Wireless Lavalier System Product

Overview

Wireless lavalier systems give on-camera talent freedom of movement during interviews and demonstrations. The microphone is a small omnidirectional lapel-mounted capsule (wired to a bodypack transmitter), and the audio is transmitted over UHF radio to a stationary receiver. The receiver outputs line-level audio to a mixing console or audio recorder, providing pristine dialogue capture without visible microphone booms or cables.

This system emphasizes simplicity and reliability for documentary and narrative production. The bodypack is pocket-sized and inconspicuous; the lavalier capsule clips to a lapel or collarbone. Dual-channel design supports two talent simultaneously, enabling interview setups with host and subject. Diversity antenna reception combats multipath fading in challenging RF environments like warehouses or buildings.

Wireless Signal Path

Audio begins at the Lavalier Microphone omnidirectional condenser capsule. The capsule is wired to the Bodypack Transmitter pocket transmitter via a thin shielded cable. The TX Preamp single-channel preamp amplifies the capsule signal and applies a manually adjustable gain knob (−20 to +20 dB range), compensating for varying microphone output levels or source distances.

The amplified audio modulates the RF carrier in the TX RF Module, a UHF transceiver operating in the 470–600 MHz ISM band. The modulation is frequency modulation (FM), chosen for its inherent noise rejection: weak signals are quieter but intelligible, whereas AM (amplitude modulation) degrades with distance. The transmitter outputs 100 mW, sufficient for 100–150 meter line-of-sight range.

The Antenna System diversity pair receives the transmitted RF signal. The two antennas are spatially separated (often 1–2 meters apart); multipath reflections create constructive and destructive interference patterns that vary with position. By monitoring both antennas and selecting the one with the stronger signal, the Antenna Combiner combiner ensures robust reception even as the talent moves around.

The Diversity Receiver diversity receiver demodulates the FM signal in the Demodulator IC, recovering the original audio. An automatic gain control (AGC) circuit normalizes the demodulated level, compensating for transmitter distance and RF fading. The Audio DAC converts the digital audio to analog, and the XLR Output Driver delivers balanced line-level XLR output to the console or recorder.

Bodypack Design and Comfort

The Bodypack Transmitter transmitter is compact (120 x 80 x 40 mm) and weighs only 150 grams. It clips to a belt, fits in a shirt pocket, or is concealed in a waistband pocket. The TX Battery lithium-polymer cell provides 8 hours of runtime, ample for a full shooting day.

Two buttons control operation: a mute button (silencing the microphone) and a power button. The LED Indicators dual LED provides visual feedback—green when armed and transmitting, red when muted, amber on low battery. The gain knob is positioned on the side, allowing the talent or boom operator to pre-set the signal level before rolling.

Microphone Capsule and Placement

The Lavalier Microphone is a 4 mm omnidirectional condenser capsule rated 40 Hz–18 kHz. Omnidirectional means it picks up sound equally from all directions, which is essential for interviews where talent may turn their head during dialogue. A cardioid (directional) lavalier would suffer from terrible off-axis response when the talent looks away.

The capsule is wired via a thin shielded cable (1.2 m, allowing it to reach from waistband transmitter to collar mic position). The Lapel Clip clips the capsule to a lapel, shirt button, or neckline using a rubber-padded clip that avoids damaging fabric. The Foam Windscreen foam cover reduces wind noise (essential for outdoor interviews) and plosive breath sounds.

Optimal mic placement is 15–20 cm from the mouth, centered on the chest. This distance produces a presence peak in the presence region (2–5 kHz) that favors intelligibility. Closer placement (5–10 cm) increases proximity effect (bass boost) and picking up clothing rustle; farther placement (30+ cm) reduces signal-to-noise ratio and picks up more background.

Receiver and Monitoring

The Diversity Receiver is a 1U rack-mount unit with dual-channel RF modules. The RX MCU processor handles frequency programming via the front-panel LCD menu, allowing field crews to reprogram frequency within the ISM band if interference is encountered. The receiver outputs stereo XLR (one per transmitter) at 0 dBu (nominal) or −6 dBu (hot) selectable on the back panel.

The RX Enclosure includes ventilation slots; the receiver generates minimal heat (RF demodulation is low-power) and rarely requires active cooling. A headphone output (mini-jack) allows the sound operator to monitor both channels simultaneously during recording.

Charging and On-Set Workflow

The Charging Case is a USB-C powered smart case that charges the bodypack battery in 3–4 hours (or 30 minutes with a fast-charger PSU upgrade). During a meal break, the talent can drop their transmitter in the case, and by lunch's end, the battery is fully charged.

Before rolling: the boom operator or sound assistant turns on the bodypack and receiver, checks frequency match, sets gain with a quick voice test through the receiver's headphone output, and rolls camera. During the scene, the operator monitors RF level and audio level on the receiver's LCD. If RF signal drops (talent moves too far away), the operator can either move the antennas closer or ask the talent to move within range.

Interference and Frequency Coordination

The 470–600 MHz ISM band is shared with TV broadcasts, wireless microphone systems, and other licensed devices. In congested markets (cities with many active broadcast TV stations), interference is possible. The receiver's LCD displays RF signal strength and demodulation quality, allowing the operator to detect interference immediately.

If interference occurs, the TX MCU and RX MCU support frequency-agile reprogramming. The operator selects a new frequency pair (one for each channel) via a menu, and both bodypack and receiver are reprogrammed in seconds. Most professional systems come with a frequency scanner app that identifies quiet frequencies before the shoot.

Diversity Reception and Multipath

In studios with hard walls (concrete, glass), RF energy reflects, creating standing wave patterns. A transmitter 10 meters away might have weak signal in one corner due to destructive interference. The diversity antenna system measures signal strength on both antennas and automatically selects the antenna with the stronger (more constructive) RF. This switching happens 50+ times per second, seamlessly combating multipath fading.

In open-air locations (outdoor interviews), diversity offers less benefit, but the reduced impedance mismatch from the antenna pair still provides slight improvements over a single antenna.

Limitations and Constraints

UHF wireless operates best line-of-sight. Obstacles (walls, dense foliage, vehicle bodies) block signal. Indoor range is typically 50 meters; outdoor range stretches to 100–150 meters. Tunnels or metal-walled buildings severely attenuate UHF and are incompatible.

RF interference from nearby high-power radio or TV transmitters can degrade audio. Frequency coordination before the shoot is essential in major metropolitan areas. Professional wireless rentals include interference scanning and frequency database services.

The FM modulation scheme has a capture effect: if two transmitters are active on overlapping frequencies, the receiver locks to whichever one has the stronger signal. This is useful for automatic selection but means having two identical systems in close proximity requires careful frequency separation (typically 500 kHz or more).

Talent wearing metal-heavy costumes (chain mail, foil), or holding metal objects (swords, large reflectors) can detune the bodypack antenna and reduce range. Field crews position antennas carefully to avoid occlusion by talent or set.
