Overview

A resistance seam welder creates a continuous or intermittent weld line by rolling a pair of [[seam-welder-upper-wheel|rotating electrode wheels]] across overlapped sheet edges while pulsing high current. Each current pulse creates a single nugget; the next pulse fires as the wheel advances, overlapping nuggets to form a gas-tight seam.

Used primarily for metal can seaming (aluminum beverage cans), fuel tank side seams, pipe spiral seaming, and container fabrication. No filler, no flux, no consumables except electrode dressing. A seam sealer can process 200+ meters of weld per hour in production.

The welder rolls continuously; an encoder on the [[seam-welder-wheel-drive|drive motor]] synchronizes current pulses with wheel rotation, ensuring nuggets are evenly spaced and fully overlapped. Modern systems offer continuously rolling or periodic (pulse-on-demand) modes for flexible joint designs.

How it works

Setup and Positioning: The operator positions the overlapping edge zone between the two [[seam-welder-upper-wheel|electrode wheels]]. A [[seam-welder-pressure-cylinder|pneumatic or hydraulic cylinder]] applies squeeze force (typically 3–5 kN for thin aluminum). The lower wheel is either free-spinning or motorized.

Wheel Rotation Initiation: The [[seam-welder-drive-motor|drive motor]] starts at soft-ramp via a soft-starter or VFD, spinning up the upper wheel to the desired rotation speed (typically 50–150 rpm). A [[seam-welder-wheel-encoder|rotary encoder]] mounted on the wheel shaft counts revolutions.

Pulse Synchronization: The [[seam-welder-pulse-controller|timer controller]] listens to the [[seam-welder-wheel-encoder|encoder]] and fires the [[seam-welder-contactor|transformer contactor]] at predetermined intervals synchronized with wheel rotation. For example, if pulse duration is 200 ms on and 300 ms off, the welder energizes the transformer for 200 ms, then de-energizes for 300 ms as the wheel rotates. The [[seam-welder-pulse-timer|programmable timer]] adjusts these intervals for nugget spacing.

Current Pulse and Nugget Formation: When the contactor energizes, [[seam-welder-transformer|secondary current]] (5–30 kA) flows between the wheels through the overlapping seam zone. Resistance heating produces a molten nugget in 100–300 ms. The [[seam-welder-wheel-pressure|squeeze force]] consolidates the nugget as current expires. The wheel continues rotating.

Continuous Seam: As the wheel advances, the next pulse fires, creating an adjacent nugget that overlaps the previous one by 30–50%. Continuous overlapping produces a sealed edge with no gaps. Pulse rate and wheel speed are tuned so each nugget partially re-melts and bonds to the previous nugget, creating a continuous fusion line.

Workpiece Advance (Optional): Some systems use a [[seam-welder-workpiece-drive|motorized pinch roller drive]] to advance the workpiece linearly under the wheels at a constant rate (20–200 mm/min). This is useful for producing long straight seams without operator effort. Hand-fed systems require the operator to manually advance the seam between the wheels.

Cool and Release: After seaming is complete, the operator releases the squeeze force (solenoid de-energizes), the wheels disengage, and the workpiece is removed. The seam cools instantly due to the massive copper wheel heat sinks.

Nugget Overlap and Seam Continuity

A seam is strong if:

1. Nuggets fully overlap: At least 30–50% of the nugget diameter overlaps the adjacent nugget, forming a continuous metallurgical bond.
2. No porosity or cracks: Proper force and cooling during hold ensure solid metal.
3. Consistent nugget size: Voltage and current stability produce uniform nuggets along the entire seam.

Insufficient overlap (nuggets spaced too far apart) leaves micro-cracks between nuggets, allowing fluid or gas to leak. This is the most common failure mode in high-volume can seaming.

Nugget spacing is calculated:

$$ ext{Spacing} = rac{ ext{Wheel circumference} imes ext{pulse on time}}{( ext{pulse on time} + ext{pulse off time})}$$

For a 150 mm diameter wheel rotating at 100 rpm:

• Circumference = 0.47 m
• Rotation time per revolution = 0.6 s
• If pulse is 200 ms on, 300 ms off: spacing = 0.47 × 0.2 / 0.5 = 0.19 m = 19 mm

Spacing of 15–20 mm with 25–30 mm nugget diameter provides reliable overlap.

Wheel Wear and Dressing

Copper alloy electrodes erode during extended seaming. Wheel face diameter can grow 0.5–2 mm over 100,000 meters of weld, changing the nugget size and spacing. When wear reaches 1 mm diameter growth, wheels must be "dressed" (machined).

Dressing involves:

1. Unmounting the wheels (quick-change or bolted).
2. Placing them on a lathe or specialized wheel-dressing machine.
3. Turning the OD down ~1 mm, re-machining the face radius.
4. Reinstalling and re-calibrating the pulse timing.

