Automatic Voltage Regulator Product

Overview

An automatic voltage regulator (servo stabilizer) holds its output at 230 V while the incoming mains wanders anywhere from 160 to 270 V. It is the standard defense in regions with weak distribution networks, protecting CNC machines, medical imaging equipment, telecom shelters, and HVAC plants from the slow sags and swells that trip drives and shorten motor life. Unlike a UPS it stores no energy and cannot ride through an outage; its job is purely to correct voltage, which it does continuously, efficiently, and without distorting the waveform.

The architecture has three power elements in series with the load: a motorized Motorized Variac that produces a continuously variable voltage, a Buck-Boost Transformer that injects the correction, and the protection switchgear. A Control Board closes the loop, and a Servo Drive provides the muscle.

How it works

The variac is a toroidal autotransformer: a single Copper Winding laid in one layer around the Toroidal Core, with a band of the winding surface machined bare to form a commutation track. A Carbon Brush pair, pressed onto the track by Coil Springs on the pivoting Brush Arm, taps off a voltage proportional to its angular position — anywhere from zero to about 15% above line voltage, smoothly and without steps.

The variac output does not feed the load directly; at 30 kVA the brush could not carry the current. Instead it drives the primary of the buck-boost transformer, whose secondary is wired in series with the line. Depending on the winding polarity presented by the brush position, the series winding either adds (boosts) or subtracts (bucks) up to roughly ±50 V from the incoming supply. Because the transformer handles only the correction power — about 20% of throughput at worst case — its Buck-Boost Core is far smaller than a full isolation transformer, which is why servo stabilizers exceed 98% efficiency.

Closing the loop, two Sense Transformers feed scaled input and output voltages to the Microcontroller, which computes true-RMS output and compares it against the setpoint. Any error beyond the ±1% deadband energizes one of the direction Relays, running the Servo Motor through its Helical Gear Pair reduction and Drive Coupling to walk the brush toward the null point. Correction speed is 35–50 V/s — a full 160→270 V input excursion is corrected in about two seconds. Limit Switches kill the motor drive at each end of travel so a sensing fault cannot wind the brush off the track.

Protection

Regulation alone is not enough; the unit must also disconnect cleanly when correction is impossible. The Protection & Bypass assembly enforces a configurable cutoff window: if output strays outside 180–260 V despite full brush travel — input collapsed below 160 V, say — the controller drops the Output Contactor, waits for the supply to recover, and reconnects after a 5-second delay to avoid chattering on an unstable feed. The Current Transformer gives the controller load current for a 120%/10-minute overload trip. Three Surge Arrester MOV modules clamp lightning transients, an Input MCB handles bolted faults, and a one-shot Thermal Fuse buried in the buck-boost winding opens if insulation temperature exceeds its Class F limit. For maintenance, the rotary Bypass Switch feeds the load raw mains so brushes can be changed without downtime.

Operation and maintenance

The Display Panel shows input voltage, output voltage, and load current on the LCD Panel; the Membrane Keypad sets the output setpoint, cutoff limits, and reconnect delay. Service items are few and mechanical: the carbon brushes wear at a rate set by how active the local mains is — a site with constant voltage swings keeps the brush sweeping all day — and are inspected yearly, replaced when worn to their marker. The track is cleaned of carbon dust at the same interval, and brush spring pressure checked, since a light brush arcs and pits the winding surface.

The whole assembly — variac, transformer, switchgear — mounts on the welded Chassis Frame behind bolted Sheet Metal Panels, with a Blower Motor fan moving air across the windings and cables entering through compression Cable Glands. Static (electronic tap-changer) regulators correct faster, in 1–2 cycles, with no wearing parts, but the servo type remains dominant above 10 kVA: it is cheaper per kVA, tolerant of inrush and harmonic-rich loads, and adds zero waveform distortion of its own.
