Horizontal Resaw Product

Overview

A lumber resaw is a horizontal band saw machine that divides boards into narrower strips or thinner pieces. It is typically placed downstream of a [[lumber-resaw|headrig]] and [[lumber-resaw|edger]] in a sawmill sequence, splitting dimensional lumber (e.g., 1×10s or 2×10s) into standard widths (e.g., 1×4s, 1×6s) or converting thick stock into thinner boards. The resaw is often the workhorse of a custom mill because it converts log-to-lumber conversion into final product dimensions.

The core is the Blade Assembly—a continuous steel Saw Blade (1.5–2.5 inches wide) running between two crowned Blade Wheels at 4,000–7,000 feet per minute. A Powered Infeed with powered Feed Rollers advances the board through the blade at a preset feed rate (60–200 ft/min). A Rip Fence sets the distance from the blade, and the Control Panel governs blade speed and infeed speed. Sawdust is removed by the Chip Conveyor.

How it works

The Main Motor (10–20 horsepower) drives the upper Blade Wheel via a Drive Belt. The blade runs continuously at a speed set by the Control Panel. A board is placed on the Feed Rollers, which grip it and push it under the blade at a constant feed rate. The blade cuts the board into two pieces along the path parallel to the Rip Fence.

The operator adjusts the Rip Fence to set the cut position (read from the Fence Scale). For example, to rip a 1×10 board into two 1×5s, the fence is set 5 inches from the blade. The Feed Motor, a variable-speed Main Motor or a separate [[lumber-resaw-feed-motor|hydraulic drive]], is ramped up slowly to avoid blade stall. Once the board is clear of the blade, the Chip Conveyor (powered by a Screw Motor) removes the resulting kerf of sawdust.

Many modern resaws use a [[lumber-resaw-vsd|variable-frequency drive]] on the Main Motor so that blade speed can be adjusted on the fly—slower speeds (4,000 ft/min) for thick or dense wood, faster speeds (7,000 ft/min) for thin or soft wood. This reduces blade deflection and produces straighter cuts.

Blade design and performance

The Saw Blade is a continuous steel band (typically 1.5 to 2.5 inches wide, 12 to 15 feet long) with rip teeth (large, evenly spaced teeth for following the grain with minimal deflection). Blade thickness is typically 0.035–0.050 inches. The two Blade Wheels are crowned—slightly domed—to keep the blade centered and in tracking.

Blade performance depends on sharpness and speed. A sharp blade cuts freely and requires moderate feed force; a dull blade forces the motor to work hard, heats the Saw Blade, and produces a rough cut. Modern mills re-sharpen blades every 40–80 hours of cutting. The Blade Guides (carbide-backed blocks on top and bottom of the blade) prevent blade deflection but allow the blade to oscillate slightly, reducing friction and heat. If guides wear, the blade can wander and produce tapered or curved cuts.

Blade tension, set by the Tension Spring, must be correct: too loose and the blade wanders; too tight and the Wheel Bearings on the wheels wear prematurely. A well-maintained resaw holds cut width to within ±1/16 inch over a full board length.

Infeed and speed control

The Powered Infeed uses two Feed Rollers (top and bottom) driven by a Feed Motor through a Feed Reducer. The rollers grip the board and pull it toward the blade at a constant speed set by the operator or a [[mcu|control system]]. Typical feed rates are 60–120 ft/min for rough-sawn softwood, up to 200 ft/min for thin or dried stock.

If the Feed Rollers are too slow, the Main Motor idles and the blade dulls quickly from lack of chip load. If they are too fast, the Main Motor stalls, the blade heats and can snap, and the cut wanders. Optimal feed rate balances blade speed, wood species, and board thickness; a PLC-based system may adjust feed in real time based on motor current draw.

Some resaws integrate a {{encoder}} on the Feed Roller shaft, allowing the Control Panel to measure feed speed directly and correct for Feed Roller slippage.

Rip fence and accuracy

The Rip Fence is a critical accuracy component. It must be parallel to the blade and held rigidly against thrust forces. Precision resaws use hardened Rip Fences with a Fence Scale calibrated to 1/16 inch graduations. Some mills add micrometers or digital Fence Scales for repeatable ripping.

The Blade Splitter, positioned immediately behind the blade, prevents the kerf from closing up (which would bind the blade) and reduces kickback risk. A sharp Blade Splitter reduces friction and heat.

Chip removal

The Chip Conveyor (typically an [[lumber-resaw-conveyor-screw|auger screw]]) rotates continuously, moving sawdust and small chips away from the blade and into the Discharge Hopper. Without efficient chip removal, sawdust accumulates under the board, creating friction and a fire hazard. High-throughput mills integrate the resaw chip stream into a central [[lumber-resaw|dust collection system]].

Integration and flexibility

A resaw is one of the most flexible machines in a mill because it can rip in any direction (with respect to grain or growth ring). Millers use resaws to:

• Split cants into dimensional lumber (1×4, 2×4, etc.)
• Resaw thick boards into thinner products
• Salvage waney-edge material by removing defects
• Upgrade appearance-grade lumber by removing surface defects

This flexibility makes resaws valuable for custom or value-added work. A typical small mill might operate a single resaw that handles 2,000–5,000 board feet per hour, while a high-output mill may have multiple resaws working in parallel, coordinated with upstream and downstream equipment.