Well-maintained wheels can last 500,000–1,000,000 meters of seam. Neglect and improper cooling reduce life to 50,000 meters.

Thermal Management and Wheel Cooling

The [[seam-welder-cooling-system|water cooling system]] is critical. Seam welding dissipates continuous power (even during pulse off, wheel rolling creates friction). Wheel face temperature can exceed 300 °C without cooling, softening the copper and distorting the electrode geometry.

A typical system delivers 30–50 L/min of 20–25 °C water through spiral passages inside both [[seam-welder-upper-wheel|upper]] and [[seam-welder-lower-wheel|lower wheels]]. The water absorbs heat and returns to a [[seam-welder-cooling-tank|large reservoir]] where it cools. A [[seam-welder-thermostatic-valve|three-way proportional valve]] regulates inlet temperature by mixing cool return water with bypass flow.

Without cooling, the operator cannot run continuously; they must pause every 5–10 minutes for the wheels to cool. With cooling, run times of 2–4 hours are feasible before routine maintenance.

Continuous vs. Intermittent Seaming

Continuous rolling (no current): The wheels roll slowly across the joint under squeeze force, heating the seam by friction alone. This is rare and only works on materials with high friction (soft aluminum). No external power needed.

Pulsed resistance (modern standard): Wheels roll continuously; current pulses fire at regular intervals synchronized to rotation. Each pulse creates a nugget. This allows precise spacing control and higher speed. Most modern seamers use this mode.

Linear indexing (specialized): Wheels stop, current pulses for a set time to form a nugget, then wheels index forward and repeat. Slower but allows very precise nugget placement. Used for specialty high-reliability applications.

Current and Material Selection

Material	Thickness	Spacing	Current	Speed
Aluminum 1050	0.2 mm	15–18 mm	8–12 kA	150 rpm
Aluminum 5182	0.3 mm	18–22 mm	10–14 kA	120 rpm
Mild steel	0.5 mm	20–25 mm	12–18 kA	100 rpm
Stainless 304	0.8 mm	20–30 mm	15–25 kA	80 rpm

Aluminum seams are tight and fast (high rpm, small spacing) due to low electrical resistance. Stainless is slower (lower rpm to control current) and spacing is larger (more robust nuggets needed to bridge oxide).

Leakage and Weld Quality Testing

Seam-sealed containers are pressure-tested after fabrication. A pressure bump at the seam during hydrostatic or pneumatic test indicates porosity or micro-cracks between nuggets.

Destructive weld tests verify seam integrity: cross-section the seam and examine nugget overlap under a microscope. Pull-apart tests measure tensile strength of the seam line. Well-sealed seams should not fail; failure indicates spacing, current, or force tuning issues.

Maintenance Schedule

Daily: Drain condensation from cooling water tank, wipe wheel faces with a cloth (remove light scale), and visually inspect electrode wheel faces for spalling.

Weekly: Check cooling water temperature and flow (should reach setpoint within 30 min), inspect encoder cable for damage, and test pulse timing on a scrap sample.

Monthly: Clean the [[seam-welder-cooling-filter|cooling filter]], check wheel squeeze force with a pressure gauge (should hold setpoint), and examine transformer fan operation.

Quarterly: Measure wheel diameter with calipers (if growth > 1 mm, schedule dressing), flush cooling system with fresh water and inhibitor, and calibrate transformer secondary voltage with a multimeter.

Annually: Rebuild the [[seam-welder-cooling-pump|centrifugal pump]], inspect wheel bearings for play (replace if loose), and recalibrate all pressure/timing sensors.

Troubleshooting

Seam leaks (micro-cracks): Insufficient nugget overlap (increase pulse on-time or reduce wheel speed), low squeeze force (increase pneumatic pressure), or inconsistent current (check transformer secondary voltage on all taps).

Wheel face spalling: Dirty cooling water (replace coolant and flush passages), wheel overheating during cool-down pause (add external cooling or use motorized feed to avoid stopping), or incorrect pulse parameters (pulse off-time too long, allowing wheel surface to overheat).

No or weak current: Loose wheel-to-frame electrical contact (clean contact faces or tighten mounting bolts), broken encoder cable (test with multimeter, replace if open), or transformer primary contactor not closing (check 24V coil voltage and contactor contacts).

Nugget spacing inconsistent: Wheel speed varying (tachometer check on motor, tune soft-start ramp rate), or encoder missing pulses (check encoder alignment and cable shielding in drag chain).

Loud grinding or seizing: Wheel bearings worn (replace bearing cartridge), or high wheel pressure with partial seizure (reduce pneumatic pressure and verify workpiece isn't jamming between wheels).
