Overview

A playground zip line — formally a cableway or aerial runway under EN 1176-4 — is the simplest powered ride there is: the power is gravity and the track is a single wire rope. The Cable Span runs 20-30 m between a Start Tower and a End Anchor with a few percent of fall; the rider boards the Seat Rig hanging from the Trolley, pushes off, accelerates to 3-6 m/s through the sag of the cable, and is caught at the far end by the Brake System. Everything underneath is Safety Surfacing.

The cable as a track

The Wire Rope is 8-12 mm galvanized steel in 6×19 construction — six strands of nineteen wires, chosen because it is flexible enough to grip in clamps yet stiff enough to resist crushing under the trolley wheels. Its minimum breaking load runs to several tonnes against a design rider load under 100 kg; EN 1176 effectively demands a safety factor of five or more once dynamic loads are counted.

Each end terminates in an eye formed around a Thimble and locked with three Cable Clamp U-bolts (saddle on the live side — the installer's rule "never saddle a dead horse"), then connects through a rated Shackle to the tower's Anchor Plate. The Turnbuckle sets the working tension. Tension is the key tuning parameter: tighter cable means less sag, a faster and flatter ride, and much higher anchor loads — a taut cable multiplies rider weight several-fold through the shallow-angle geometry, which is why the Concrete Footing blocks under each mast are engineering items, typically a metre deep. The Tension Indicator gives inspectors a sag reference, because wire rope creeps and needs seasonal re-tensioning.

Trolley and seat

The Trolley Body is a closed housing: it wraps fully around the cable so it cannot derail in use or be lifted off mid-span, and can only be installed at an open termination. Inside, two grooved Sheave Wheel runners on sealed Ball Bearing sets carry the load; the groove is profiled to the rope diameter so contact pressure stays low and the rope's galvanizing survives. A bearing-mounted Swivel Eye hangs the seat so the rider can spin without winding up the trolley, and rubber Trolley Bumper pads take the repeated brake impacts. Hang-and-ride versions substitute a Handle Bar for the seat.

The standard playground seat is a rotomolded Disc Seat on a steel-reinforced Seat Rope — deliberately a straddle disc rather than a comfortable chair, because a disc sheds a rider who tries to stand on it, and EN 1176 requires that the seat not trap the rider. The Rope Adjuster sets the seat roughly 400 mm above the surfacing under load. Inclusive installations add a full bucket Seat Assembly with a backrest at the cost of supervised boarding.

Stopping the rider

All the kinetic energy — a 50 kg child at 5 m/s carries about 625 J — has to go somewhere soft. The primary brake is the Brake Spring, a long helical compression spring threaded over the cable near the low end and backed by a clamped Spring Anchor. The trolley bumper meets the spring and decelerates over 0.6-1.2 m, keeping peak deceleration to a fraction of a g rather than the jolt a hard stop would give; the spring then throws the trolley gently back up-cable, which riders treat as part of the ride. A secondary Coil Spring buffer and a hard End Stop clamp guard the failure case so the trolley can never reach the End Mast. The cable's own up-slope at the end (the catenary rises toward the anchor) does much of the braking for free.

Site and safety

The Platform Deck at the start is kept low — a mound or low deck — so the free height of fall stays within what the surfacing can absorb. The full ride corridor gets a Surfacing Layer of around 300 mm engineered wood fibre or equivalent rubber, retained by an Edge Restraint, with clearance zones either side of the cable kept free of equipment. Inspection is routine and specific: clamp torque, rope wear and broken-wire counts, bearing play in the trolley, spring condition, and sag measurement — the same checklist a small ropeway would get, scaled to a playground.
