Outdoor Litter Vacuum Product

Overview

An outdoor litter vacuum is the powered replacement for a worker with a grabber stick and sack. Pushed at walking pace across plazas, parks, stadium concourses, and parking lots, it inhales cans, bottles, cups, leaves, cigarette ends, and broken glass through a wide floor nozzle and packs them into a large onboard bag. Municipal and facility crews use them because one operator with a machine clears litter several times faster than hand picking, and the machine collects fine debris — glass shards, cigarette butts, bottle caps — that hand picking misses entirely.

Earlier machines used small petrol engines; current models are predominantly battery-electric, which suits the stop-start duty cycle, removes exhaust from pedestrian areas, and brings noise down to a level acceptable near housing and hospitals in the early morning.

How it works

Suction comes from the Suction Impeller Unit. Unlike a household vacuum, where debris is filtered out before the fan, here everything passes directly through the Serrated Steel Impeller — a hardened steel paddle wheel with serrated blades. This is deliberate: the serrations chop bulky items such as drink cans, PET bottles, and cartons into fragments, so the load packs into the bag at several times the density loose litter would achieve. The Volute Housing is protected by a Replaceable Wear Liner, a sacrificial panel that takes the sandblasting from grit and glass and is replaced rather than the housing. Jams are cleared through the bolted Inlet Plate.

The impeller is driven directly by the BLDC Fan Motor, a brushless DC machine of 1–1.5 kW. The Motor Controller commutates it through a six-Power MOSFET bridge using Hall Sensor feedback, soft-starts the heavy steel wheel, and trips on overcurrent if a jam stalls it — the most common fault event in service. Energy comes from the Battery Pack, a removable 36 V pack of roughly one hundred Li-ion Cell, 18650 cells in a 10S10P arrangement managed by a BMS Board. A pack of about 1 kWh gives two to four hours of work depending on the Suction Speed Dial setting; fleets carry a spare pack to cover a full shift.

Collection and filtration

Shredded debris discharges into the Collection Bag Assembly. The Mesh Collection Bag itself is the filter: air exits through the polyester weave while solids stay behind, so there is no separate filter element to clog. A Discharge Dust Skirt at the bag mouth keeps fine dust from puffing back toward the operator, and the Bag Support Frame carries the load — a full bag of compacted litter can weigh 30–40 kg. Emptying takes under a minute: unclip the Bag Latch pair, lift the bag off its frame, and unzip it over a dumpster.

Nozzle and terrain

The Intake Nozzle spans about 700 mm ahead of the front casters. Pickup quality depends on the gap between nozzle lip and ground, so the Nozzle Height Adjuster lets the operator crank clearance from roughly 10 mm on smooth pavement up to 50 mm over grass and gravel, where a low setting would plough. Front and rear Nozzle Rubber Flap strips concentrate the airflow at surface level while flexing to admit bulky items. For drains, planters, benches, and bins, the Hose & Wand Kit diverts the full airstream into a 125 mm Suction Hose and hand wand via the Diverter Coupler.

Operation

The operator turns the key on the Control Pod, holds the Dead-Man Bail Lever against the grip, and pushes. The bail is a dead-man control: releasing it cuts the motor, so the impeller is never spinning while the operator's hands are off the machine — important given that the fan will ingest and shred anything reaching the nozzle. The four-wheel Chassis & Wheels uses pneumatic rear wheels and swivel front casters for kerb-hopping and tight turns; heavier models add a traction drive on the rear Rear Axle. Typical area coverage is 3,000–6,000 m² per hour, an order of magnitude beyond manual picking.
