Decontamination Shower System Product
Overview
A decontamination shower system is the engineered core of the "warm zone" at a hazardous-materials incident: a transportable shower line where contaminated people are washed before they reach clean areas, ambulances, or hospitals. Flushing with large volumes of warm water and mild detergent removes the bulk of most chemical, biological, and radiological surface contamination; studies behind current mass-decon doctrine credit prompt undressing and showering with removing on the order of 90 % or more of contaminant. The system exists to make that wash fast, private, warm, and contained.
A typical unit erects a roughly 3 × 6 m Shower Enclosure divided into three lanes — two ambulatory, one for stretcher casualties rolled through on trestles — and processes 60–100 walking casualties per hour. Everything packs into four wheeled Transport Case totaling under 500 kg, deployable by a hazmat team in five to ten minutes.
Structure and casualty flow
The Frame Pole Set erect a scissor or hub frame carrying the welded PVC Canopy and Walls; inflatable-arch variants trade the pole set for a small air blower. Inside, Lane Curtain divide lanes and screen the undress stage, and weighted Entry/Exit Flap at each end enforce one-way flow from the dirty (hot-zone) side to the clean side, reinforced by the Zone Signage Set zone markers. Occupants stand on Floor Grating Panel panels that keep feet above the runoff layer — direct contact with pooled rinse water would simply recontaminate them.
Water supply and heating
Cold-water decontamination causes hypothermia within minutes, especially in casualties who have just undressed outdoors, so heating is not optional. The Supply Pump draws from a hydrant, water tender, or bladder through the Inlet Strainer and pushes 60–100 L/min into the Water Heater. This is a tankless propane unit: the Propane Burner modulates between roughly 70 and 120 kW to track flow, transferring heat through a single-pass copper Heat Exchanger. The Outlet Thermostat holds the outlet near 38 °C, a Thermal Fuse provides a hard overtemperature cutout, and a Pressure Sensor interlock stops the Gas Control Valve from opening without water flow, preventing a dry-fired exchanger. Downstream, the Thermostatic Mixing Valve blends in a cold bypass as an anti-scald guarantee — delivered water can never exceed the valve's setpoint even if the heater control fails high.
Heated water feeds the Spray System through color-coded Supply Hose Set with cam-lock couplings. Each lane has an arched Spray Manifold carrying six full-cone Spray Nozzle aimed at head, torso, and leg height. Nozzle selection is deliberate: 3–6 L/min each at 2–3 bar gives soaking coverage without the fine high-pressure mist that would aerosolize contaminant into attendants' breathing zones. Attendants in the non-ambulatory lane use the trigger-operated Handheld Wand to wash stretcher casualties systematically, head to toe.
Wastewater containment
Runoff from a decon line is itself hazardous waste. The entire enclosure stands inside the Containment Pool Liner, a welded-seam berm liner holding 1000–2000 L. A Sump Level Float starts the chemical-rated submersible Sump Transfer Pump before runoff reaches grating level, transferring it through the dedicated Waste Transfer Hose to a collapsible Wastewater Bladder of 2000–5000 L for later licensed disposal. US practice under EPA guidance permits uncontained runoff when lives are at immediate risk, but teams are expected to capture wastewater whenever the equipment is available — which is much of why this equipment exists.
Power and control
A small generator or shore connection feeds the Power Distribution Box, with every circuit behind the GFCI Breaker breaker given that pumps, lights, and standing water share the same footprint. A Power Supply converts to low voltage for heater controls, Relay interlocks enable pump and burner only when supply pressure exists, and IP65 LED Lane Light in each lane support night operations. The Stake and Guy Kit guys the structure against winds to roughly 60 km/h, and the Field Repair Kit carries patch material and spare nozzles, since a torn liner or clogged nozzle cannot be allowed to stop a casualty line mid-incident.
