Veterinary ICU Cage Product

Overview

A veterinary ICU cage is a climate-controlled enclosure for animals in respiratory distress, recovering from anesthesia, or fighting hypothermia, heat stroke, or sepsis. Where a standard kennel cage offers only containment, the ICU cage actively manages the three variables that most affect a critical patient: inspired oxygen fraction, ambient temperature, and humidity — while a sensor suite watches the chamber and alarms the moment anything drifts. The common clinical cases tell the story: a cat in congestive heart failure breathes 40% oxygen without the stress of a face mask; a 300-gram puppy recovering from surgery sits in 32 °C air because it cannot yet thermoregulate; a brachycephalic dog in heat stroke is actively cooled in 18 °C air at 40% humidity.

Chamber

The patient compartment is built for visibility, access, and disinfection at once. A polycarbonate Transparent Front Door spans the full front so staff can assess the patient without opening the seal; self-sealing Access Port grommets pass IV lines, ECG leads, and a clinician's hands without collapsing the oxygen atmosphere — important because a 100-liter chamber at 40% O2 takes several minutes and many liters of oxygen to re-establish after a full door opening. The seamless Chamber Liner has coved corners with no crevices, and the Floor Grate & Drain Pan lifts out over a drain pan so the patient stays dry. A dimmable Interior LED Light supports both examination and the day-night cycling that long-stay patients need.

Oxygen control

Oxygen enters through DISS-keyed Oxygen Inlet Fitting fittings from hospital pipeline, a cylinder, or a concentrator. After the Oxygen Regulator, a Proportional Solenoid Valve meters flow under closed-loop control: the galvanic Oxygen Concentration Sensor samples chamber gas, and the controller modulates the valve until measured FiO2 sits on the setpoint, anywhere from room air to 60%. Clinically, 40% is the standard target — it relieves most hypoxemia while staying well below the threshold for oxygen toxicity, which becomes a concern above 60% sustained beyond 24 hours. A rotameter Oxygen Flowmeter gives a glanceable backup reading, and the Oxygen Inlet Diffuser spreads the incoming gas so no cold jet plays on the patient. The Door-Ajar Sensor pauses metering when the door is ajar rather than venting expensive oxygen into the ward.

Temperature and humidity

Conditioned air loops continuously through the machinery bay. A PTC Heating Element warms the stream for hypothermic and neonatal patients; for hyperthermic ones, a Peltier Cooling Stack chills it, rejecting heat through a Radiator — giving a true 18–40 °C range that resistive-only cages cannot reach downward. Two layers of hardware protection back the software loop: a Duct Overtemp Thermostat opens the heater circuit if the duct overheats, and a Thermal Fuse is the unresettable last resort, the same defense-in-depth pattern used in infant incubators.

Humidity matters more than most owners would guess. Dry oxygen desiccates airway mucosa and thickens secretions, so the Ultrasonic Nebulizer atomizes distilled water from the Water Reservoir into the airstream to hold 40–65% RH; the same transducer can nebulize saline for pneumonia and bronchitis cases. When a wet patient or its own respiration pushes humidity high, the chilled Dehumidifier Condenser Coil pulls moisture out into the Condensate Tray. A Reservoir Level Switch alarms before the reservoir runs dry.

Air handling and CO2

A patient in a sealed box exhales into its own atmosphere, so CO2 management is a safety function, not a comfort feature. The Blower Motor turns chamber air over 12–20 times an hour through an H13 HEPA Recirculation Filter, and an NDIR CO2 Sensor (NDIR) watches the recirculated gas; above roughly 0.5% CO2 the controller opens the CO2 Purge Valve, bleeding chamber gas and drawing fresh make-up air while the O2 loop compensates. The Supply Air Duct distributes flow along the ceiling so the patient sits in gentle, even air rather than a draft, and in-chamber noise stays under 45 dB(A) — sound stress measurably worsens outcomes in feline patients.

Control, alarms, and safety

The Control Board runs three independent PID loops (O2, temperature, humidity) on a real-time Microcontroller while a Compute SoC Module handles the touchscreen, trend graphs, and logging of chamber climate into the patient record. Alarms are tiered: a drifting parameter raises a yellow advisory on the Alarm Beacon; sensor failure, supply-pressure loss on the Pressure Sensor, or temperature excursion escalates to a red audible alarm. The Alarm Battery Backup keeps sensing and alarms alive through a mains failure — the cage cannot heat without power, but it can still summon a human, which is the response that actually matters at 3 a.m. in a ward.
