Ultrasonic Flow Meter Product

Overview

An ultrasonic flow meter determines flow velocity by measuring the time it takes for ultrasonic pulses to travel between two transducers mounted on opposite sides of a pipe. When flow exists, the pulse traveling downstream reaches the opposite transducer faster than the pulse traveling upstream, because the fluid carries the sound. By measuring the difference in transit times, the electronics compute flow velocity and multiply by pipe area to obtain volumetric flow. The clamp-on design is non-invasive: no cutting, draining, or welding; just strap the transducers to the outside of the pipe. This makes ultrasonic meters ideal for retrofit, pilot plants, and custody transfer where minimal installation cost and zero pressure drop are critical.

The system includes a Transducer Pair Assembly mounted on the pipe via a Clamp Fixture Assembly, a Transmitter Electronics generating ultrasonic bursts and timing their returns, and a Cable Assembly connecting everything. The transmitter's Microcontroller calculates flow from transit-time differences and outputs 4–20 mA.

How it works

The upstream and downstream Transducer Pair Assembly alternately pulse and listen. The transmitter sends a burst downstream and measures the time T1 for the echo to return, then sends a burst upstream and measures time T2. If flow velocity is V and the transducer spacing is D, the relationship is approximately (T2 − T1)/(2 × T1 × T2) = V/C², where C is the speed of sound in the fluid (nominally 1480 m/s in water).

The Receiver Amplifier detects the weak return echo and times its arrival with microsecond precision. Temperature affects sound speed, so many meters include temperature compensation. The Microcontroller solves for velocity and multiplies by pipe cross-section area (entered during setup) to yield volumetric flow.

The clamp-on approach trades some accuracy (±1–2%) for installation ease: the acoustic-coupling between transducer and pipe introduces a small systematic offset that calibration corrects. Ultrasonic meters work on any pipe material (metal, plastic, concrete) as long as the fluid is a liquid, including slurries, oils, and corrosive liquids—because the sound path is external and only the acoustic window contacts the process. Multi-path designs (chordal paths at different radii) improve accuracy in swirling flow, but single-path clamp-on meters are the minimum cost for general flows.