Operational context
Deployment doctrine follows OSHA HAZWOPER (29 CFR 1910.120) and NFPA 470: the shower line sits in the warm zone on the upwind, uphill edge of the contaminated area, with undress at the dirty end, wash and rinse in the middle, and monitoring plus redress kits at the clean end. Technical decontamination of suited entry teams uses the same hardware at lower throughput, with wash steps tailored to the agent. The recurring engineering constraints — warm water at volume, no aerosols, total runoff capture, ten-minute setup — drive every component choice above.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labourTap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
7 top-level lines · 56 rows shown · 102 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Shower Enclosure 6 parts | decon-shower-system-enclosure | 1× | 1 | 15 | assembly |
| 1.1 | Frame Pole Set | decon-shower-system-frame-poles | 1× | 1 | — | part |
| 1.2 | Canopy and Walls | decon-shower-system-canopy | 1× | 1 | — | part |
| 1.3 | Lane Curtain | decon-shower-system-curtains | 4× | 4 | — | part |
| 1.4 | Floor Grating Panel | decon-shower-system-floor-grating | 6× | 6 | — | part |
| 1.5 | Entry/Exit Flap | decon-shower-system-entry-flaps | 2× | 2 | — | part |
| 1.6 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Water Heater 7 parts | decon-shower-system-water-heater | 1× | 1 | 7 | assembly |
| 2.1 | Propane Burner | decon-shower-system-burner | 1× | 1 | — | part |
| 2.2 | Heat Exchanger | decon-shower-system-heat-exchanger | 1× | 1 | — | part |
| 2.3 | Gas Control Valve | decon-shower-system-gas-valve | 1× | 1 | — | part |
| 2.4 | Outlet Thermostat | decon-shower-system-thermostat | 1× | 1 | — | part |
| 2.5 | Flue Stack | decon-shower-system-flue | 1× | 1 | — | part |
| 2.6 | Thermal Fuse | thermal-fuse | 1× | 1 | — | part |
| 2.7 | Pressure Sensor | pressure-sensor | 1× | 1 | — | part |
| 3 | Supply Pump 7 parts | decon-shower-system-supply-pump | 1× | 1 | 28 | assembly |
| 3.1 | Pump Head | decon-shower-system-pump-head | 1× | 1 | — | part |
| 3.2 | Stator Assembly 3 parts | stator-assembly | 1× | 1 | 3 | assembly |
| 3.2.1 | Stator Core (laminations) | stator-core | 1× | 1 | — | part |
| 3.2.2 | Copper Winding | copper-winding | 1× | 1 | — | part |
| 3.2.3 | Slot Insulation | stator-insulation | 1× | 1 | — | part |
| 3.3 | Rotor Assembly 4 parts | rotor-assembly | 1× | 1 | 19 | assembly |
| 3.3.1 | Rotor Shaft | rotor-shaft | 1× | 1 | — | part |
| 3.3.2 | Rotor Core | rotor-core | 1× | 1 | — | part |
| 3.3.3 | Neodymium Magnet | neodymium-magnet | 16× | 16 | — | part |
| 3.3.4 | Ball Bearing | ball-bearing | 1× | 1 | — | part |
| 3.4 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 3.5 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 3.6 | Oil Seal | oil-seal | 1× | 1 | — | part |
| 3.7 | Inlet Strainer | decon-shower-system-inlet-strainer | 1× | 1 | — | part |
| 4 | Spray System 6 parts | decon-shower-system-spray-system | 1× | 1 | 26 | assembly |
| 4.1 | Spray Manifold | decon-shower-system-manifold-pipes | 3× | 3 | — | part |
| 4.2 | Spray Nozzle | decon-shower-system-nozzles | 18× | 18 | — | part |
| 4.3 | Handheld Wand | decon-shower-system-hand-wand | 2× | 2 | — | part |
| 4.4 | Thermostatic Mixing Valve | decon-shower-system-mixing-valve | 1× | 1 | — | part |
| 4.5 | Supply Hose Set | decon-shower-system-supply-hoses | 1× | 1 | — | part |
| 4.6 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 5 | Wastewater Recovery 5 parts | decon-shower-system-waste-recovery | 1× | 1 | 5 | assembly |
| 5.1 | Containment Pool Liner | decon-shower-system-containment-pool | 1× | 1 | — | part |
| 5.2 | Sump Transfer Pump | decon-shower-system-sump-pump | 1× | 1 | — | part |
| 5.3 | Wastewater Bladder | decon-shower-system-waste-bladder | 1× | 1 | — | part |
| 5.4 | Waste Transfer Hose | decon-shower-system-waste-hose | 1× | 1 | — | part |
| 5.5 | Sump Level Float | decon-shower-system-level-float | 1× | 1 | — | part |
| 6 | Power and Electrical 7 parts | decon-shower-system-power-electrical | 1× | 1 | 14 | assembly |
| 6.1 | Power Supply | power-supply | 1× | 1 | — | part |
| 6.2 | Power Distribution Box | decon-shower-system-distribution-box | 1× | 1 | — | part |
| 6.3 | GFCI Breaker | decon-shower-system-gfci | 1× | 1 | — | part |
| 6.4 | LED Lane Light | decon-shower-system-led-lights | 4× | 4 | — | part |
| 6.5 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 6.6 | Relay | relay | 2× | 2 | — | part |
| 6.7 | Connector | connector | 4× | 4 | — | part |
| 7 | Deployment Kit 4 parts | decon-shower-system-deployment-kit | 1× | 1 | 7 | assembly |
| 7.1 | Transport Case | decon-shower-system-transport-cases | 4× | 4 | — | part |
| 7.2 | Stake and Guy Kit | decon-shower-system-stake-kit | 1× | 1 | — | part |
| 7.3 | Field Repair Kit | decon-shower-system-repair-kit | 1× | 1 | — | part |
| 7.4 | Zone Signage Set | decon-shower-system-signage | 1× | 1 | — | part |
