Overview

A mast climbing work platform (MCWP) puts a long, heavily loaded work deck anywhere on a building facade: the deck rides a lattice mast on a rack-and-pinion drive, the mast stands on a ballasted chassis at ground level, and tie frames anchor it to the structure as it grows. Against the alternatives it occupies a specific niche — far more material capacity than a suspended cradle (tonnes rather than a few hundred kilograms), far less erection labour than scaffolding for tall uniform facades. Bricklaying is the classic application, because the deck can hold a full day's masonry and keep the working course at waist height all day; recladding, render, and glazing crews use the same machines.

A single-mast unit carries a deck of 10–15 m; two masts bridged by one deck stretch past 30 m. Heights reach 100 m and more when tied, while freestanding operation on ballast alone is limited to roughly 10–30 m depending on model and wind exposure. EN 16719 governs the type in Europe, ANSI A92.9 in North America.

Climbing drive

The mast is a stack of Mast Section units — galvanized lattice, about 1.5 m tall — each carrying a Mast Rack segment up one chord, aligned across joints to sub-millimetre accuracy so pinions never strike a step. The Carriage Frame wraps the mast on eight eccentric-adjustable Guide Roller units and climbs with two or three Drive Gearmotor gearmotors, each turning a case-hardened Drive Pinion held at correct mesh depth by a Backup Roller.

Redundancy is multiplicative. Each motor carries its own spring-applied Motor Brake, sized so any single brake holds the rated load alone. Below all of that sits the Safety Brake, an independent centrifugal device on its own pinion: if the platform ever descends faster than about 0.7 m/s — which requires every motor brake to have failed simultaneously — it wedges and arrests the deck mechanically. The same device family protects rack-and-pinion construction hoists, and like them it is drop-tested on a schedule.

Travel speed is 6–12 m/min, slow enough that the Drive Cabinet needs only VFD soft ramps, with Limit Cam Switch switches on the mast tripping slow-down and final stop at both ends and a Landing Buffer pair at the base catching any overrun.

Deck and loading

The Deck Module bays pin end to end outward from the carriage; allowable load falls as cantilever grows, and the load chart on the Control Station is configuration specific. Extension Deck sections telescope up to 1.8 m toward the facade, closing the gap over recesses so crews never bridge with planks. Guardrail Frame frames with toe boards enclose every open edge, and Load Cell sensing in the carriage blocks upward travel above 110 percent of rated load — overloading an MCWP is the historically dominant accident cause, so the interlock is mandatory under EN 16719.

Base, ballast, and ties

Everything reacts through the Chassis Frame, levelled to within half a degree of plumb on four Outrigger Jack screw jacks over Sole Plate pads. Stacked Ballast Block counterweights stabilize freestanding configurations; beyond freestanding height, Tie Frame collars clamp the mast every 6–10 m and triangulate through Tie Tube struts to Wall Bracket fixings, every Anchor Bolt pull-tested on site before the mast climbs past its level. A Tilt Sensor watches mast plumb continuously, catching ground settlement or a disturbed tie, and the Anemometer enforces the 12.7 m/s in-service wind limit.

Erection and operation

MCWPs are self-erecting: the platform carries a stack of mast sections, rises to the mast top in an interlocked erection mode, and the crew hoists each new section onto the stack, torques the Section Bolts, and continues — a two-person team can add 20–30 m of mast in a shift, which is the core economic advantage over scaffolding. Power arrives through the Trailing Cable managed by a Cable Reel; on power failure the crew descends by manually venting the motor brakes in a controlled procedure. Between sites the machine folds onto its own Axle Set as a road trailer or breaks into truck-loadable modules.
