degrads after 20–50 brews (typically 4–6 months of heavy use) and must be replaced. The Mesh Support Screen backing prevents blinding (pore closure).

Oxygen exclusion: Concentrate oxidizes quickly in air. The Nitrogen Blanket Subsystem supplies a blanket at 2–5 psi, covering the liquid surface and displacing oxygen. Without it, concentrate develops rancid flavors within 48 hours. Nitrogen is inert and food-safe, making it standard in commercial systems.

Gravity vs. pump dispensing: A simple Gravity Spigot tap relies on head pressure from the elevated tank; output is ~0.5–1 L/min and consistent. A Peristaltic Pump Head overcomes gravity limitations, delivering 2–5 L/min and allowing speed-variable dispensing. Peristaltic design (tubing-squeezing) is gentler than centrifugal pumps, minimizing aeration of concentrate.

Thermal stability: Cold brew requires no heating, so the system is electrically simple and safe. Ambient temperature should remain 15–25 °C; higher temperatures accelerate fermentation (undesirable). Some commercial kitchens place the Steeping Vessel Assembly in a walk-in cooler.

Standards and maintenance

Commercial cold brew systems comply with NSF and local food service codes. All Frame and Support Structure, Tank Body, and fittings are stainless steel 304 or higher to resist pitting from mineral content in water.

Maintenance includes daily draining of the Drip and Drain Assembly and weekly sanitizing of cloth filters with hot water (160 °F) and food-approved sanitizer. Monthly nitrogen regulator and gauge inspection ensures proper blanket pressure.
