Hydraulic Scissor Lift Table Product

Overview

A hydraulic scissor lift table raises loads between floor level and working height — pallet positioning, ergonomic work stations, dock levelling, conveyor line transfers. The geometry is a pantograph: two pairs of steel legs crossed at a Center Pivot, with one end of each leg pinned and the other rolling in a Roller Track. Pushing the scissor open with a hydraulic cylinder raises the Load Platform while keeping it level through the whole stroke, with no vertical guides or columns. Capacities run from 500 kg ergonomic tables to multi-tonne coil and die handlers; the type is governed by EN 1570-1 in Europe and ANSI MH29.1 in North America.

Mechanics of the scissor

The defining mechanical fact is that the cylinder force requirement is not constant. Near the closed position the legs are nearly horizontal, the cylinder acts at a poor angle, and the force needed to start lifting can be three to five times the payload; as the table rises the geometry improves and the force falls. This is why the Track Roller units and the Center Pivot are sized for the lowered condition, why closed height cannot shrink arbitrarily, and why low-profile tables cost disproportionately more. The Inner Leg and Outer Leg weldments are box sections tied by Cross Tube members so an offset pallet cannot rack the platform; EN 1570-1 requires rated performance with the load on half the platform. Every pin runs in a Pivot Bushing — the main scheduled wear item, greased or self-lubricating.

Hydraulic circuit

The circuit is deliberately minimal. A Gear Pump driven by the Pump Motor (1.5–4 kW, rated for intermittent S3 duty because the motor only runs during lifting) feeds one or two single-acting Lift Cylinder units at 160–200 bar. There is no powered descent: gravity closes the scissor, pushing oil back through the Lowering Valve, a normally closed solenoid valve with pressure-compensated flow control, so descent speed is the same loaded or empty. The Check Valve holds the load when the pump stops, and the factory-sealed Relief Valve makes overloading hydraulically impossible — the table simply stalls rather than lifts beyond rating, with a Pressure Sensor switch available to signal the condition.

The safety-critical valves sit on the cylinders, not the powerpack. A Hose Burst Valve — a velocity fuse — at each cylinder port locks flow if a hose in the Hose Set ruptures, so a burst line drops the platform millimetres, not metres. This placement is an EN 1570-1 requirement: protection must survive failure of everything between cylinder and tank.

Controls

Controls are intentionally primitive by machine standards: a 24 V hold-to-run Control Pendant or guarded Foot Switch energizes the Motor Contactor (up) or the lowering valve solenoid (down), and releasing the control stops motion immediately. The Control Box contains the contactor, the Control Transformer that keeps operator circuits at 24 V, and Limit Switch inputs for the stroke ends. Conveyor-line installations replace the pendant with PLC control and add position sensing, but the same hold-to-run hardware remains for maintenance mode.

Safety devices

The dominant hazard is descent: shear and crush points close as the table lowers. EN 1570-1's primary answer is the Trip Frame, a bar frame hanging a few millimetres below the platform perimeter — anything it touches during descent lifts it against the Trip Switch pair and de-energizes the lowering valve, which closes and stops the platform at once. Toe Guard skirts keep feet from under the deck edge, Pinch Guard panels cover scissor crossings reachable from the sides, and a full Skirt Bellows encloses the mechanism where operators work against the table. For maintenance, painted Maintenance Prop struts pin across the scissor so no one works under a hydraulically suspended platform.

Installation and service

The Base Weldment either bolts to the slab with the Anchor Set or sits in a shallow pit so the lowered Deck Plate lies flush with the floor for pallet-truck loading. Leveling Shim packs square the base on imperfect concrete so the legs load evenly; Fork Pocket tubes allow forklift relocation of unanchored units. Service is undemanding — annual oil checks of the Oil Reservoir, bushing lubrication, and a Seal Kit at overhaul — and well-maintained tables routinely exceed 100,000 cycles.
