Wire Drawing Machine Product
Overview
Wire drawing is the fundamental process for reducing the diameter of rod or wire while increasing length and imparting work-hardening and directional strength. A Die Box Assembly holds a series of progressively smaller hardened-steel or tungsten-carbide dies; the wire or rod is pulled through each die in sequence, emerging with reduced diameter and work-hardened properties. Drawing is essential for copper wire (electrical and mechanical), steel wire (springs, cables, fasteners), aluminum wire, and specialty alloys. A drawing machine with an integrated Annealing Furnace can draw and soften the wire in the same pass, enabling large reductions without mechanical breakage.
The process is ancient (dating to medieval Europe) but remains unchanged in principle: the die shapes and works the material as mechanical force pulls it through. Modern machines add precision control, lubrication, and annealing to achieve fine diameters and tight tolerances.
Die box and progression
The Die Box Assembly is a precisely machined ductile-iron or steel block containing 4–8 drawing dies in sequence. Each die is a hardened-steel or tungsten-carbide bushing with a conical inlet (the approach) and a tight cylindrical gauge section. The inlet angle is typically 8–12 degrees; the gauge length is 1.5–3 mm. Wire enters the inlet, is compressed and reshaped by the conical section, then passes through the gauge section where it reaches its final diameter for that stage.
The reduction ratio per stage is typically 1.3–2.5:1 (e.g., 4 mm to 2.5 mm per die). The total reduction from raw rod to final wire can be 3:1 to 10:1 depending on the number of dies and intermediate annealing.
Capstan and pulling force
The Capstan Drum Assembly — typically two large grooved drums — grip the wire and pull it through the dies. The Primary Capstan (upstream) is the main puller, and the Secondary Capstan (downstream) paces and stabilizes the wire exit. Both are driven by independent Capstan Motor units with VFDs, allowing the machine operator to adjust speed ratios and control wire tension.
Drawing force is enormous: pulling a 10 mm rod through a die to 5 mm diameter can require 20–30 tons of tensile force, supported by massive bearings and frames.
Lubrication and die cooling
The Lubrication & Cooling supplies drawing lubricant (a soap-based or synthetic compound) through the Lube Supply Manifold into each die. The lubricant reduces friction, cools the die (which heats from compression), and is filtered by the Lube Filter and circulated by a Lube Pump. Proper lubrication is essential: insufficient lubrication causes wire breakage and rough surfaces; excess causes slipping and loss of control.
Annealing for large reductions
A single draw stage can reduce diameter by 1.3–2.5:1 before the wire becomes too hard and brittle to draw further. For larger total reductions, an intermediate Annealing Furnace is placed between drawing stages. The wire is heated to 600–850 °C (material-dependent) to anneal (soften) it, then cooled before the next draw stage. This heat treatment restores ductility and allows another large reduction.
The Anneal Chamber is a resistively heated or gas-fired furnace tube; the wire travels through slowly at a few meters per minute. The Anneal Temperature Controller maintains temperature, and forced air from the Cooling Air Section section cools the wire post-anneal before it enters the next die.
Tension and speed control
Drawing is a high-tension process, and controlling tension is critical to avoid breakage and ensure uniform properties. The Tension Control System system uses a Tension Sensor (load cell or dancer-arm gauge) to measure wire tension between capstans. A Tension Controller PLC adjusts the speed ratio between Capstan Motor units to maintain constant tension within ±5% of setpoint. Constant-tension drawing produces uniformly work-hardened, consistent-property wire.
Output and finishing
The finished wire exits the final die and is wound onto a Spooler & Winding spindle. A Spooler Brake maintains tension as the spool builds up to 100–500 kg of wire. A Length Counter tracks length or weight for production counting.
For fine wire (< 1 mm), the drawing speed is 200–500 m/min, producing dozens of kilometers of wire per shift. For heavy rod (> 5 mm), speed is slower (50–150 m/min) due to mechanical stress limits.
