Night Vision Goggle Product
A Gen-3 image-intensifier night vision monocular: an objective lens gathers faint light onto a photocathode, an intensifier tube amplifies it, and an eyepiece presents the green phosphor image, all in a sealed nitrogen-purged housing on a helmet mount. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
12 top-level lines · 38 rows shown · 35 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Housing 4 parts | night-vision-goggle-housing | 1× | 1 | 5 | assembly |
| 1.1 | Body Tube | night-vision-goggle-body-tube | 1× | 1 | — | part |
| 1.2 | Housing Shell & Boot | night-vision-goggle-shells | 2× | 2 | — | part |
| 1.3 | Sacrificial Window | night-vision-goggle-sacrificial-window | 1× | 1 | — | part |
| 1.4 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 2 | Objective Lens Assembly 2 parts | night-vision-goggle-objective | 1× | 1 | 3 | assembly |
| 2.1 | Lens Assembly | camera-lens | 2× | 2 | — | part |
| 2.2 | Objective Barrel & Focus Ring | night-vision-goggle-objective-barrel | 1× | 1 | — | part |
| 3 | Image-Intensifier Tube 4 parts | night-vision-goggle-intensifier-tube | 1× | 1 | 4 | assembly |
| 3.1 | Photocathode | night-vision-goggle-photocathode | 1× | 1 | — | part |
| 3.2 | Microchannel Plate (MCP) | night-vision-goggle-mcp | 1× | 1 | — | part |
| 3.3 | Phosphor Screen & Fiber Inverter | night-vision-goggle-phosphor-screen | 1× | 1 | — | part |
| 3.4 | Tube Housing | night-vision-goggle-tube-housing | 1× | 1 | — | part |
| 4 | High-Voltage Power Supply 3 parts | night-vision-goggle-hv-supply | 1× | 1 | 3 | assembly |
| 4.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 4.2 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 4.3 | HV Step-Up & Gating | night-vision-goggle-step-up | 1× | 1 | — | part |
| 5 | Eyepiece Lens Assembly 2 parts | night-vision-goggle-eyepiece | 1× | 1 | 3 | assembly |
| 5.1 | Lens Assembly | camera-lens | 2× | 2 | — | part |
| 5.2 | Dioptre Ring | night-vision-goggle-diopter-ring | 1× | 1 | — | part |
| 6 | IR Illuminator 2 parts | night-vision-goggle-ir-illuminator | 1× | 1 | 2 | assembly |
| 6.1 | IR Emitter & Lens | night-vision-goggle-ir-emitter | 1× | 1 | — | part |
| 6.2 | IR Switch | night-vision-goggle-ir-switch | 1× | 1 | — | part |
| 7 | Controls 3 parts | night-vision-goggle-controls | 1× | 1 | 3 | assembly |
| 7.1 | Gain Knob, Switch & Buttons | night-vision-goggle-gain-switch | 1× | 1 | — | part |
| 7.2 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 7.3 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 8 | Battery Compartment 3 parts | night-vision-goggle-battery | 1× | 1 | 4 | assembly |
| 8.1 | Li-ion Cell, 18650 | li-cell-18650 | 1× | 1 | — | part |
| 8.2 | Battery Contacts & Cap | night-vision-goggle-battery-contacts | 2× | 2 | — | part |
| 8.3 | Coil Spring | coil-spring | 1× | 1 | — | part |
| 9 | Helmet Mount Bracket 3 parts | night-vision-goggle-mount | 1× | 1 | 4 | assembly |
| 9.1 | J-Arm & Dovetail | night-vision-goggle-j-arm | 1× | 1 | — | part |
| 9.2 | Flip-Up Mount | night-vision-goggle-flip-mount | 1× | 1 | — | part |
| 9.3 | Coil Spring | coil-spring | 2× | 2 | — | part |
| 10 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 11 | Connector | connector | 2× | 2 | — | part |
| 12 | Fastener Set | fastener-set | 1× | 1 | — | part |
Sourcing — likely vendors
Companies that make this · indicative price $100–$8k · MOQ & lead are typical| Vendor | HQ | Specialty | MOQ | Lead time |
|---|---|---|---|---|
| 🇯🇵Canon canon.com ↗ | Tokyo, JP | Imaging & optics | 500 units | 10–16 wks |
| 🇯🇵Nikon nikon.com ↗ | Tokyo, JP | Imaging & optics | 500 units | 10–16 wks |
| 🇩🇪ZEISS zeiss.com ↗ | Oberkochen, DE | Optics & optoelectronics | 500 units | 10–16 wks |
| leica-camera.com ↗ | Wetzlar, DE | Cameras & optics | 500 units | 10–16 wks |
| flir.com ↗ | Wilsonville, US | Thermal imaging | 500 units | 10–16 wks |
