A hot-swappable wireless mechanical keyboard: gasket-mounted steel plate, a hot-swap PCB with per-key RGB and a wireless module, PBT doubleshot keycaps, a CNC aluminium case with weight and dampening foam, screw-in stabilizers, and a LiPo battery for Bluetooth use. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
12 top-level lines · 50 rows shown · 999 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Case 6 parts | mechanical-keyboard-case | 1× | 1 | 6 | assembly |
| 1.1 | Top Case | mechanical-keyboard-top-case | 1× | 1 | — | part |
| 1.2 | Bottom Case | mechanical-keyboard-bottom-case | 1× | 1 | — | part |
| 1.3 | Brass Weight | mechanical-keyboard-weight | 1× | 1 | — | part |
| 1.4 | Case Foam | mechanical-keyboard-case-foam | 1× | 1 | — | part |
| 1.5 | Plate Foam | mechanical-keyboard-plate-foam | 1× | 1 | — | part |
| 1.6 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Switch Plate | mechanical-keyboard-plate | 1× | 1 | — | part |
| 3 | PCB Assembly 11 parts | mechanical-keyboard-pcb-assembly | 1× | 1 | 329 | assembly |
| 3.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 3.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 3.3 | Hot-Swap Socket | mechanical-keyboard-hotswap-socket | 87× | 87 | — | part |
| 3.4 | Matrix Diode | mechanical-keyboard-diode | 87× | 87 | — | part |
| 3.5 | RGB LED | mechanical-keyboard-rgb-led | 87× | 87 | — | part |
| 3.6 | SMD Passive (R/C/L) | smd-passives | 60× | 60 | — | part |
| 3.7 | USB-C Connector | mechanical-keyboard-usb-c-connector | 1× | 1 | — | part |
| 3.8 | Wireless Module | mechanical-keyboard-wireless-module | 1× | 1 | — | part |
| 3.9 | FPC Connector | mechanical-keyboard-fpc-connector | 2× | 2 | — | part |
| 3.10 | Reset Switch | mechanical-keyboard-reset-switch | 1× | 1 | — | part |
| 3.11 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 4 | Mechanical Switch 6 parts | mechanical-keyboard-switch | 87× | 87 | 7 | assembly |
| 4.1 | Switch Top Housing | mechanical-keyboard-switch-top-housing | 1× | 87 | — | part |
| 4.2 | Switch Bottom Housing | mechanical-keyboard-switch-bottom-housing | 1× | 87 | — | part |
| 4.3 | Switch Stem | mechanical-keyboard-switch-stem | 1× | 87 | — | part |
| 4.4 | Coil Spring | coil-spring | 1× | 87 | — | part |
| 4.5 | Contact Leaf | mechanical-keyboard-switch-contact-leaf | 2× | 174 | — | part |
| 4.6 | Switch Slider | mechanical-keyboard-switch-slider | 1× | 87 | — | part |
| 5 | Keycap Set | mechanical-keyboard-keycap-set | 1× | 1 | — | part |
| 6 | Stabilizer 4 parts | mechanical-keyboard-stabilizer | 5× | 5 | 6 | assembly |
| 6.1 | Stabilizer Wire | mechanical-keyboard-stab-wire | 1× | 5 | — | part |
| 6.2 | Stabilizer Housing | mechanical-keyboard-stab-housing | 2× | 10 | — | part |
| 6.3 | Stabilizer Insert | mechanical-keyboard-stab-insert | 2× | 10 | — | part |
| 6.4 | Fastener Set | fastener-set | 1× | 5 | — | part |
| 7 | Gasket Set | mechanical-keyboard-gasket-set | 1× | 1 | — | part |
| 8 | Battery Pack 3 parts | mechanical-keyboard-battery | 1× | 1 | 3 | assembly |
| 8.1 | LiPo Cell | lipo-cell | 1× | 1 | — | part |
| 8.2 | BMS Board | bms-board | 1× | 1 | — | part |
| 8.3 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 9 | USB-C Daughterboard 4 parts | mechanical-keyboard-daughterboard | 1× | 1 | 9 | assembly |
| 9.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 9.2 | USB-C Connector | mechanical-keyboard-usb-c-connector | 1× | 1 | — | part |
| 9.3 | FPC Connector | mechanical-keyboard-fpc-connector | 1× | 1 | — | part |
| 9.4 | SMD Passive (R/C/L) | smd-passives | 6× | 6 | — | part |
| 10 | USB-C Cable 2 parts | mechanical-keyboard-cable | 1× | 1 | 3 | assembly |
| 10.1 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 10.2 | Connector | connector | 2× | 2 | — | part |
| 11 | Feet & Tilt Legs 2 parts | mechanical-keyboard-foot-set | 1× | 1 | 6 | assembly |
| 11.1 | Tilt Leg | mechanical-keyboard-tilt-leg | 2× | 2 | — | part |
| 11.2 | Rubber Foot | mechanical-keyboard-rubber-foot | 4× | 4 | — | part |
| 12 | Fastener Set | fastener-set | 1× | 1 | — | part |
