Overview

A greenhouse CO2 generator is a stationary combustion-based system that produces carbon dioxide gas by burning propane or natural gas. The process yields CO2 as a byproduct of complete fuel oxidation (C3H8 + O2 → CO2 + H2O + heat). In horticulture, this CO2-enriched exhaust is piped directly into the growing environment, typically boosting ambient CO2 from 400 ppm (outdoor air) to 1000–1500 ppm during daylight hours. Plants absorb CO2 during photosynthesis; elevated concentrations accelerate carbon fixation, shortening crop cycles by 15–30% and increasing yields by 20–40% depending on light and nutrient availability.

Combustion generators are the most cost-effective large-scale CO2 source for commercial greenhouses (vs. bottled CO2 or fermentation), delivering both heat and CO2 simultaneously—a dual-benefit efficiency in temperate climates.

How It Works

The system operates on a daily cycle tied to light availability. When the Light Sensor detects sufficient photosynthetically active radiation (typically >200 µmol/m²/s at canopy), the Controller Unit begins comparing the measured CO2 Sensor reading against the programmed setpoint (e.g., 1200 ppm).

If CO2 concentration is below setpoint, the controller energizes the Fuel Solenoid Valve, opening the fuel line from the propane tank or natural gas mains. The Fuel Pressure Regulator maintains safe burner inlet pressure (0.5–1 bar). Simultaneously, the Ignition Electrode fires a high-voltage spark across a 3–4 mm gap, igniting the fuel at the Burner Head. The refractory combustion chamber reaches 900–1200°C; flue gas—mostly CO2, N2, H2O, and trace NOx—exits at 150–250°C.

If a scrubber is installed, the hot exhaust passes through the Heat Exchanger Core. Water circulated by the Coolant Circulation Pump cools the flue gas from 200°C to ~60°C, condensing most water vapor. The cooled, drier gas then feeds the Distribution Manifold, where the Metering Valve proportionally restricts flow. The metering valve allows fine tuning: a given solenoid pulse width maps to a precise CO2 injection rate (mL/min), preventing overshoot and wasting fuel.

Downstream of the metering valve, the Back-Pressure Regulator maintains 5–10 kPa line pressure, ensuring steady diffusion. The CO2-enriched gas then travels through the Main Supply Line (insulated copper or stainless tube) and branches into four Distribution Tube segments. Each terminates at a Diffuser Nozzle—a perforated bar or venturi—dispersing CO2 evenly across the growing zone.

The Flame Sensor continuously monitors the pilot or main flame. If combustion extinguishes (fuel leak, air blockage, or ignition failure), the flame signal drops and the sensor immediately signals the controller to de-energize the Fuel Solenoid Valve. This shutoff occurs in <100 ms, preventing unburned fuel escape.

Simultaneously, the Oxygen Monitor (if present) detects if oxygen depletion occurs in the greenhouse. If O2 falls below 19% (dangerous for workers), the control logic disables CO2 dosing and alarms, forcing ventilation. When the Light Sensor detects dusk (light <100 µmol/m²/s), the controller halts burner operation regardless of CO2 setpoint, conserving fuel.

Heat Recovery and Energy Balance

The Burner Unit liberates 10–50 kW of thermal energy. In winter, this heat is captured via the Heat Exchanger Core and distributed through the cooling circuit, warming the growing zone to 20–25°C. In summer, when ambient temperature exceeds desired growing conditions, the Thermostat Mixing Valve bypasses hot coolant, and excess heat is ventilated outside.

This simultaneous delivery of heat and CO2 avoids the energy waste of independent heaters and CO2 bottling systems.

Safety Interlocks and Compliance

Flame Detection: The Flame Sensor uses ultraviolet flicker detection, responding to burner spectral signature. Loss of flame immediately shuts the Fuel Solenoid Valve, halting fuel supply.

Pressure Relief: A Pressure Relief Valve valve set to 10 kPa ruptures if piping backs up, preventing over-pressurization and damage.

Oxygen Monitoring: The Oxygen Monitor triggers an automatic shutoff and audible alarm if greenhouse O2 drops below 19.5%. This protects workers in enclosed spaces.

Emergency Stop: A manual Emergency Stop Button button (24V latching relay) allows immediate burner kill for maintenance or emergency.

Modern combustion generators comply with European EN 12098-5 and North American CSA B140 standards, requiring annual inspection by certified technicians.

Operational Tuning and Setpoints

CO2 Setpoint: Typically 1000–1500 ppm during daylight, 0 ppm at night (burner off). Leafy greens respond well to 1200 ppm; fruiting plants prefer 1000 ppm (higher CO2 inhibits fruit set in some species).

