DAF System
ProductOverview
Dissolved air flotation (DAF) is a clarification process that removes suspended solids, oils, fats, algae, and colloidal matter by attaching fine gas bubbles to particles, causing them to float to the surface for removal. Unlike conventional settling which relies on particle density to achieve separation, DAF exploits buoyancy, making it ideal for low-density or colloidal materials unsuitable for gravity settling.
The core principle is Henry's Law: compressed air dissolves into water at pressure, releasing as micro-bubbles when pressure drops. A Saturation Vessel maintains 4–6 bar absolute pressure, dissolving 35–50 mg/L air. Saturated water is then released into the main Flotation Tank where rapid decompression nucleates bubbles (20–100 μm diameter). These bubbles attach to flocculated solids, forming aggregates less dense than water that rise to the surface in minutes.
Performance depends on three factors: coagulation (destabilizing colloids), flocculation (growing micro-flocs), and flotation (attaching bubbles). A DAF system typically removes 80–95% of suspended solids and 60–80% of oils/grease when properly operated.
Process Chemistry
Coagulation destabilizes colloids via charge neutralization. Common coagulants:
- Aluminum salts (alum, PAC): 5–30 mg/L, optimal pH 6–8, produces aluminum hydroxide micro-precipitate
- Iron salts (ferric chloride, ferrous sulfate): 10–40 mg/L, optimal pH 7–9
Flocculation follows: polyelectrolytes (anionic or cationic PAM) at 0.1–1 mg/L bridge coagulated particles into larger aggregates (0.1–1 mm). The resulting floc is loosely bonded and easily attached to bubbles.
Henry's Law governs air dissolution: C_air = k_H × P_air
Where k_H = solubility coefficient (~0.0058 mol/(L·atm) at 20°C), P_air = partial pressure. At 4 bar gauge (5 bar absolute): C_air = 0.0058 × 5 = 0.029 mol/L ≈ 45 mg/L
When released to atmospheric pressure (1 bar), the air precipitates as bubbles.
Saturation Vessel Operation
The Saturation Vessel holds recycled effluent at 4–6 bar for 1–5 minutes. Residence time formula: t = V / Q_recycle
For a 1 m³ vessel with 10 m³/h recycle flow: t = (1 × 60) / 10 = 6 minutes
Air injection occurs continuously via a bubble stone, introducing 1–2 m³/min compressed air. Pressure is maintained by a relief valve set to 5 bar.
The saturation tank must be sized generously: excessive pressure drop or short residence time results in incomplete air dissolution, reducing bubble yield in the flotation tank.
Flotation Tank Dynamics
Saturated water enters the Flotation Tank through a depressurization valve. As pressure drops to atmospheric, dissolved air nucleates into 20–100 μm bubbles. The bubble count depends on air concentration and nucleation efficiency; typical yield is 10⁷–10⁹ bubbles per liter.
Bubble attachment to floc particles is governed by particle size, bubble size, and floc density. Optimal performance occurs with particle size 50–500 μm and bubble size 20–100 μm. Floc density should be slightly greater than water (density difference: 0.5–2% of water density) to ensure gentle rise without shearing.
The Baffle Wall divides the flotation tank into inlet and flotation zones, ensuring even distribution and preventing short-circuiting. The flotation zone has upflow velocity of 0.5–1.0 m/h, allowing 15–25 minutes residence. At this rate, floc-bubble aggregates rise at 0.5–2 m/h (depending on density and bubble attachment strength) and reach the surface for removal by the Skimmer.
The Skimmer operates at 0.2–2 rpm, continuously raking foam and float sludge into a discharge hopper. Settled sludge in the Sludge Hopper is withdrawn periodically via a Hopper Discharge Valve.
Recycle Ratio and Energy Balance
The recycle pump recirculates 10–30% of the clarified effluent through the saturation vessel. Higher recycle ratios produce more bubbles but increase energy consumption. A typical balance:
- 10% recycle: Low bubble yield, minimal power (3–5 kW), suitable for low-turbidity inlet
- 20% recycle: Standard operation, moderate power (5–10 kW), removal 85–90%
- 30% recycle: High bubble yield, increased power (10–15 kW), removal 90–95%
The Recycle Pump System is typically a gear pump or positive-displacement centrifugal pump delivering recycle flow at pump discharge pressure minus pressure drop through the saturation vessel (typically 0.5–1.5 bar).
Sludge Characteristics
Float sludge from the DAF is typically 3–5% solids by weight, much finer than gravity-settled sludge. It contains primarily coagulant hydroxide precipitate, flocculated colloids, and attached micro-bubbles. Float sludge often requires thickening (via dissolved-air flotation, gravity thickening, or centrifugal thickening) before dewatering via Belt Filter Press or Sludge Screw Press.
