Concert Pedal Harp Product

Overview

The concert pedal harp is a large orchestral and solo performance instrument capable of playing in all keys through a seven-pedal pitch-shifting mechanism. With 47 strings tuned to a diatonic scale and spanning 6.5 octaves, it produces a rich, resonant tone across its entire range. The [[concert-harp-frame|frame assembly]] supports extreme string tension—approximately 6–7 metric tons total—while the [[concert-harp-pedal-mechanism|pedal mechanism]] allows rapid harmonic shifts during performance.

Each of the seven [[concert-harp-pedal-rod|pedals]] engages a separate set of [[concert-harp-disc-set|discs]] that mechanically shorten the [[concert-harp-strings|active string length]] by precise amounts. By engaging one, two, or all three pedals in positions 1, 2, and 3 (corresponding to flats, naturals, and sharps), the player can play in any chromatic key. This mechanical advantage eliminates the need for manual retuning and enables smooth harmonic changes mid-performance.

The instrument's resonance depends on a carefully selected [[concert-harp-soundboard|soundboard]] of quarter-sawn European spruce and a rigid [[concert-harp-column|column]] and [[concert-harp-forepillar|forepillar]] to counteract string tension. String selection—[[concert-harp-treble-strings|nylon treble]], [[concert-harp-mid-strings|wound mid-register]], and [[concert-harp-bass-strings|copper-wound bass]]—affects both tone color and playing feel.

Concert harps are handcrafted instruments, with each model taking several months to complete. They are the standard in orchestras, chamber ensembles, and solo recitals worldwide.

How it works

The harp generates sound through vibrating strings held at precise tension by the [[concert-harp-frame|frame]]. When a player plucks a string, it oscillates and transfers energy to the [[concert-harp-soundboard|soundboard]], which amplifies and colors the tone before radiating it into the air.

The [[concert-harp-pedal-mechanism|pedal mechanism]] works through a series of interconnected [[concert-harp-pedal-rod|rods]] and [[concert-harp-disc-set|discs]]. When a pedal is pressed, it tilts the discs inward, forcing two sharp metal plates (called sharping head and flat head) to shorten the vibrating length of strings tuned to the same note. For example, if the harp is tuned in C major, pressing pedal 1 raises all Cs to C♯ by reducing string length by a semitone. Pressing pedal 2 raises all Fs to F♯, and pedal 3 raises all Bs to B♯.

The [[concert-harp-tuning-pin-set|tuning pins]] at the top of the [[concert-harp-neck|neck]] hold the string ends and provide initial pitch adjustment. A professional [[concert-harp-tuning-key|tuning key]] is required to adjust these pins before each performance. The [[concert-harp-spring-set|return springs]] beneath each pedal base pull the discs back to neutral when released, restoring the original pitch.

String tension is critical: [[concert-harp-treble-strings|treble strings]] carry 50 kg tension each, [[concert-harp-mid-strings|mid strings]] carry 60–80 kg, and [[concert-harp-bass-strings|bass strings]] carry 80–100 kg. The [[concert-harp-column|column]] and [[concert-harp-belly-rail|belly rail]] distribute this load and prevent frame collapse. Periodic maintenance includes replacing worn strings, lubricating pedal joints, and re-varnishing the [[concert-harp-soundboard|soundboard]] to maintain tonal clarity.

Variants and construction notes

Standard concert harp specifications are set by ISO 7378 and maintained by organizations like the American Harp Society. The three main tonal categories are American (bright, direct), Italian (warm, complex), and German (mellow, distributed). Each uses different wood combinations and soundboard thicknesses.

Full restoration of a concert harp requires 2–3 years of skilled lutherie work. The [[concert-harp-frame|frame]] must be structurally sound and resistant to humidity changes; even small shifts cause tuning instability. Professional players often maintain two concert harps—one for solo work and one for orchestral duty—to accommodate repertoire demands and climate variations.
