A solid-body electric guitar with three single-coil pickups and a tremolo bridge. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
6 top-level lines · 41 rows shown · 133 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Body Assembly 6 parts | electric-guitar-body | 1× | 1 | 8 | assembly |
| 1.1 | Body Wood Blank | electric-guitar-body-blank | 1× | 1 | — | part |
| 1.2 | Finish Lacquer | electric-guitar-finish | 1× | 1 | — | part |
| 1.3 | Pickguard | electric-guitar-pickguard | 1× | 1 | — | part |
| 1.4 | Cavity Cover Plate | electric-guitar-cavity-cover | 2× | 2 | — | part |
| 1.5 | Strap Button | electric-guitar-strap-button | 2× | 2 | — | part |
| 1.6 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Neck Assembly 9 parts | electric-guitar-neck | 1× | 1 | 61 | assembly |
| 2.1 | Neck Wood Blank | electric-guitar-neck-blank | 1× | 1 | — | part |
| 2.2 | Fretboard | electric-guitar-fretboard | 1× | 1 | — | part |
| 2.3 | Fret Wire | electric-guitar-fret | 22× | 22 | — | part |
| 2.4 | Truss Rod | electric-guitar-truss-rod | 1× | 1 | — | part |
| 2.5 | Nut | electric-guitar-nut | 1× | 1 | — | part |
| 2.6 | Position Marker Inlay | electric-guitar-position-marker | 7× | 7 | — | part |
| 2.7 | Headstock Assembly 2 parts | electric-guitar-headstock | 1× | 1 | 26 | assembly |
| 2.7.1 | Tuning Machine 4 parts + deeper › | electric-guitar-tuner | 6× | 6 | 4 | assembly |
| 2.7.2 | String Tree | electric-guitar-string-tree | 2× | 2 | — | part |
| 2.8 | Neck Plate | electric-guitar-neck-plate | 1× | 1 | — | part |
| 2.9 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 3 | Bridge Assembly 5 parts | electric-guitar-bridge | 1× | 1 | 19 | assembly |
| 3.1 | Tremolo Baseplate | electric-guitar-bridge-plate | 1× | 1 | — | part |
| 3.2 | Bridge Saddle | electric-guitar-saddle | 6× | 6 | — | part |
| 3.3 | Tremolo Block | electric-guitar-tremolo-block | 1× | 1 | — | part |
| 3.4 | Coil Spring | coil-spring | 5× | 5 | — | part |
| 3.5 | Intonation Screw | electric-guitar-intonation-screw | 6× | 6 | — | part |
| 4 | Single-Coil Pickup 5 parts | electric-guitar-pickup | 3× | 3 | 10 | assembly |
| 4.1 | Neodymium Magnet | neodymium-magnet | 6× | 18 | — | part |
| 4.2 | Copper Coil Winding | electric-guitar-coil-wind | 1× | 3 | — | part |
| 4.3 | Pickup Bobbin | electric-guitar-bobbin | 1× | 3 | — | part |
| 4.4 | Pickup Baseplate | electric-guitar-pickup-baseplate | 1× | 3 | — | part |
| 4.5 | Pickup Cover | electric-guitar-pickup-cover | 1× | 3 | — | part |
| 5 | Electronics Harness 7 parts | electric-guitar-electronics | 1× | 1 | 9 | assembly |
| 5.1 | Potentiometer | electric-guitar-potentiometer | 2× | 2 | — | part |
| 5.2 | Control Knob | electric-guitar-knob | 2× | 2 | — | part |
| 5.3 | Tone Capacitor | electric-guitar-capacitor | 1× | 1 | — | part |
| 5.4 | 5-Way Selector Switch | electric-guitar-selector-switch | 1× | 1 | — | part |
| 5.5 | Output Jack | electric-guitar-output-jack | 1× | 1 | — | part |
| 5.6 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 5.7 | Cavity Shielding | electric-guitar-shielding | 1× | 1 | — | part |
| 6 | String Set 1 parts | electric-guitar-string-set | 1× | 1 | 6 | assembly |
| 6.1 | Guitar String | electric-guitar-string | 6× | 6 | — | part |
