Continuous Butter Churn Product
Horizontal or vertical churn with internal beaters, cream agitation section, and fat-phase separation zone producing butter at 500–2000 kg/h throughput. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
7 top-level lines · 44 rows shown · 43 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Churning Cylinder 5 parts | continuous-butter-churn-churning-cylinder | 1× | 1 | 6 | assembly |
| 1.1 | Outer Barrel | continuous-butter-churn-outer-barrel | 1× | 1 | — | part |
| 1.2 | Cooling Jacket | continuous-butter-churn-cooling-jacket | 1× | 1 | — | part |
| 1.3 | Baffle Plates | continuous-butter-churn-baffle-plates | 1× | 1 | — | part |
| 1.4 | Inlet Spout | continuous-butter-churn-inlet-spout | 1× | 1 | — | part |
| 1.5 | Pressure Sensor | pressure-sensor | 2× | 2 | — | part |
| 2 | Beater Assembly 5 parts | continuous-butter-churn-beater-assembly | 1× | 1 | 6 | assembly |
| 2.1 | Beater Shaft | continuous-butter-churn-beater-shaft | 1× | 1 | — | part |
| 2.2 | Paddles | continuous-butter-churn-paddles | 1× | 1 | — | part |
| 2.3 | Disc Stack | continuous-butter-churn-disc-stack | 1× | 1 | — | part |
| 2.4 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 2.5 | Oil Seal | oil-seal | 1× | 1 | — | part |
| 3 | Separation Section 3 parts | continuous-butter-churn-separation-section | 1× | 1 | 3 | assembly |
| 3.1 | Drain Outlet | continuous-butter-churn-drain-outlet | 1× | 1 | — | part |
| 3.2 | Settling Zone | continuous-butter-churn-settlingzone | 1× | 1 | — | part |
| 3.3 | False Floor | continuous-butter-churn-false-floor | 1× | 1 | — | part |
| 4 | Working Augers 4 parts | continuous-butter-churn-working-augers | 1× | 1 | 4 | assembly |
| 4.1 | Auger Shaft | continuous-butter-churn-auger-shaft | 1× | 1 | — | part |
| 4.2 | Flight Spiral | continuous-butter-churn-flight-spiral | 1× | 1 | — | part |
| 4.3 | Auger Housing | continuous-butter-churn-auger-housing | 1× | 1 | — | part |
| 4.4 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 5 | Drive Motor 4 parts | continuous-butter-churn-drive-motor | 1× | 1 | 4 | assembly |
| 5.1 | Motor | continuous-butter-churn-motor | 1× | 1 | — | part |
| 5.2 | Gearbox | continuous-butter-churn-gearbox | 1× | 1 | — | part |
| 5.3 | Drive Belt | drive-belt | 1× | 1 | — | part |
| 5.4 | Bearing Housing | continuous-butter-churn-bearing-housing | 1× | 1 | — | part |
| 6 | Drainage System 4 parts | continuous-butter-churn-drainage-system | 1× | 1 | 17 | assembly |
| 6.1 | Collection Tank | continuous-butter-churn-collection-tank | 1× | 1 | — | part |
| 6.2 | Pump Unit | continuous-butter-churn-pump-unit | 1× | 1 | — | part |
| 6.3 | Flow Meter | continuous-butter-churn-flow-meter | 1× | 1 | — | part |
| 6.4 | Swing / Wafer Check Valve 9 parts | check-valve | 1× | 1 | 14 | product |
| 6.4.1 | Valve Body | check-valve-body | 1× | 1 | — | part |
| 6.4.2 | Disc & Hinge 3 parts + deeper › | check-valve-disc-assy | 1× | 1 | 3 | assembly |
| 6.4.3 | Spring Poppet 3 parts + deeper › | check-valve-poppet-assy | 1× | 1 | 3 | assembly |
| 6.4.4 | Seat Ring | check-valve-seat-ring | 1× | 1 | — | part |
| 6.4.5 | Access Cover | check-valve-cover | 1× | 1 | — | part |
| 6.4.6 | Arm & Stop 2 parts + deeper › | check-valve-arm-stop | 1× | 1 | 2 | assembly |
| 6.4.7 | Flange Set | check-valve-flange-set | 1× | 1 | — | part |
| 6.4.8 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 6.4.9 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 7 | Control Unit 3 parts | continuous-butter-churn-control-unit | 1× | 1 | 3 | assembly |
| 7.1 | Control PLC | continuous-butter-churn-plc | 1× | 1 | — | part |
| 7.2 | Temperature Probe | continuous-butter-churn-temperature-probe | 1× | 1 | — | part |
| 7.3 | Motor VFD | continuous-butter-churn-motor-vfd | 1× | 1 | — | part |
