A walk-behind broadcast spreader spreads granular material — winter de-icing salt, lawn fertiliser, or grass seed — in a wide, even fan as the operator pushes it. It is a rotary or "broadcast" spreader, distinct from a drop spreader: material falls onto a spinning disc that flings it outward, covering a 2–4 m swath in one pass rather than laying a narrow precise band. The mechanism is entirely ground-driven, taking all its power from the turning of the wheels, so there is nothing to start or charge.

Material sits in the Hopper, an Agitator keeps it flowing to the outlet, a Flow Gate meters how much drops through, and the Spinner Disc & Gearbox disc broadcasts it. The operator works it all from levers on the Frame & Wheels handle.

How it works

As the operator pushes, the two Wheel Assembly drive wheels turn the Drive Axle, whose pinion drives a Helical Gear Pair step-up inside the sealed Gearbox Housing. This spins the Spinner Shaft roughly four to five times faster than the wheels, so the Spinner Disc whirls at a few hundred rpm even at walking pace. Material drops from the Outlet Ports onto the moving disc; the radial fins catch each granule and throw it outward by centrifugal action, producing a fan that lands well clear of the operator's feet.

Because spread width depends on disc speed, faster walking throws material wider and thinner — which is why broadcast spreaders are calibrated as a rate per area rather than a fixed band. The Adjustable Fin Set can be repositioned to bias the pattern, throwing more to one side for edge work along a path or wall.

Metering the rate

The single most important adjustment is the Flow Gate. A sliding Gate Plate sits under the hopper outlets; its opening, from fully shut to wide open, sets how much material falls per second. A numbered Rate Cam limits the gate travel so a chosen setting — say, "12" for a particular fertiliser — repeats exactly each time. The operator presets this with the Rate Lever, then uses the On/Off Lever trigger, linked by the Gate Cable, to open the gate only while actually over the target area and snap it shut at the headland. Getting the rate right matters in both directions: too little salt leaves ice, too much wastes material and, for fertiliser, scorches the lawn in stripes where passes overlapped.

A Gate Seal wiper stops fine material dribbling out when the gate is closed, important with free-flowing salt that would otherwise leave a trail across a clean path.

Keeping material flowing

Salt and fertiliser are both hygroscopic and prone to caking, and fine or damp material tends to "bridge" — arch over the outlet holes and stop feeding, so the disc spins but throws nothing. The Agitator solves this: an Agitator Arm driven off the spinner shaft sweeps just above the Outlet Ports, constantly breaking any arch that forms. A Lump Screen in the filling mouth knocks apart lumps before they ever reach the gate, and a clip-on Rain Cover keeps the load dry between passes.

Edge control and use

Broadcasting is fast but imprecise at boundaries, where flung salt or weed-and-feed lands on flowerbeds, ponds, or the neighbour's drive. The flip-down Edge Deflector blocks one side of the fan so the operator can run a clean line along an edge, then flip it up to spread full-width in the open.

Calibration is worth doing once per material: spread a measured weight over a measured area at a fixed gate setting and pace, weigh what is left, and adjust. For de-icing salt the usual target is 10–40 g/m² depending on conditions; over-salting damages turf and corrodes nearby metal. After winter use the whole unit must be rinsed thoroughly — salt is brutally corrosive, and a spreader put away wet will have a seized gate and rusted axle by spring. Rinse the hopper, work the gate, and oil the Drive Axle and spinner bearings before storage.
