Overview

A chocolate moulding line is a multi-stage system for producing filled or solid pralines at scale. The Chocolate Depositor precisely doses melted chocolate into Mould Conveyor System-mounted moulds. The Vibrating Deaeration Table removes trapped air. The Cooling Tunnel hardens the chocolate, and the Demoulder Machine ejects finished pralines.

Artisanal chocolatiers and larger confectionery manufacturers use moulding lines to achieve consistent praline weight, appearance, and structure. Manual moulding is labor-intensive; a line producing 300–500 pralines/minute is a significant productivity multiplier.

Chocolate depositor and pump system

The Chocolate Depositor starts with a stainless steel tank holding 30–50 L of tempered chocolate. The Gear Pump is a gear pump with very low shear, essential because chocolate is sensitive to mechanical damage (agitation causes viscosity loss and crystallization defects). The pump draws from the tank, forces chocolate through the Nozzle Bank Assembly manifold, and delivers it to the solenoid-controlled nozzles.

Each Nozzle Solenoid Valve is a 24 V DC 3/2 solenoid valve that vents the nozzle cavity pressure to atmosphere when the solenoid is energized, allowing the pump pressure to push chocolate into the mould cavity. When the solenoid closes, flow stops and residual chocolate drains back. The Dispensing Nozzle diameter (typically 1–3 mm) is chosen to deliver the target cavity fill in 0.5–2 seconds.

The Temperature Jacket circulates hot water around the pump and manifold, keeping chocolate at 30–35 °C. Too cold, and it is too viscous to pump; too hot, and it separates or develops bloom. A Circulation Pump recirculates water from an external heater through the jacket and back.

Mould conveyor and pallet system

The Mould Conveyor System is a stainless steel chain conveyor running at variable speed (1–3 m/min). The Mould Carrier Pallet pallets are quick-change platforms, typically holding one cavity sheet of 8–16 moulds. Pallets index continuously or step-and-dwell (stop under the depositor for fill, advance to the next station, etc.).

Synchronization is critical: the depositor solenoids must fire in sync with mould position. The Control & Automation PLC tracks mould position (via a rotary encoder on the conveyor drive) and triggers nozzle valves at the precise moment each cavity aligns under its nozzle.

Some lines use a fixed depositor head and moving moulds; others use a moving nozzle head and fixed moulds. The fixed-depositor design is simpler but requires perfect nozzle-to-cavity alignment.

Vibration and deaeration

The Vibrating Deaeration Table is positioned immediately after the depositor. Freshly deposited chocolate often traps air bubbles; vibration shakes them out. The Vibration Motor is an unbalanced rotor motor that creates oscillation; the Vibrating Deck is typically 1–2 m long and isolated from the factory floor by Isolation Mount so vibration doesn't propagate.

The vibration frequency is tuned: 50–100 Hz typically works for chocolate, high enough to disrupt bubbles without inducing standing waves in the liquid chocolate that would re-entrap air.

Cooling tunnel

The Cooling Tunnel is an insulated chamber where filled moulds pass through a cold air stream, hardening the chocolate. The setpoint is typically 8–12 °C for dark chocolate, 10–15 °C for milk chocolate (to avoid bloom formation). The Refrigeration Unit unit includes a Tunnel Compressor and Evaporator Coil.

The Tunnel Circulation Fan circulates air across the evaporator coil and over the moulds. Air velocity is controlled: too fast causes surface hardening while the interior is still soft (shell cracking and collapse); too slow is inefficient. A typical tunnel is 2–4 m long and moves moulds through in 5–10 minutes at production speed.

Temperature gradients within the tunnel are important: entry zone cool but not frozen; middle zone cold enough to harden the interior; exit zone slightly warmer to even out temperature before demoulding. Temperature profiles are programmable; some lines use multiple zones with independent temperature control.

Demoulder and unload

The Demoulder Machine ejects hardened pralines from moulds. The design depends on the mould type: for polycarb or aluminum trays, a Pusher Plate plate advances under the mould, flexing the tray and popping pralines out; for rigid moulds, an air jet from the back knocks pralines into a collection chute.

The Pneumatic Cylinder is a pneumatic double-acting cylinder providing the push force. Timing is critical: moulds must be cold enough that pralines are set (risk of breakage if pushed too warm) but not so cold that they are brittle and crack on impact.

Automation and control

The Control & Automation is the nervous system. An Programmable Logic Controller reads a rotary encoder on the conveyor drive, calculates mould position, and triggers solenoid valves at precise delays. It also monitors filled cavity volume (some systems use optical or pressure sensors) and can adjust nozzle open time in real time to correct for fill variation.

The Touch HMI HMI allows the operator to set fill time, temperature setpoints, conveyor speed, and cooling time. Recipes are stored in memory so the operator can recall, say, "praline-type-A" and the line automatically configures all parameters.

Safety interlocks are essential: if a mould is missing or damaged, the line should not deposit (causing spill). If the cooling tunnel temperature drifts, an alarm sounds. If demoulder pressure exceeds a threshold (indicating a jam), the line stops.

Filling accuracy and quality

Depositor repeatability is typically ±2–3% of target fill, limited by nozzle flow variability and mould temperature variation. Better systems use weight scales or video inspection to verify fill weight, flag over/under-fill, and reduce waste.

Bloom (gray-white streaks) is a common defect in chocolate, caused by cocoa butter crystal migration. A slow cooling rate and stable final temperature (27–28 °C) minimize bloom. Some lines include a post-cooler that slowly warms moulds to room temperature before demoulding.

Praline appearance is influenced by depositor dwell time (longer dwell allows air to escape but risks overflow), mould cleanliness (dust or previous chocolate residue mars the surface), and demoulder gentleness (rough ejection breaks thin shells or creates flat spots).

Maintenance

Daily: Nozzles are flushed with warm chocolate or a specified solvent to prevent hardening. The demoulder is inspected for residual chocolate or metal shavings. The cooling tunnel temperature is confirmed.

Weekly: Moulds are inspected for damage; cracked trays are replaced. The chain conveyor is checked for slack and adjusted if needed. The chocolate-moulding-pumping-motor is checked for unusual noise.

Monthly: The cooling unit condenser is cleaned of chocolate dust (which insulates and reduces efficiency). Thermostat calibration is verified; if tunnel temperature is off by more than 1 °C, the sensor may need replacement.

Annually: The Gear Pump is inspected for wear; gears may show minor scoring after extended runs, but major damage requires replacement. Refrigerant charge is checked and topped up if there are any leaks.
