The post peeler is a stationary or semi-portable machine that removes bark from wooden posts, poles, and logs in a continuous process. It operates on the principle of a rotating Cutter Head equipped with multiple hardened steel Peeling Knife knives that shave bark as the post is advanced through the cutting zone via a powered Feed System. Post peelers are essential in utility pole preparation, fence-post manufacturing, and transmission tower component production.

The machine consists of a diesel-powered hydraulic system driving both the Cutter Motor (rotating the cutter drum) and Feed Motor (advancing the post). The operator sets feed speed via a proportional control valve, balancing cutting quality against processing speed.

How it works

The operator positions a freshly cut post or pole into the Machine Frame machine, centering it in the Post Guide V-groove roller set. The post is gripped by the powered Top Feed Roller and Bottom Guide Roller pair, which advance it at a controllable feed speed (0.5–3 m/min) into the rotating Cutter Head.

The Cutter Head rotates at 250–400 rpm via the Cutter Motor, a bent-axis motor driven by the variable displacement Hydraulic Pump. As the post is fed into the drum, the eight hardened Peeling Knife knives mounted in Knife Holder Block blocks make continuous contact with the bark surface, peeling it in thin shavings. The knives are radially adjustable to accommodate posts of different diameters, and the knife depth is set so that only bark (typically 5–15 mm thick depending on species) is removed, leaving the sapwood intact.

Bark shavings are ejected radially from the drum and typically fall into a collection bin or conveyor beneath the machine. The peeled post exits the opposite side of the cutter head, completely debarked and ready for further processing (pickling, preservation treatment, or direct use).

The diesel Diesel Engine drives the Hydraulic Pump continuously. A Flow Divider proportionally supplies the Cutter Motor and Feed Motor, ensuring synchronized operation. The operator modulates feed speed via a proportional pilot control, adjusting it based on post diameter and bark thickness; larger posts or thicker bark require slower feed rates to prevent knives from chattering.

Cutter Head Design

The Cutter Head is the critical component. The Cutter Drum is a welded steel cylinder 500 mm diameter and 1200 mm wide, providing 1.2 m of active cutting length. It has eight equally spaced knife mounting slots at 45° intervals around the circumference.

Each Knife Holder Block block is a ductile iron socket bolted into a slot. The blocks are radially adjustable via eccentric bushings or shims, allowing the cutting radius to be set for different post diameters (typically 50–350 mm). The eight Peeling Knife are hardened tool-steel blades (100×40 mm) with a straight or slightly curved cutting edge. Each blade is replaceable; they are held in the block via a mechanical wedge or clamp, allowing quick changes without disassembling the drum.

The Cutter Drum is supported on two Drum Bearing heavy-duty cylindrical roller bearings that carry the radial load of the peeling process. A Drum Seal dual-lip oil seal at each bearing housing protects the bearing from bark and wood debris. The drum is driven by the Cutter Motor via a flexible coupling, isolating the motor from vibration.

Feed System

The Feed System consists of two rollers: a powered Top Feed Roller (100 mm diameter, elastomer-coated) and a spring-loaded Bottom Guide Roller (80 mm diameter, steel). The pair operates similarly to a document feed roller; as the top roller rotates, it grips the post and advances it toward the cutter drum.

The top roller is coated with elastomer to provide traction without marring the wood. The bottom roller is spring-loaded against the top, maintaining consistent contact pressure regardless of post diameter. Both rollers are mounted on Feed Bearing pillow block bearings in the Machine Frame.

The Feed Drive Shaft couples the top roller to the Feed Motor, a fixed-displacement unit. Feed speed is controlled by modulating the motor's pilot pressure via a proportional spool valve in the Hydraulic System circuit. Typical speeds are 0.5–3 m/min; softer woods and thinner bark allow faster feed rates, while hardwoods require slower speeds to allow the knives to cut cleanly without stalling.

Machine Frame and Structure

The Machine Frame is welded from steel box-section and angle iron, rigidly mounting the cutter head, feed system, and hydraulic components. The two Frame Beam main beams (300×200 mm wall 12 mm) run the length of the machine and are cross-braced by Cross Member members for lateral stiffness.