Materials and applications
Copper wire is the most common: electrical wire (down to 0.1 mm), mechanical spring wire, and control cable all rely on drawing. Steel wire is drawn for springs, fasteners, and tire cords. Aluminum and stainless steel follow similar processes. The drawing process imparts directional strength (the wire is stronger along its length than perpendicular) and can be controlled to achieve precise tensile properties.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labourTap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
8 top-level lines · 35 rows shown · 46 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Die Box Assembly 4 parts | wire-drawing-machine-die-box | 1× | 1 | 14 | assembly |
| 1.1 | Die Block | wire-drawing-machine-die-block | 1× | 1 | — | part |
| 1.2 | Drawing Die | wire-drawing-machine-drawing-die | 6× | 6 | — | part |
| 1.3 | Die Seat | wire-drawing-machine-die-seat | 6× | 6 | — | part |
| 1.4 | Die Alignment Pin | wire-drawing-machine-die-alignment-pin | 1× | 1 | — | part |
| 2 | Capstan Drum Assembly 4 parts | wire-drawing-machine-capstan-drums | 1× | 1 | 10 | assembly |
| 2.1 | Primary Capstan | wire-drawing-machine-primary-capstan | 1× | 1 | — | part |
| 2.2 | Secondary Capstan | wire-drawing-machine-secondary-capstan | 1× | 1 | — | part |
| 2.3 | Capstan Bearing | wire-drawing-machine-capstan-bearing | 6× | 6 | — | part |
| 2.4 | Capstan Motor | wire-drawing-machine-capstan-motor | 2× | 2 | — | part |
| 3 | Annealing Furnace 4 parts | wire-drawing-machine-annealer | 1× | 1 | 5 | assembly |
| 3.1 | Anneal Chamber | wire-drawing-machine-anneal-chamber | 1× | 1 | — | part |
| 3.2 | Anneal Heater | wire-drawing-machine-anneal-element | 2× | 2 | — | part |
| 3.3 | Anneal Temperature Controller | wire-drawing-machine-anneal-controller | 1× | 1 | — | part |
| 3.4 | Cooling Air Section | wire-drawing-machine-anneal-cooling-air | 1× | 1 | — | part |
| 4 | Spooler & Winding 4 parts | wire-drawing-machine-spooler | 1× | 1 | 4 | assembly |
| 4.1 | Spooler Motor | wire-drawing-machine-spooler-motor | 1× | 1 | — | part |
| 4.2 | Spool Drum | wire-drawing-machine-spooler-drum | 1× | 1 | — | part |
| 4.3 | Spooler Brake | wire-drawing-machine-spooler-brake | 1× | 1 | — | part |
| 4.4 | Length Counter | wire-drawing-machine-counter | 1× | 1 | — | part |
| 5 | Lubrication & Cooling 4 parts | wire-drawing-machine-lubrication-system | 1× | 1 | 4 | assembly |
| 5.1 | Lube Pump | wire-drawing-machine-lube-pump | 1× | 1 | — | part |
| 5.2 | Lube Filter | wire-drawing-machine-lube-filter | 1× | 1 | — | part |
| 5.3 | Lube Tank | wire-drawing-machine-lube-tank | 1× | 1 | — | part |
| 5.4 | Lube Supply Manifold | wire-drawing-machine-lube-supply-block | 1× | 1 | — | part |
| 6 | Motor Drive System 2 parts | wire-drawing-machine-drive-motors | 1× | 1 | 4 | assembly |
| 6.1 | Variable-Frequency Drive | wire-drawing-machine-vfd | 2× | 2 | — | part |
| 6.2 | Current Sensor | wire-drawing-machine-current-sensor | 2× | 2 | — | part |
| 7 | Tension Control System 2 parts | wire-drawing-machine-tension-control | 1× | 1 | 2 | assembly |
| 7.1 | Tension Sensor | wire-drawing-machine-tension-sensor | 1× | 1 | — | part |
| 7.2 | Tension Controller | wire-drawing-machine-tension-controller | 1× | 1 | — | part |
| 8 | Machine Frame 3 parts | wire-drawing-machine-frame | 1× | 1 | 3 | assembly |
| 8.1 | Base Frame | wire-drawing-machine-baseframe | 1× | 1 | — | part |
| 8.2 | Die Support Mount | wire-drawing-machine-die-support | 1× | 1 | — | part |
| 8.3 | Fastener Set | fastener-set | 1× | 1 | — | part |
