Continuous Ice Cream Freezer Product
Scraped-surface freezer barrel incorporating air injection, dasher action, and refrigeration to transform mix into ice cream at 5–15 L/min continuous throughput. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
7 top-level lines · 34 rows shown · 31 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Barrel Assembly 5 parts | continuous-ice-cream-freezer-barrel-assembly | 1× | 1 | 6 | assembly |
| 1.1 | Outer Jacket | continuous-ice-cream-freezer-outer-jacket | 1× | 1 | — | part |
| 1.2 | Inner Cylinder | continuous-ice-cream-freezer-inner-cylinder | 1× | 1 | — | part |
| 1.3 | Dasher Shaft | continuous-ice-cream-freezer-dasher-shaft | 1× | 1 | — | part |
| 1.4 | Stationary Scrapers | continuous-ice-cream-freezer-stationary-scrapers | 1× | 1 | — | part |
| 1.5 | Pressure Sensor | pressure-sensor | 2× | 2 | — | part |
| 2 | Dasher Drive 4 parts | continuous-ice-cream-freezer-dasher-drive | 1× | 1 | 5 | assembly |
| 2.1 | Drive Motor | continuous-ice-cream-freezer-drive-motor | 1× | 1 | — | part |
| 2.2 | Gearbox | continuous-ice-cream-freezer-gearbox | 1× | 1 | — | part |
| 2.3 | Shaft Coupling | continuous-ice-cream-freezer-shaft-coupling | 1× | 1 | — | part |
| 2.4 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 3 | Refrigeration 5 parts | continuous-ice-cream-freezer-refrigeration | 1× | 1 | 6 | assembly |
| 3.1 | Compressor | continuous-ice-cream-freezer-compressor | 1× | 1 | — | part |
| 3.2 | Condenser | continuous-ice-cream-freezer-condenser | 1× | 1 | — | part |
| 3.3 | Expansion Valve | continuous-ice-cream-freezer-expansion-valve | 1× | 1 | — | part |
| 3.4 | Receiver | continuous-ice-cream-freezer-receiver | 1× | 1 | — | part |
| 3.5 | Pressure Sensor | pressure-sensor | 2× | 2 | — | part |
| 4 | Air Injection 4 parts | continuous-ice-cream-freezer-air-injection | 1× | 1 | 4 | assembly |
| 4.1 | Air Pump | continuous-ice-cream-freezer-air-pump | 1× | 1 | — | part |
| 4.2 | Air Needle Valve | continuous-ice-cream-freezer-air-needle-valve | 1× | 1 | — | part |
| 4.3 | Air Filter | continuous-ice-cream-freezer-air-filter | 1× | 1 | — | part |
| 4.4 | Air Manifold | continuous-ice-cream-freezer-air-manifold | 1× | 1 | — | part |
| 5 | Product Pump 3 parts | continuous-ice-cream-freezer-product-pump | 1× | 1 | 4 | assembly |
| 5.1 | Feed Pump | continuous-ice-cream-freezer-feed-pump | 1× | 1 | — | part |
| 5.2 | Discharge Pump | continuous-ice-cream-freezer-discharge-pump | 1× | 1 | — | part |
| 5.3 | O-Ring Set | oring-set | 2× | 2 | — | part |
| 6 | Control Unit 3 parts | continuous-ice-cream-freezer-control-unit | 1× | 1 | 3 | assembly |
| 6.1 | Control PLC | continuous-ice-cream-freezer-plc | 1× | 1 | — | part |
| 6.2 | Temperature Sensors | continuous-ice-cream-freezer-temperature-sensors | 1× | 1 | — | part |
| 6.3 | Flow Meter | continuous-ice-cream-freezer-flow-meter | 1× | 1 | — | part |
| 7 | Discharge Valve 3 parts | continuous-ice-cream-freezer-discharge-valve | 1× | 1 | 3 | assembly |
| 7.1 | Solenoid Valve | continuous-ice-cream-freezer-solenoid-valve | 1× | 1 | — | part |
| 7.2 | Chiller Jacket | continuous-ice-cream-freezer-chiller-jacket | 1× | 1 | — | part |
| 7.3 | Check Valve | continuous-ice-cream-freezer-check-valve | 1× | 1 | — | part |
Sourcing — likely vendors
Companies that make this · indicative price $1k–$500k · MOQ & lead are typical| Vendor | HQ | Specialty | MOQ | Lead time |
|---|---|---|---|---|
| gea.com ↗ | Düsseldorf, DE | Process technology | 20 units | 12–20 wks |
| buhlergroup.com ↗ | Uzwil, CH | Food & materials processing | 20 units | 12–20 wks |
| tetrapak.com ↗ | Pully, CH | Food packaging & processing | 20 units | 12–20 wks |
| jbtc.com ↗ | Chicago, US | Food processing equipment | 20 units | 12–20 wks |
| alfalaval.com ↗ | Lund, SE | Heat transfer & separation | 20 units | 12–20 wks |
