Hair Dryer Product
Sourcing — likely vendors
Real suppliers (🇮🇳 🇸🇬 🇨🇳); price, MOQ & lead time are estimates| Vendor | HQ | Specialty | Est. unit price | MOQ | Lead time |
|---|---|---|---|---|---|
| 🇨🇳Foxconn foxconn.com ↗ | Shenzhen, CN | Electronics contract mfg | $95 | 1,000 pcs | 6–10 wks |
| flex.com ↗ | Singapore | Electronics contract mfg | $67 | 1,000 pcs | 6–10 wks |
| dixoninfo.com ↗ | Noida, IN | Electronics contract mfg | $98 | 1,000 pcs | 6–10 wks |
| bydelectronic.com ↗ | Shenzhen, CN | Electronics contract mfg | $75 | 1,000 pcs | 6–10 wks |
| venture.com.sg ↗ | Singapore | Electronics contract mfg | $76 | 1,000 pcs | 6–10 wks |
A high-speed brushless hair dryer with ionizer and magnetic nozzles. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
9 top-level lines · 50 rows shown · 63 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Housing 6 parts | hair-dryer-housing | 1× | 1 | 7 | assembly |
| 1.1 | Handle Shell | hair-dryer-handle-shell | 1× | 1 | — | part |
| 1.2 | Barrel Half Shell | hair-dryer-barrel-half | 2× | 2 | — | part |
| 1.3 | Air Inlet Filter | hair-dryer-inlet-filter | 1× | 1 | — | part |
| 1.4 | Air Inlet Mesh | hair-dryer-inlet-mesh | 1× | 1 | — | part |
| 1.5 | Nozzle Concentrator Attachment | hair-dryer-concentrator | 1× | 1 | — | part |
| 1.6 | Rear Cap | hair-dryer-rear-cap | 1× | 1 | — | part |
| 2 | High-Speed Brushless Motor 7 parts | hair-dryer-motor | 1× | 1 | 32 | assembly |
| 2.1 | Stator Assembly 3 parts | stator-assembly | 1× | 1 | 3 | assembly |
| 2.1.1 | Stator Core (laminations) | stator-core | 1× | 1 | — | part |
| 2.1.2 | Copper Winding | copper-winding | 1× | 1 | — | part |
| 2.1.3 | Slot Insulation | stator-insulation | 1× | 1 | — | part |
| 2.2 | Rotor Assembly 4 parts | rotor-assembly | 1× | 1 | 19 | assembly |
| 2.2.1 | Rotor Shaft | rotor-shaft | 1× | 1 | — | part |
| 2.2.2 | Rotor Core | rotor-core | 1× | 1 | — | part |
| 2.2.3 | Neodymium Magnet | neodymium-magnet | 16× | 16 | — | part |
| 2.2.4 | Ball Bearing | ball-bearing | 1× | 1 | — | part |
| 2.3 | Neodymium Magnet | neodymium-magnet | 2× | 2 | — | part |
| 2.4 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 2.5 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 2.6 | Impeller Fan | hair-dryer-impeller | 1× | 1 | — | part |
| 2.7 | Motor Controller Board 3 parts | hair-dryer-motor-controller | 1× | 1 | 4 | assembly |
| 2.7.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 2.7.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 2.7.3 | Connector | connector | 2× | 2 | — | part |
| 3 | Heating Assembly 4 parts | hair-dryer-heating | 1× | 1 | 5 | assembly |
| 3.1 | Heating Element | heating-element | 1× | 1 | — | part |
| 3.2 | Mica/Ceramic Former | hair-dryer-mica-former | 1× | 1 | — | part |
| 3.3 | Thermistor Sensor | hair-dryer-thermistor | 2× | 2 | — | part |
| 3.4 | Thermal Cutoff Fuse | hair-dryer-thermal-fuse | 1× | 1 | — | part |
| 4 | Ionizer 2 parts | hair-dryer-ionizer | 1× | 1 | 2 | assembly |
| 4.1 | Ion Generator Module | hair-dryer-ion-generator | 1× | 1 | — | part |
| 4.2 | Ion Emitter Needle | hair-dryer-ion-needle | 1× | 1 | — | part |
| 5 | Controls 5 parts | hair-dryer-controls | 1× | 1 | 7 | assembly |
| 5.1 | Power Switch | hair-dryer-power-switch | 1× | 1 | — | part |
| 5.2 | Heat Selector Switch | hair-dryer-heat-switch | 1× | 1 | — | part |
| 5.3 | Speed Selector Switch | hair-dryer-speed-switch | 1× | 1 | — | part |
| 5.4 | Cold-Shot Button | hair-dryer-cold-shot | 1× | 1 | — | part |
| 5.5 | Control PCB 2 parts | hair-dryer-control-pcb | 1× | 1 | 3 | assembly |
| 5.5.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 5.5.2 | Connector | connector | 2× | 2 | — | part |
| 6 | Power Cord 3 parts | hair-dryer-power-cord | 1× | 1 | 3 | assembly |
| 6.1 | Mains Cable | hair-dryer-cord | 1× | 1 | — | part |
| 6.2 | Mains Plug | hair-dryer-plug | 1× | 1 | — | part |
| 6.3 | Strain Relief Grommet | hair-dryer-strain-relief | 1× | 1 | — | part |
| 7 | Magnetic Nozzle Ring 2 parts | hair-dryer-nozzle-ring | 1× | 1 | 5 | assembly |
| 7.1 | Nozzle Ring Body | hair-dryer-ring-body | 1× | 1 | — | part |
| 7.2 | Neodymium Magnet | neodymium-magnet | 4× | 4 | — | part |
| 8 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 9 | Fastener Set | fastener-set | 1× | 1 | — | part |
