Thermal Binoculars Product
Overview
Thermal binoculars show the world in heat instead of visible light, letting users see warm objects (humans, animals, engines, fires) in complete darkness or through obscuring smoke and fog. The Thermal Camera Core contains an uncooled Microbolometer Array—a grid of tiny temperature sensors on silicon, each one responsive to thermal radiation in the 8–14 micrometer infrared band. The Thermal Objective Lens focuses this heat onto the array. The Image Processor Board converts the temperature map into a false-color image and sends it to both Left Eyepiece (OLED) and Right Eyepiece (OLED) OLED displays, so the user sees a comfortable stereoscopic view.
The Laser Rangefinder Module adds a laser distance measurement and ballistic computer—essential for hunters and military users who need to know aim-off corrections for wind, gravity, and target motion. The Battery Pack runs continuously for 4–6 hours, and the rubber-armored Binocular Housing is rugged enough for field use.
Unlike visible-light binoculars, which magnify an image (so distant objects appear closer), thermal binoculars are a fixed-focal system where magnification is achieved digitally—the processor zooms into regions of the image—so a pixel remains a pixel regardless of zoom setting.
How it works
The Thermal Objective Lens is precision multi-element optics made of germanium or sapphire, which are transparent to long-wave infrared (LWIR, 8–14 μm). Regular glass blocks LWIR, so this is not a simple glass lens. The lens focuses the heat from a scene onto the Microbolometer Array, which is a 160×120 or 320×256 array of vanadium-oxide resistors. Each resistor's temperature is proportional to the amount of infrared radiation hitting it.
An active thermal control circuit maintains a reference resistor (actually a second FPA cell isolated from the scene) at a slightly higher temperature. The Thermal Readout ASIC scans each bolometer pixel, measures its resistance (which indicates temperature), and outputs an analog video signal. This readout is slow—LWIR cameras cannot capture video at 60 fps like visible cameras; they typically update at 9–30 Hz because the bolometer time constant is inherently slow.
The analog signal goes to the Image Processor Board, which applies flat-field and non-uniformity corrections (accounting for variations in bolometer sensitivity across the array) and remaps the temperature range to a 640×480 image. The Image Processor Board also applies color palettes—the most common is a grayscale or "white-hot" palette where warm objects are bright, or "iron" where hotter is darker red/white. The output is delivered via HDMI or LVDS to the two Left Eyepiece (OLED) and Right Eyepiece (OLED) micro-OLED displays, one for each eye.
The user looks through the eyepiece optics, which magnify the OLED display (typically 1–3×), creating a comfortable viewing angle and exit pupil size matching the human eye. Diopter wheels (Eye Focus Wheel) allow focus adjustment, and an interocular distance wheel adjusts the separation between eyepieces.
The Laser Rangefinder Module is a simple pulsed laser (usually 905 nm, in the near-infrared where silicon detectors work well) and a Photodiode Array. A signal processor measures the time-of-flight to compute distance. This distance is fed to the Ballistics Processor, which solves for wind, gravity drop, and spin drift to compute a firing solution. The solution is overlaid on the thermal image as a reticle or offset indicator.
Thermal sensitivity is critical: a good thermal imaging system can resolve a temperature difference of 50 mK (0.05 °C) at the sensor—much better than what the uncooled bolometer can achieve, thanks to careful calibration and noise filtering. NEDT (noise-equivalent temperature difference) values of 40–80 mK are typical.
Battery consumption is driven by the OLED displays and signal processing, typically 2–5 W. The Battery Pack is sized for 4–6 hours of continuous operation, often user-replaceable for field recharge via USB or external charger.
Field-of-view is fixed by the objective focal length. A short focal length (e.g., 19 mm) gives a wide field of view (9°), useful for scanning. A long focal length (e.g., 75 mm) gives a narrow field (2°), useful for identifying distant targets. High-end systems offer a zoom turret with multiple objectives; consumer versions are fixed.