A Post Guide V-groove roller assembly at the feed inlet centers incoming posts in the feed roller pair, ensuring straight feed alignment. The Mounting Base is a steel plate bolted to the frame, providing anchor points for permanent or temporary floor mounting in a mill or processing facility.

Hydraulic System and Control

The Hydraulic Pump is a bent-axis variable displacement unit (50 cc/rev) with pressure compensation, supplying up to 210 bar. A Flow Divider proportionally apportions flow between the cutter and feed motors, maintaining synchronized operation.

The operator controls feed speed via a proportional lever or electronic throttle that modulates pilot pressure to the feed motor's control spool. The cutter motor typically runs at full speed continuously, as the drum speed is non-critical to cutting quality (within the 250–400 rpm range). A Relief Valve protects against overpressure if a knife binds.

The Cooler is fan-driven and maintains oil temperature below 50°C during continuous operation.

Performance and Maintenance

A modern post peeler processes 2–4 posts per minute depending on post diameter and bark thickness. A 6 m utility pole requires approximately 45–90 seconds, including positioning and ejection.

Key maintenance:

  • Replace or resharpen cutter knives every 20–40 processing hours, depending on wood species and bark hardness.
  • Check hydraulic fluid level and condition weekly.
  • Inspect drum and feed roller bearings for noise or play quarterly.
  • Clean bark accumulation from the machine exterior regularly to prevent fire hazard in mill environments.

Manufacturers like Söderhamn, Logosol, and Tersa produce post peelers ranging from small standalone units (100 kW, 30–50 posts/day) to large integrated processing lines. The technology is fundamental to utility infrastructure development in countries rapidly expanding electrical grid coverage.

Build & assembly graph

expand / collapse · shared sub-assemblies converge · links to related products · est. labour
product / assembly shared across products atomic part related product

Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.

Bill of materials

7 top-level lines · 28 rows shown · 44 parts total · indented to 3 levels
# Item / sub-assembly Part no. Qty/assy Ext. qty Parts Type
1 Cutter Head 5 parts post-peeler-cutter-head 1 20 assembly
1.1 Cutter Drum post-peeler-drum 1 part
1.2 Knife Holder Block post-peeler-knife-holder 8 part
1.3 Peeling Knife post-peeler-knife-blade 8 part
1.4 Drum Bearing post-peeler-drum-bearing 2 part
1.5 Drum Seal post-peeler-drum-seal 1 part
2 Feed System 5 parts post-peeler-feed-system 1 8 assembly
2.1 Top Feed Roller post-peeler-feed-roller-top 1 part
2.2 Bottom Guide Roller post-peeler-feed-roller-bottom 1 part
2.3 Feed Bearing post-peeler-feed-bearing 4 part
2.4 Feed Drive Shaft post-peeler-feed-drive-shaft 1 part
2.5 Feed Motor Linkage post-peeler-feed-motor-link 1 part
3 Machine Frame 4 parts post-peeler-machine-frame 1 7 assembly
3.1 Frame Beam post-peeler-frame-beam 2 part
3.2 Cross Member post-peeler-frame-cross 3 part
3.3 Post Guide post-peeler-post-guide 1 part
3.4 Mounting Base post-peeler-mounting-base 1 part
4 Hydraulic System 5 parts post-peeler-hydraulics 1 5 assembly
4.1 Hydraulic Pump post-peeler-pump 1 part
4.2 Flow Divider post-peeler-flow-divider 1 part
4.3 Relief Valve post-peeler-relief-valve 1 part
4.4 Cooler post-peeler-cooler 1 part
4.5 Hose Set post-peeler-hose-set 1 part
5 Cutter Motor post-peeler-motor-cutter 1 part
6 Feed Motor post-peeler-motor-feed 1 part
7 Diesel Engine 2 parts post-peeler-engine 1 2 assembly
7.1 Engine Block post-peeler-engine-block 1 part
7.2 Fuel Tank post-peeler-engine-fuel-tank 1 part
