Lat Pulldown Machine

Overview

A lat pulldown trains the back: the user sits, grips a wide bar overhead, and pulls it down to the chest against a stack of weights. It is the seated, scalable counterpart to a pull-up, and because resistance comes from a selectorized stack rather than bodyweight, anyone can dial in a load that suits them.

The machine stands on a welded Steel Frame whose tall mast carries the top pulley directly above the seat, with a Stack Tower alongside it for the weights. The user grips the Lat Pulldown Bar, braces under the Thigh Hold-Down, and sits on the Seat Pad while the pull lifts the Selectorized Weight Stack through the Pulley Cable Train.

How it works

Resistance lives in the Selectorized Weight Stack: a column of Weight Plate plates riding two Guide Rod rods. Pushing the Selector Pin through a chosen plate ties every plate above it to the cable, so the user lifts only the weight selected. The plate at the top is the driven Top Plate the cable attaches to, and a rubber bumper cushions the stack as it returns.

The pull travels through the Pulley Cable Train. A Steel Cable runs from the top plate up over a top Pulley and down to the bar; each pulley is a grooved wheel on a sealed ball bearing, so the cable turns its corners with little friction and the lift feels even from start to finish. Cable thimbles protect the eyes where the cable is swaged to its fittings.

At the hands, the Lat Pulldown Bar hangs from a Bar Swivel so it can spin freely as the grip rotates through the rep, sparing the wrists. Because the stack pulls upward through the bar, the user has to be anchored down: the Thigh Hold-Down clamps the thighs with two pads, and a pop-pin adjuster sets its height so a tall or short user is held just as firmly against the lift.