Unlike cooled thermal cameras (which achieve < 20 mK NEDT using cryogenic cooling and are used in aerospace and military imaging), uncooled thermal binoculars are practical for field work: no cryogenic maintenance, lower power, lighter weight, and dramatically lower cost—though sensitivity is lower.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labourTap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
10 top-level lines · 52 rows shown · 267 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Thermal Camera Core 4 parts | thermal-camera-core | 1× | 1 | 4 | assembly |
| 1.1 | Microbolometer Array | thermal-microbolometer | 1× | 1 | — | part |
| 1.2 | Thermal Readout ASIC | thermal-readout-asic | 1× | 1 | — | part |
| 1.3 | FPA Housing | thermal-fpa-housing | 1× | 1 | — | part |
| 1.4 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 2 | Thermal Objective Lens 4 parts | thermal-objective-lens | 1× | 1 | 5 | assembly |
| 2.1 | Germanium Lens Element | thermal-ge-element | 2× | 2 | — | part |
| 2.2 | AR Coating | thermal-ar-coating | 1× | 1 | — | part |
| 2.3 | Lens Barrel | thermal-lens-barrel | 1× | 1 | — | part |
| 2.4 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 3 | Beamsplitter Module 3 parts | thermal-beamsplitter | 1× | 1 | 3 | assembly |
| 3.1 | Thermal Dichroic Mirror | thermal-dichroic-mirror | 1× | 1 | — | part |
| 3.2 | Split Optics | thermal-split-optics | 1× | 1 | — | part |
| 3.3 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 4 | Left Eyepiece (OLED) 4 parts | thermal-eyepiece-left | 1× | 1 | 28 | assembly |
| 4.1 | Micro-OLED Display | thermal-oled-micro | 1× | 1 | — | part |
| 4.2 | Eyepiece Relay Optics | thermal-eyepiece-relay | 1× | 1 | — | part |
| 4.3 | Eye Focus Wheel 2 parts | thermal-eye-focusing | 1× | 1 | 25 | assembly |
| 4.3.1 | Servo Motor 4 parts + deeper › | servo-motor | 1× | 1 | 24 | assembly |
| 4.3.2 | Ball Bearing | ball-bearing | 1× | 1 | — | part |
| 4.4 | Connector | connector | 1× | 1 | — | part |
| 5 | Right Eyepiece (OLED) 4 parts | thermal-eyepiece-right | 1× | 1 | 28 | assembly |
| 5.1 | Micro-OLED Display | thermal-oled-micro | 1× | 1 | — | part |
| 5.2 | Eyepiece Relay Optics | thermal-eyepiece-relay | 1× | 1 | — | part |
| 5.3 | Eye Focus Wheel 2 parts | thermal-eye-focusing | 1× | 1 | 25 | assembly |
| 5.3.1 | Servo Motor 4 parts + deeper › | servo-motor | 1× | 1 | 24 | assembly |
| 5.3.2 | Ball Bearing | ball-bearing | 1× | 1 | — | part |
| 5.4 | Connector | connector | 1× | 1 | — | part |
| 6 | Image Processor Board 5 parts | thermal-image-processor | 1× | 1 | 157 | assembly |
| 6.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 6.2 | Compute SoC Module | soc-module | 1× | 1 | — | part |
| 6.3 | Microcontroller | mcu | 1× | 1 | — | part |
| 6.4 | SMD Passive (R/C/L) | smd-passives | 150× | 150 | — | part |
| 6.5 | Connector | connector | 4× | 4 | — | part |
| 7 | Laser Rangefinder Module 4 parts | thermal-rangefinder | 1× | 1 | 4 | assembly |
| 7.1 | Rangefinder Laser | thermal-rangefinder-laser | 1× | 1 | — | part |
| 7.2 | Rangefinder Detector | thermal-rangefinder-detector | 1× | 1 | — | part |
| 7.3 | Ballistics Processor | thermal-ballistics-cpu | 1× | 1 | — | part |
| 7.4 | Microcontroller | mcu | 1× | 1 | — | part |
| 8 | Battery Pack 3 parts | thermal-battery-pack | 1× | 1 | 6 | assembly |
| 8.1 | Li-ion Cell, 18650 | li-cell-18650 | 4× | 4 | — | part |
| 8.2 | BMS Board | bms-board | 1× | 1 | — | part |
| 8.3 | Connector | connector | 1× | 1 | — | part |
| 9 | Binocular Housing 5 parts | thermal-housing | 1× | 1 | 31 | assembly |
| 9.1 | Main Body | thermal-main-body | 1× | 1 | — | part |
| 9.2 | Ocular Cup | thermal-ocular-cup | 2× | 2 | — | part |
| 9.3 | Focus Wheel Mechanism 2 parts | thermal-focus-mechanism | 1× | 1 | 25 | assembly |
| 9.3.1 | Servo Motor 4 parts + deeper › | servo-motor | 1× | 1 | 24 | assembly |
| 9.3.2 | Ball Bearing | ball-bearing | 1× | 1 | — | part |
| 9.4 | Armor Coating | thermal-armor-coating | 1× | 1 | — | part |
| 9.5 | Fastener Set | fastener-set | 2× | 2 | — | part |
| 10 | Fastener Set | fastener-set | 1× | 1 | — | part |
Sourcing — likely vendors
Companies that make this · indicative price $100–$8k · MOQ & lead are typical| Vendor | HQ | Specialty | MOQ | Lead time |
|---|---|---|---|---|
| 🇯🇵Canon canon.com ↗ | Tokyo, JP | Imaging & optics | 500 units | 10–16 wks |
| 🇯🇵Nikon nikon.com ↗ | Tokyo, JP | Imaging & optics | 500 units | 10–16 wks |
| 🇩🇪ZEISS zeiss.com ↗ | Oberkochen, DE | Optics & optoelectronics | 500 units | 10–16 wks |
| leica-camera.com ↗ | Wetzlar, DE | Cameras & optics | 500 units | 10–16 wks |
| flir.com ↗ | Wilsonville, US | Thermal imaging | 500 units | 10–16 wks |
