Overview

Raman spectroscopy measures inelastic scattering of laser light by molecular vibrations. When a photon collides with a molecule, most scatter elastically (Rayleigh scattering, same frequency). Rarely (~1 in 10⁶ events), the photon transfers energy to or from a molecular vibration, emerging with shifted frequency. The energy difference corresponds directly to vibrational frequencies, which are characteristic of chemical bonds and functional groups. A Raman spectrum thus acts as a molecular fingerprint, identifying composition and structure without sample destruction or chemical modification.

Unlike infrared spectroscopy (which measures absorption), Raman measures scattered intensity, making it ideal for aqueous solutions, transparent materials (glass, ceramics), and non-polar molecules that absorb weakly in IR. Raman also provides complementary information to FTIR: bonds symmetric in structure (C=C, S=S) show strong Raman but weak IR response.

How it works

Laser Excitation: A focused laser beam (typically green 532 nm or near-IR 785 nm) illuminates a <1 µm³ sample volume. Photons interact with electron clouds of molecules, creating a brief virtual electronic state with lifetime ~10⁻¹⁶ s. The photon scatters with modified energy.

Energy Transfer: If the molecule gains vibrational energy hν_vib (Stokes scattering), the scattered photon loses that energy: ν_scattered = ν_laser − ν_vib, or in wavenumber units, ω_scattered = ω_laser − Δω (where Δω is the Raman shift in cm⁻¹). If the molecule loses energy (anti-Stokes), the scattered photon gains it. Stokes is ~100× more intense than anti-Stokes at room temperature (due to Boltzmann population of excited vibrational states).

Optical Rejection: The scattered light is collected by the objective lens and passes through dichroic and notch filters. The dichroic reflects the laser into the sample and transmits scattered light toward the spectrograph. The notch filter blocks Rayleigh scatter (elastic, at laser frequency) with >10⁶:1 rejection, allowing only Raman-shifted photons (Stokes or anti-Stokes) to reach the spectrograph.

Spectral Measurement: A holographic grating disperses Raman light by frequency. The spectrograph's entrance slit selects a ~25–100 µm spatial region (set by user), the collimator directs light onto the grating at oblique incidence, and the grating's 1200–1800 lines/mm spacing disperses the spectrum. A focusing mirror projects the dispersed light onto a CCD array. Each pixel records intensity at a specific Raman shift (wavenumber), building a spectrum over 200–3500 cm⁻¹ in a single exposure.

Detection: The CCD is back-thinned and deep-depleted (optimized for 532–900 nm sensitivity), cooled to −70 °C via Peltier thermoelectric modules to reduce dark current <1 e⁻/pixel/s. Exposure times of 10–60 s typical; hundreds of counts per peak in high-quality spectra. Readout is >1 MHz per pixel, and 16-bit digitization preserves intensity quantization.

Spatial Control: A motorized xy stage (±25 mm travel, 0.5 µm resolution) allows scanning across heterogeneous samples. Optional confocal pinhole (50–100 µm) blocks out-of-focus light, improving depth resolution to ~1–2 µm in z.

Raman Shift Identification

Characteristic Raman shifts of common bonds:

• C–H stretches: 2800–3100 cm⁻¹ (alkyl, aromatic)
• C=C stretches: 1200–1700 cm⁻¹ (alkene, aromatic rings)
• C≡C stretches: 2100–2200 cm⁻¹ (triple bond)
• C–O stretches: 1000–1200 cm⁻¹ (alcohols, ethers)
• N–H bends: 1300–1600 cm⁻¹ (amines, amides)
• S–S stretches: 400–600 cm⁻¹ (disulfides)

Crystalline materials (diamonds, silicon, salts) exhibit sharp, narrow lines; disordered or amorphous materials (polymers, glasses) show broader bands. Raman mapping—collecting spectra from a 50 × 50 µm grid—reveals spatial composition variation.

Advantages

• Non-destructive: Photons only excite vibrational states; no ionization or decomposition.
• Aqueous-compatible: Water shows minimal Raman (symmetric O–H stretches are Raman-inactive), unlike FTIR where water dominates.
• Small samples: Microscope coupling allows single-cell or fiber analysis.
• Fast: Full spectrum in <1 minute; chemical imaging over minutes.
• Complementary to FTIR: Symmetric bonds show strong Raman but weak IR.

Limitations

• Fluorescence: Many dyes and organic compounds fluoresce under UV/visible laser, overwhelming weak Raman signal. 785 nm excitation or anti-Stokes methods can mitigate.
• Laser photodegradation: High-power laser can photo-bleach or ablate sensitive samples.
• Weak signals: Raman cross-section is ~10⁻³⁰ cm², requiring >100 mW laser power and long integration for dilute samples.

Applications

• Pharmaceutical: Polymorph identification, API purity, and excipient mapping in tablets.
• Minerals & Gems: Rapid mineral ID and gemstone authenticity without destructive sampling.
• Polymers: Degree of crystallinity, chain orientation, and blend composition.
• Catalysis: Support interactions, oxidation state, and structural disorder.
• Forensics: Fiber, paint, and gunshot residue analysis.
• Art & Conservation: Non-destructive pigment identification in paintings.
• Biological: Protein secondary structure and cellular lipid/nucleic acid content (label-free).

Maintenance

• Laser alignment: Annual check-up; mirrors and dichroics require dry-cloth cleaning only.
• CCD sensor: Periodic dark-frame acquisition for thermal-noise calibration; ~5-year lifespan before performance degradation.
• Notch filter: Absorptive coatings degrade under prolonged laser exposure; replacement every 2–5 years typical.
• Sample stage: Stepper motor lubrication every 500 operating hours; no mechanical wear if <50 µm particles avoided.
