Mobile Light Tower Product

Overview

A mobile light tower is the standard way to light a place that has no grid power: road works, mine benches, festival car parks, disaster scenes, airfield aprons during overnight construction. The machine is a single towable package, a diesel generator on a trailer with a telescoping mast that lifts a bar of floodlights to 7–9 metres. One unit with four LED fixtures lights roughly 30,000–40,000 m² to the 4–5 lux needed for general site work, and a tank of diesel keeps it running unattended for several nights.

The shift from 4 × 1,000 W metal-halide lamps to 4 × 300 W LEDs around the mid-2010s changed the machine's economics more than its appearance. Electrical load fell by two thirds, so the same Fuel Tank now runs 60–100 hours instead of 25–30, the lamps strike instantly instead of needing a 15-minute warm-up and cool-down, and a dropped fixture no longer means a broken arc tube.

How it works

Light starts at the Diesel Generator Set. A small industrial diesel, the Diesel Engine, spins at a governed 1,500 rpm (1,800 rpm in 60 Hz markets) and direct-drives the Alternator, a brushless synchronous machine built from a Stator Assembly and Rotor Assembly that holds 230 V within a few percent across the load range. The set is deliberately oversized: four LED floodlights draw only 1.2–1.4 kW, so the 6–8 kVA alternator leaves capacity for the auxiliary outlets on the Breaker Panel, which crews use for drills and battery chargers. The engine breathes through a heavy-duty Engine Air Filter, rejects heat through a Radiator, and exhausts through a Exhaust Muffler sized to keep the whole unit at 60–65 dB(A) at 7 metres, quiet enough for night work near houses.

The Telescoping Mast is a stack of five nested Mast Section tubes. A single Lift Wire Rope reeved over Mast Pulley Sheave sheaves at each section head extends all stages together as the Mast Winch turns; the geometry means one metre of cable at the drum produces several metres of mast travel. The Automatic Load Brake is the critical safety component, a ratchet-and-friction automatic brake that holds the mast at any height and prevents free-fall if the operator lets go of the Winch Crank Handle. At full height the mast rotates about 340° on its base and locks with the Mast Rotation Lock, so the operator aims the entire light bar from the ground.

Each LED Floodlight Fixture is an IP65 fixture: a LED Engine Board running near 140 lm/W inside a finned die-cast Floodlight Housing, behind a tempered Floodlight Lens, fed by a potted LED Driver. Individual Aiming Yoke brackets let each head be tilted before raising, typically two aimed near, two far, overlapping into an even pool.

Deployment and control

Setup is a fixed ritual because a 9-metre mast on a 1-tonne trailer is a sail. The unit is towed in on its Tow Coupler, positioned, and the four Outrigger Jack legs are swung out and screwed down until the Trailer Frame is level on the bubble gauge; the Wheel Assembly pair should carry little weight. Only then is the mast raised. Properly outrigged, the raised mast is rated for winds around 90 km/h; the operating manual requires lowering it above that or when the unit is left for storms.

Running is mostly automatic. The Controller PCB sequences glow-plug preheat, cranks the Starter Motor from the 12 V Battery, and switches the light circuits through its relays once the alternator stabilises; it also shuts the engine down on low oil pressure or high coolant temperature. With the Photocell Sensor enabled, the whole cycle keys off ambient light, start at dusk, stop at dawn, so a row of towers along a highway job runs for a week with no human input beyond refuelling. The Run Timer covers fixed-schedule jobs, and fleet units add telematics that report fuel level and run hours to the rental company.

Service

Daily checks through the Canopy Service Door cover oil, coolant, and the Fuel Filter / Water Separator water bowl, since site-delivered diesel is routinely contaminated. The Lift Wire Rope is inspected for broken strands at each setup and replaced on condition, and the winch must always retain dead wraps on the Winch Drum. Engine service follows ordinary diesel intervals of 250–500 hours. The LED heads themselves are effectively maintenance-free over the 30,000–50,000 hour fixture life, which for a rental machine usually means the lights outlast the trailer.
