Overview

A slipform paver lays a continuous reinforced or plain concrete slab — a highway lane, airport runway, canal lining or barrier wall — without fixed formwork. The mold travels with the machine: stiff, low-slump concrete is dumped in front of it, fluidized by vibration, forced through the Paving Mold Kit, and emerges behind the machine already shaped to its final width, thickness and crown. Because the mix is so dry, the extruded slab edge stands on its own seconds after the Side Form passes. A mid-size mainline paver covers a 3.5–7.5 m width and places several hundred metres of pavement per day; the largest configurations exceed 15 m for two-lane single-pass work.

The machine is built around the Telescoping Tractor Frame, a telescoping weldment that hangs the mold between four crawler legs. The Power Unit supplies everything hydraulically, four Crawler Track Unit units carry and steer the machine, and the Guidance System system holds it on line and grade to a few millimetres.

Concrete handling

Trucks discharge concrete onto the grade ahead of the machine or onto a belt placer. The Spreading Auger then distributes the pile across the full paving width; its two opposite-hand Auger Flighting sections can run independently and in reverse, so the operator can shift material toward a starved side. Behind the auger, the Strike-Off Plate plate meters a consistent head of concrete — typically 100–150 mm above final grade — into the vibrator chamber. Maintaining that head is the single most important operator task: too little starves the mold and leaves voids, too much overloads the Tamper Bar and lifts the profile.

Consolidation and extrusion

Inside the mold throat hangs a gang of Poker Vibrator units spaced 300–600 mm apart. Each contains a hydraulically spun eccentric running at 6,000–10,000 vibrations per minute, which momentarily liquefies the surrounding concrete so entrapped air escapes and the mix flows around dowels and tie bars. Flow to each poker is set at the Vibrator Flow Valve bank on the Vibrator Manifold; modern specifications require vibrator frequency monitoring tied to ground speed, because over-vibration at slow speed segregates the mix and causes longitudinal cracking over each poker trail.

The fluidized concrete is then confined by the Mold Pan and side forms. As the machine creeps forward at 0.5–4 m/min, the pan acts as a moving extrusion die: pressure from the confined, vibrating concrete fills the profile, and the Crown Adjuster jacks set the transverse shape. On thick pavements a tamper bar oscillating just ahead of the pan pushes coarse aggregate down so mortar rises to the surface. A trailing Finishing Pan floats the surface closed; hand finishers behind the machine need only correct minor tears and apply texture and curing compound.

Propulsion and steering

Each crawler is an independent module: a Track Frame with a sealed Track Chain running on flat pads, driven by a planetary Track Final Drive from the propel circuit. Because paving speed is two orders of magnitude below a dozer's travel speed, the hydrostatic drives are optimized for smooth creep — speed ripple at the tracks prints directly into the slab surface. Steering is by Steering Cylinder at each leg, and the Swing Leg geometry lets the tracks rotate 90° for transport or run offset to pave hard against an obstruction. The four Hydraulic Lift Column posts set elevation; together the columns and steer cylinders give the guidance computer full four-axis authority over the mold position.

Guidance

Traditional control uses a stringline: a tensioned wire set by surveyors at a fixed offset from the design alignment. Four Stringline Sensor Wand sensors ride the wire, two reporting elevation and two reporting horizontal deviation, while the Cross-Slope Sensor carries the grade across the width. The Guidance ECU closes the loop at several hertz, driving steer and lift valves so the mold tracks the wire within about ±3 mm. Stringless operation replaces the wire with the 3D Guidance Interface: one or two robotic total stations track mast-mounted prisms on the machine (or GNSS supplies position on lower-tolerance work), and the ECU compares the measured mold position against a digital terrain model. Stringless paving removes the surveying labour and truck-access obstruction of the wire, and is now standard on airport and highway mainline work.

Power and controls

The Diesel Engine runs at constant speed driving the Hydraulic Pump Group, with separate circuits for propel, vibrators, auger and auxiliaries so a stalled auger cannot starve the tracks. The operator works from the Operator Station platform above the mold, where the Control Console groups travel, width, vibrator and guidance setpoints; a hard-wired E-Stop Circuit rings the machine. Daily production hinges less on the machine than on logistics: a paver stopped waiting for trucks leaves a cold joint, so batch-plant output, haul cycle and paver speed are planned as one system.
