Oxygen Analyzer Product

Overview

An oxygen analyzer measures O₂ concentration in combustion gases, furnaces, or other high-temperature environments where traditional chemical titration is too slow. It employs a Zirconia Thimble, a ceramic material (yttria-stabilized zirconia) that becomes an ionic conductor above 700 °C. When oxygen-bearing gas flows across the cell, oxygen ions migrate through the zirconia crystal between two porous platinum Porous Electrode, creating an electrochemical potential that follows the Nernst equation: EMF = (RT/4F) × ln(P₁O₂/P₂O₂), where P₁ and P₂ are oxygen partial pressures on either side. By comparing the sample-side potential to a reference side (typically air or nitrogen), the electronics compute %O₂. The Heater Control Module maintains the zirconia at its operating temperature via feedback control, the Signal Converter Electronics linearizes the EMF to %O₂, and the Reference Air System provides calibration gases.

How it works

The zirconia cell requires high temperature because ionic conductivity is negligible below 600 °C. The Heater Element heats the cell to 700–900 °C (exact temperature varies by manufacturer and gas composition). At this temperature, oxygen molecules on the high-concentration side of the membrane dissociate into O²⁻ ions, which migrate through the zirconia lattice to the low-concentration side, where they recombine as O₂. This ion flow creates a voltage proportional to the concentration ratio.

The Sample Conditioning Module module draws sample gas through a Sample Probe inserted in the furnace or duct, passes it through a Humidity Trap (water vapor can contaminate the cell), and controls flow to the cell via the Flow Control Valve. The EMF Amplifier buffers the high-impedance cell voltage and drives an ADC in the Linearization CPU.

The cell potential is logarithmic in oxygen concentration; the CPU stores a two-point calibration (zero: pure nitrogen = 0% O₂, span: air or calibration gas = 21% O₂ or other known level). Using these two points, the software linearizes the logarithmic Nernst relationship to %O₂ over the measurement range. The Reference Selector Valve can be commanded by the analyzer to automatically switch between zero and span gases on a user-set calibration schedule (e.g., daily at midnight), or calibration can be manual.

Zirconia analyzers tolerate high-temperature and high-particulate environments that would destroy optical sensors, making them standard in furnace oxygen control, steel-mill process monitoring, and waste-incinerator emissions measurement. Accuracy improves with calibration frequency; the cell EMF slowly drifts due to electrode contamination and zirconia aging, so weekly or daily calibration is typical for precision control applications. Reference gas bottles must be replaced when empty, and the cell itself eventually requires replacement (3–5 year life).