Photoperiod Gating: Systems only inject CO2 when light exceeds 200 µmol/m²/s; below this, photosynthesis is light-limited, and CO2 enrichment is wasted.

Proportional Control: Rather than on/off (burner at 0% or 100%), proportional metering allows fine gradations: solenoid pulse-width modulation or continuous proportional valve opening maintains CO2 within ±100 ppm of setpoint, minimizing fuel waste.

Maintenance and Troubleshooting

Monthly: Visually inspect the Burner Head for soot buildup; if heavy, clean with a soft brush.

Quarterly: Recalibrate the CO2 Sensor using zero air (CO2-free nitrogen) and span gas (known ppm standard).

Annually: Professional inspection of the Fuel Pressure Regulator, Flame Sensor, and Heat Exchanger Core for corrosion or blockage; replace any water-logged Cooling Reservoir coolant.

Common faults: fouled Ignition Electrode (won't spark), blocked Diffuser Nozzle (uneven CO2), and sensor drift (setpoint no longer accurate). Each is diagnosable with a multimeter and visual inspection.

Comparison to Alternatives

Bottled CO2: High purity but expensive (~5–10× fuel cost). Suitable for research rooms <100 m².

Fermentation or dry ice sublimation: Laboratory scale; impractical for continuous supply.

Integrated hydroponic systems with CO2 injection: Closed-loop systems (e.g., NFT or deep-water culture) can employ propane burners if insulated. Aquaponics systems generate CO2 from fish metabolism but rarely achieve sufficient concentrations without supplementation.

Combustion generators remain the industry standard for commercial greenhouse CO2 enrichment because of simplicity, efficiency, and dual heat-CO2 delivery.

Build & assembly graph

expand / collapse · shared sub-assemblies converge · links to related products · est. labour
product / assembly shared across products atomic part related product

Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.

Bill of materials

6 top-level lines · 30 rows shown · 34 parts total · indented to 3 levels
# Item / sub-assembly Part no. Qty/assy Ext. qty Parts Type
1 Burner Unit 4 parts greenhouse-co2-generator-burner-unit 1 4 assembly
1.1 Burner Head greenhouse-co2-generator-burner-head 1 part
1.2 Fuel Pressure Regulator greenhouse-co2-generator-fuel-regulator 1 part
1.3 Fuel Solenoid Valve greenhouse-co2-generator-fuel-solenoid 1 part
1.4 Ignition Electrode greenhouse-co2-generator-ignition-electrode 1 part
2 CO2 Scrubber and Heat Exchanger 4 parts greenhouse-co2-generator-co2-scrubber 1 4 assembly
2.1 Heat Exchanger Core greenhouse-co2-generator-heat-exchanger-core 1 part
2.2 Coolant Circulation Pump greenhouse-co2-generator-water-circulation-pump 1 part
2.3 Cooling Reservoir greenhouse-co2-generator-cooling-reservoir 1 part
2.4 Thermostat Mixing Valve greenhouse-co2-generator-thermostat-valve 1 part
3 Distribution Manifold 4 parts greenhouse-co2-generator-distribution-manifold 1 4 assembly
3.1 Manifold Body greenhouse-co2-generator-manifold-body 1 part
3.2 Metering Valve greenhouse-co2-generator-metering-valve 1 part
3.3 Flow Indicator greenhouse-co2-generator-flow-indicator 1 part
3.4 Back-Pressure Regulator greenhouse-co2-generator-backpressure-regulator 1 part
4 Control System 4 parts greenhouse-co2-generator-control-system 1 4 assembly
4.1 Controller Unit greenhouse-co2-generator-controller-unit 1 part
4.2 CO2 Sensor greenhouse-co2-generator-co2-sensor 1 part
4.3 Light Sensor greenhouse-co2-generator-light-sensor 1 part
4.4 Relay Board greenhouse-co2-generator-relay-board 1 part
5 Piping Network 4 parts greenhouse-co2-generator-piping-network 1 14 assembly
5.1 Main Supply Line greenhouse-co2-generator-main-supply-line 1 part
5.2 Distribution Tube greenhouse-co2-generator-distribution-tube 4 part
5.3 Diffuser Nozzle greenhouse-co2-generator-diffuser-nozzle 4 part
5.4 Isolation Valve greenhouse-co2-generator-isolation-valve 5 part
6 Safety Interlocks 4 parts greenhouse-co2-generator-safety-interlocks 1 4 assembly
6.1 Flame Sensor greenhouse-co2-generator-flame-sensor 1 part
6.2 Pressure Relief Valve greenhouse-co2-generator-pressure-relief 1 part
6.3 Oxygen Monitor greenhouse-co2-generator-oxygen-monitor 1 part
6.4 Emergency Stop Button greenhouse-co2-generator-emergency-stop 1 part
