A large octocopter UAV for precision aerial crop spraying. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
10 top-level lines · 85 rows shown · 751 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Composite Airframe 3 parts | drone-sprayer-airframe | 1× | 1 | 24 | assembly |
| 1.1 | Central Body 1 parts | drone-sprayer-central-body | 1× | 1 | 2 | assembly |
| 1.1.1 | Body Shell | drone-sprayer-body-shell | 2× | 2 | — | part |
| 1.2 | Foldable Arm 2 parts | drone-sprayer-foldable-arm | 8× | 8 | 2 | assembly |
| 1.2.1 | Arm Tube | drone-sprayer-arm-tube | 1× | 8 | — | part |
| 1.2.2 | Arm Hinge | drone-sprayer-arm-hinge | 1× | 8 | — | part |
| 1.3 | Landing Gear 2 parts | drone-sprayer-landing-gear | 1× | 1 | 6 | assembly |
| 1.3.1 | Landing Skid | drone-sprayer-skid | 2× | 2 | — | part |
| 1.3.2 | Gear Strut | drone-sprayer-gear-strut | 4× | 4 | — | part |
| 2 | Propulsion Unit 4 parts | drone-sprayer-propulsion | 8× | 8 | 63 | assembly |
| 2.1 | Large BLDC Motor 4 parts | drone-sprayer-bldc-motor | 1× | 8 | 52 | assembly |
| 2.1.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 8 | 3 | assembly |
| 2.1.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 8 | 19 | assembly |
| 2.1.3 | Neodymium Magnet | neodymium-magnet | 28× | 224 | — | part |
| 2.1.4 | Ball Bearing | ball-bearing | 2× | 16 | — | part |
| 2.2 | ESC 4 parts | esc | 1× | 8 | 9 | assembly |
| 2.2.1 | Bare PCB | pcb-bare | 1× | 8 | — | part |
| 2.2.2 | Power MOSFET | mosfet | 6× | 48 | — | part |
| 2.2.3 | Gate Driver IC | gate-driver-ic | 1× | 8 | — | part |
| 2.2.4 | Microcontroller | mcu | 1× | 8 | — | part |
| 2.3 | Propeller | propeller | 1× | 8 | — | part |
| 2.4 | Motor Mount | drone-sprayer-motor-mount | 1× | 8 | — | part |
| 3 | Flight Controller 3 parts | drone-sprayer-flight-controller | 1× | 1 | 13 | assembly |
| 3.1 | Flight Controller PCBA 7 parts | drone-sprayer-fc-pcba | 1× | 1 | 10 | assembly |
| 3.1.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 3.1.2 | Compute SoC Module | soc-module | 1× | 1 | — | part |
| 3.1.3 | Microcontroller | mcu | 1× | 1 | — | part |
| 3.1.4 | IMU (6-axis) | imu | 1× | 1 | — | part |
| 3.1.5 | Barometer | barometer | 1× | 1 | — | part |
| 3.1.6 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 3.1.7 | Connector | connector | 4× | 4 | — | part |
| 3.2 | GPS Module | gps-module | 1× | 1 | — | part |
| 3.3 | RTK GPS Module 2 parts | drone-sprayer-rtk-module | 1× | 1 | 2 | assembly |
| 3.3.1 | GPS Module | gps-module | 1× | 1 | — | part |
| 3.3.2 | GNSS Antenna | drone-sprayer-gnss-antenna | 1× | 1 | — | part |
| 4 | Obstacle Sensing System 2 parts | drone-sprayer-obstacle-sensing | 1× | 1 | 7 | assembly |
| 4.1 | Terrain-Following Radar 4 parts | drone-sprayer-terrain-radar | 1× | 1 | 4 | assembly |
| 4.1.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 4.1.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 4.1.3 | Radar Antenna | drone-sprayer-radar-antenna | 1× | 1 | — | part |
| 4.1.4 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 4.2 | Camera Module 3 parts | camera-module | 1× | 1 | 3 | assembly |
| 4.2.1 | CMOS Image Sensor | image-sensor | 1× | 1 | — | part |
| 4.2.2 | Lens Assembly | camera-lens | 1× | 1 | — | part |
| 4.2.3 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 5 | Spraying System 5 parts | drone-sprayer-spray-system | 1× | 1 | 159 | assembly |
| 5.1 | Chemical Tank | drone-sprayer-chem-tank | 1× | 1 | — | part |
| 5.2 | Diaphragm Pump 3 parts | drone-sprayer-pump | 2× | 2 | 26 | assembly |
| 5.2.1 | Pump Head | drone-sprayer-pump-head | 1× | 2 | — | part |
| 5.2.2 | Pump Motor 3 parts + deeper › | drone-sprayer-pump-motor | 1× | 2 | 24 | assembly |
| 5.2.3 | Pressure Sensor | drone-sprayer-pressure-sensor | 1× | 2 | — | part |
| 5.3 | Atomizing Nozzle 2 parts | drone-sprayer-nozzle | 4× | 4 | 25 | assembly |
| 5.3.1 | Atomizing Disc | drone-sprayer-atomizing-disc | 1× | 4 | — | part |
| 5.3.2 | Nozzle Motor 3 parts + deeper › | drone-sprayer-nozzle-motor | 1× | 4 | 24 | assembly |
| 5.4 | Flow Meter | drone-sprayer-flow-meter | 1× | 1 | — | part |
| 5.5 | Plumbing Harness 2 parts | drone-sprayer-plumbing | 1× | 1 | 5 | assembly |
| 5.5.1 | Spray Hose | drone-sprayer-hose | 4× | 4 | — | part |
| 5.5.2 | Spray Manifold | drone-sprayer-manifold | 1× | 1 | — | part |
| 6 | Smart Battery Pack 4 parts | drone-sprayer-battery-pack | 1× | 1 | 15 | assembly |
| 6.1 | LiPo Cell | lipo-cell | 12× | 12 | — | part |
| 6.2 | BMS Board | bms-board | 1× | 1 | — | part |
| 6.3 | Battery Housing | drone-sprayer-battery-housing | 1× | 1 | — | part |
| 6.4 | XT60 Connector | xt60-connector | 1× | 1 | — | part |
| 7 | Power Distribution Board 4 parts | drone-sprayer-power-dist-board | 1× | 1 | 5 | assembly |
| 7.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 7.2 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 7.3 | XT60 Connector | xt60-connector | 2× | 2 | — | part |
| 7.4 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 8 | Telemetry Datalink 4 parts | drone-sprayer-radio-module | 1× | 1 | 5 | assembly |
| 8.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 8.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 8.3 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 8.4 | Datalink Antenna | drone-sprayer-antenna | 2× | 2 | — | part |
| 9 | Remote Controller 4 parts | drone-sprayer-remote-controller | 1× | 1 | 11 | assembly |
| 9.1 | Controller PCBA 4 parts | drone-sprayer-rc-pcba | 1× | 1 | 5 | assembly |
| 9.1.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 9.1.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 9.1.3 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 9.1.4 | Connector | connector | 2× | 2 | — | part |
| 9.2 | Control Stick | drone-sprayer-control-stick | 2× | 2 | — | part |
| 9.3 | LCD Display | drone-sprayer-rc-lcd | 1× | 1 | — | part |
| 9.4 | Controller Battery 2 parts | drone-sprayer-rc-battery | 1× | 1 | 3 | assembly |
| 9.4.1 | LiPo Cell | lipo-cell | 2× | 2 | — | part |
| 9.4.2 | BMS Board | bms-board | 1× | 1 | — | part |
| 10 | Fastener Set | fastener-set | 8× | 8 | — | part |
