Paint Thickness Gauge Product
Overview
A paint thickness gauge measures how much paint sits atop a metal substrate, vital for detecting re-sprayed panels in used-car inspection, assessing paint thickness uniformity during automotive detailing, and ensuring proper application during paint-booth work. Modern gauges use eddy-current induction: a small coil in the ceramic probe tip generates a high-frequency magnetic field. The field penetrates the non-magnetic paint and induces eddy currents in the underlying steel. The strength of those eddy currents changes with distance, so by measuring the coil impedance, the gauge infers the gap—and thus the paint thickness. A microcontroller converts the impedance reading into microns or mils on a small LCD.
The Sensor Head is an eddy-current coil wrapped in ceramic, shielded to reject environmental noise. The Measurement Processor is a small microcontroller and analog front-end that excites the coil at 1–5 MHz and measures the return signal. The Display and Controls shows thickness in real time, with push-buttons for calibration and unit switching. A Battery and Power Regulation powers everything for 30–50 hours on four AA cells. The Temperature Compensation thermistor corrects for thermal drift of the coil frequency, a key source of error on a sunny day. A Probe Cable and Connector runs from the probe to the main processor, and the Case and Handle holds everything in a compact hand-held form.
How it works
The eddy-current principle is elegant. A sine-wave oscillator in the processor drives the primary coil at 1–5 MHz. That oscillating magnetic field penetrates the paint and induces circular eddy currents in the conductive steel beneath. Those eddy currents generate their own magnetic field, which opposes the primary field. The net impedance the primary coil sees is thus a function of the paint thickness: the thicker the paint, the farther the steel, the weaker the eddy-current feedback, and the less the coil impedance changes. By measuring the impedance with a transimpedance amplifier and ADC, the MCU linearizes the thickness from zero air to full scale.
A key detail is the two-point calibration. The gauge has a zero-offset mode (probe held in air) and a span mode (probe placed on a calibration shim of known thickness, typically 100 µm aluminum foil). By sampling both extremes, the MCU learns the impedance curve and can then read intermediate thicknesses accurately. This is crucial because coil frequency drifts with temperature, and different alloys and paint types have slightly different conductivity. A thermistor in the probe tip feeds the ambient temperature to the MCU, which adjusts the oscillator frequency slightly to maintain calibration across 0–50 °C.
Interpreting readings
A factory new car with a single-stage enamel typically has 80–120 µm of paint, measured as one thick layer. A clear-coat car (two-stage) has 30–50 µm of base color coat plus 25–40 µm of clear, totaling 60–90 µm, but the gauge cannot distinguish the layers—it measures total thickness. A respray is obvious: if one panel reads 200–300 µm while others read 80 µm, that panel has been painted over, a red flag for collision damage. Primer adds another 20–40 µm, and heavy protective coatings can push readings past 500 µm. Spot readings across the hood, roof, and fenders reveal applying non-uniformity; a variation larger than 20 µm suggests over-spray or pooling. When used during polishing, a pre-polish reading confirms you are removing compound, not clear coat; the reading should drop only 5–10 µm with light buffing and stay stable.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labourTap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
7 top-level lines · 39 rows shown · 88 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Sensor Head 5 parts | ptg-sensor-head | 1× | 1 | 12 | assembly |
| 1.1 | Eddy-Current Coil | ptg-eddy-coil | 1× | 1 | — | part |
| 1.2 | Reference Coil | ptg-reference-coil | 1× | 1 | — | part |
| 1.3 | Ceramic Tip | ptg-ceramic-tip | 1× | 1 | — | part |
| 1.4 | EM Shielding | ptg-shielding | 1× | 1 | — | part |
| 1.5 | SMD Passive (R/C/L) | smd-passives | 8× | 8 | — | part |
| 2 | Measurement Processor 5 parts | ptg-processor | 1× | 1 | 24 | assembly |
| 2.1 | Microcontroller | mcu | 1× | 1 | — | part |
| 2.2 | Oscillator Crystal | ptg-oscillator | 1× | 1 | — | part |
| 2.3 | Transimpedance Amplifier | ptg-transimpedance-amp | 1× | 1 | — | part |
| 2.4 | ADC Front-End | ptg-adc-frontend | 1× | 1 | — | part |
| 2.5 | SMD Passive (R/C/L) | smd-passives | 20× | 20 | — | part |
| 3 | Display and Controls 5 parts | ptg-display | 1× | 1 | 18 | assembly |
| 3.1 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 3.2 | Button Set | ptg-button-pad | 3× | 3 | — | part |
| 3.3 | Display PCB | ptg-display-pcb | 1× | 1 | — | part |
| 3.4 | SMD Passive (R/C/L) | smd-passives | 12× | 12 | — | part |
| 3.5 | Connector | connector | 1× | 1 | — | part |
| 4 | Battery and Power Regulation 5 parts | ptg-battery-pack | 1× | 1 | 15 | assembly |
| 4.1 | Battery Holder | ptg-battery-holder | 1× | 1 | — | part |
| 4.2 | LDO Regulator | ptg-ldo-regulator | 2× | 2 | — | part |
| 4.3 | Reverse Protection | ptg-reverse-protect | 1× | 1 | — | part |
| 4.4 | Power Switch | ptg-power-switch | 1× | 1 | — | part |
| 4.5 | SMD Passive (R/C/L) | smd-passives | 10× | 10 | — | part |
| 5 | Temperature Compensation 3 parts | ptg-temperature-compensation | 1× | 1 | 6 | assembly |
| 5.1 | Thermistor | ptg-thermistor | 1× | 1 | — | part |
| 5.2 | Reference Resistor | ptg-reference-resistor | 1× | 1 | — | part |
| 5.3 | SMD Passive (R/C/L) | smd-passives | 4× | 4 | — | part |
| 6 | Probe Cable and Connector 4 parts | ptg-cable-connector | 1× | 1 | 8 | assembly |
| 6.1 | Shielded Coax | ptg-coax-cable | 4× | 4 | — | part |
| 6.2 | Power Wire | ptg-power-wire | 2× | 2 | — | part |
| 6.3 | Connector Header | ptg-connector-header | 1× | 1 | — | part |
| 6.4 | Strain Relief | ptg-cable-strain-relief | 1× | 1 | — | part |
| 7 | Case and Handle 5 parts | ptg-case-shell | 1× | 1 | 5 | assembly |
| 7.1 | Upper Housing | ptg-upper-housing | 1× | 1 | — | part |
| 7.2 | Lower Housing | ptg-lower-housing | 1× | 1 | — | part |
| 7.3 | Display Window | ptg-display-window | 1× | 1 | — | part |
| 7.4 | Probe Grommet | ptg-probe-grommet | 1× | 1 | — | part |
| 7.5 | Fastener Set | fastener-set | 1× | 1 | — | part |
Sourcing — likely vendors
Companies that make this · indicative price $30–$800 · MOQ & lead are typical| Vendor | HQ | Specialty | MOQ | Lead time |
|---|---|---|---|---|
| stanleyblackanddecker.com ↗ | New Britain, US | Tools (DeWalt, Craftsman) | 500 units | 6–12 wks |
| bosch-professional.com ↗ | Leinfelden, DE | Power tools | 500 units | 6–12 wks |
| ttigroup.com ↗ | Hong Kong, CN | Tools (Milwaukee, Ryobi) | 500 units | 6–12 wks |
| 🇯🇵Makita makita.com ↗ | Anjo, JP | Power tools | 500 units | 6–12 wks |
| 🇨🇭Hilti hilti.com ↗ | Schaan, CH | Construction tools | 500 units | 6–12 wks |
