Solar Air Heater Product

Overview

A solar air heater is the simplest useful solar thermal machine: a glazed box on a sunny wall that heats air instead of water. Building air is drawn in through one wall opening, passes under a hot black plate, and returns through a second opening 20–40 °C warmer. Because the working fluid is the room air itself there is no heat exchanger, no antifreeze, no pressure circuit, and no risk from leaks — a hole in the collector loses some warm air, not a tank of glycol. A 2 m² unit delivers roughly 1 kW of heat in full sun, enough to meaningfully offset daytime heating in a 25–60 m² space, and is most common on cabins, garages, and workshops where it also provides dehumidifying ventilation when the building is unoccupied.

How it works

Sunlight passes through the Glazing Panel and lands on the Absorber Plate, an aluminium sheet whose selective coating absorbs about 95% of the incident spectrum but emits only ~5% in the thermal infrared. The glazing traps a still-air layer over the plate, suppressing convective loss, while Back Insulation and Side Insulation inside the Casing Tray close the rear and edges; an Reflective Liner liner reflects re-radiated heat back into the channel.

Air does not flow over the glazed face — that would carry heat into the glass. It flows underneath the plate, forced by Flow Baffles into a serpentine path several metres long. Air is a poor heat-transfer fluid, so the design works the boundary layer hard: Turbulator Ribs ribs trip the flow into turbulence, roughly doubling the plate-to-air transfer coefficient at the cost of some fan pressure. The Inlet Plenum spreads the intake evenly across the channel width and the Outlet Plenum gathers the heated stream at the top, where the Collector Probe measures delivery temperature.

The PV-driven fan loop

The elegant trick in most modern units is the PV Panel: a 20 W module that powers the Blower Motor directly. Fan speed then tracks irradiance without any control law — bright sun means maximum heat available and maximum airflow to collect it; clouds mean both fall together. The collector needs no mains connection at all, which is why these units appear on off-grid cabins.

The Thermostat Controller refines this with a differential thermostat. Its Microcontroller compares the collector probe against the Room Probe and gates the fan through a Power MOSFET PWM stage: the fan starts only when the collector runs ~10 °C above the room (otherwise it would blow lukewarm air and feel like a draft) and stops when the room reaches the set point on the Control Knob. A Thermal Fuse protects the electronics during stagnation, when a stalled collector under full sun can reach 140 °C — every material in the stack, notably the glazing gasket and insulation binder, must survive that condition indefinitely.

At night the airflow path must close, or the collector becomes a radiator running in reverse and the warm room exhales through it. The Backdraft Damper, a simple gravity flap behind the Fan Shroud, does this passively the moment the fan stops.

Building interface

The unit couples to the room through two Ø125 mm Wall Collars — return air low and cool, supply air high and warm, matching natural stratification. Short runs of Flexible Duct take up alignment error, a washable Intake Filter keeps dust out of the absorber channels, and the Room Register lets the occupant aim or shut the warm stream. Duct Seals and the stand-off Wall Brackets keep the facade weathertight, with the casing hung on a Mounting Rail so one installer can fit it. Flat-roof and high-latitude sites use Tilt Legs at 45–60°, which favors the low winter sun that the heater exists to harvest.

Performance

Collector efficiency falls as the absorber runs hotter than ambient, because every degree of difference drives more loss through glazing and casing. At low temperature rise a glazed unit converts 60–70% of incident solar energy to delivered heat; pushed to a 40 °C rise it drops toward 40%. The practical operating point is a trade between airflow and outlet temperature, set by the fan speed: high flow harvests more total energy at modest warmth, low flow delivers hotter air. Annual yield on a south facade in a heating-dominated climate runs 300–500 kWh/m² — modest beside a heat pump, but achieved with no fuel, no mains power, and essentially no moving parts beyond one fan and one flap.