Typical Applications
- Food and Beverage: Removal of suspended solids, fats, oils from dairy, meat, or vegetable processing wastewater
- Pulp and Paper: Clarification of white water and paper machine effluent
- Oily Water: Tank-truck wash, truck stop, or petroleum facility wastewater (removal of oils and grease to <10 mg/L)
- Algae Removal: Secondary clarifier or polishing stage to remove algal cells
- Combined Sewer Overflow (CSO): Emergency or stormwater treatment removing grit and floatables
Advantages
- Low Footprint: 0.3–1.0 m² per m³/day, 1.5–2.0 m deep (vs. 1.5–3.0 m² for gravity clarifier)
- Fast Startup: No sludge bed development; full capacity in hours
- Handling Low-Density Solids: Algae, fibers, fats that don't settle in clarifiers
- Robust to Shock Loads: Brief overdoses of oil or grease don't cause clarifier upset
Limitations
- Chemical Dependency: Requires coagulant dosing; suboptimal dosing reduces efficiency
- Air Bubble Loss: Bubble coalescence or escape reduces effective bubble count
- Float Sludge Volume: Higher solids concentration than gravity-settled sludge; requires follow-on thickening
- Power Consumption: Compressor and recycle pump typically 10–30 kW continuous
Operational Checklist
| Task | Frequency |
|---|---|
| Verify saturation pressure 4–6 bar | Continuous (automated) |
| Check float sludge discharge | Daily |
| Inspect skimmer blade for wear | Weekly |
| Sample outlet clarity and settle test | Weekly |
| Adjust coagulant dose for turbidity | As needed (daily in variable loads) |
| Empty settled sludge from bottom hopper | Weekly–Monthly |
| Replace air compressor intake filter | Monthly |
| Inspect recycle pump and strainer | Monthly |
| Calibrate level transmitter | Quarterly |
Standards
- AWWA Standard B200: Filtration and Clarification
- EPA Design Manual: Fine Pore Aeration Systems
- EN 12255-8: Flotation equipment
DAF System parts and their functions
8 top-level parts · 41 parts in total · full bill of materials below| # | Part | Qty | What it does |
|---|---|---|---|
| 1 | Saturation Vessel 5 parts | 1× | High-pressure air contact and water saturation chamber |
| 2 | Flotation Tank 5 parts | 1× | Main treatment basin with rising sludge removal |
| 3 | Air Supply System 5 parts | 1× | Compressor and air injection system |
| 4 | Recycle Pump System 5 parts | 1× | Pressurized water recycle from effluent |
| 5 | Skimmer 4 parts | 1× | Surface foam and sludge collection mechanism |
| 6 | Effluent Control 3 parts | 1× | Underflow outlet and flow control |
| 7 | Chemical Dosing 5 parts | 1× | Coagulant and flocculant injection |
| 8 | Control System 7 parts | 1× | Flow, pressure, and sludge level automation |
3D model
No 3D model yet. Have a CAD file of this? Add a 3D model. STL renders right on this page; STEP, FreeCAD, and OpenSCAD sources are welcome too (openly licensed, like all 3D models on BOMwiki).
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labourTap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials for DAF System
8 top-level lines · 47 rows shown · 41 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Saturation Vessel 5 parts | dissolved-air-flotation-saturation-vessel | 1× | 1 | 6 | assembly |
| 1.1 | Saturation Tank | dissolved-air-flotation-saturation-tank | 1× | 1 | · | part |
| 1.2 | Air Injection Point | dissolved-air-flotation-air-injection | 1× | 1 | · | part |
| 1.3 | Pressure Relief Valve | dissolved-air-flotation-pressure-valve | 1× | 1 | · | part |
| 1.4 | Pressure Sensor | pressure-sensor | 2× | 2 | · | part |
| 1.5 | Isolation Valve | dissolved-air-flotation-isolation-valve | 1× | 1 | · | part |
| 2 | Flotation Tank 5 parts | dissolved-air-flotation-flotation-tank | 1× | 1 | 5 | assembly |
| 2.1 | Treatment Basin | dissolved-air-flotation-basin | 1× | 1 | · | part |
| 2.2 | Inlet Diffuser | dissolved-air-flotation-inlet-diffuser | 1× | 1 | · | part |
| 2.3 | Baffle Wall | dissolved-air-flotation-baffle-wall | 1× | 1 | · | part |
| 2.4 | Settling Zone | dissolved-air-flotation-settling-zone | 1× | 1 | · | part |
| 2.5 | Sludge Hopper | dissolved-air-flotation-sludge-hopper | 1× | 1 | · | part |
| 3 | Air Supply System 5 parts | dissolved-air-flotation-air-supply | 1× | 1 | 5 | assembly |
| 3.1 | Blower Motor | blower-motor | 1× | 1 | · | part |
| 3.2 | Air Compressor | dissolved-air-flotation-air-compressor | 1× | 1 | · | part |
| 3.3 | Air Filter | dissolved-air-flotation-air-filter | 1× | 1 | · | part |
| 3.4 | Air Dryer | dissolved-air-flotation-dryer | 1× | 1 | · | part |
| 3.5 | Check Valve | dissolved-air-flotation-check-valve | 1× | 1 | · | part |
| 4 | Recycle Pump System 5 parts | dissolved-air-flotation-recycle-pump | 1× | 1 | 5 | assembly |
| 4.1 | Recycle Pump | dissolved-air-flotation-centrifugal-pump | 1× | 1 | · | part |
| 4.2 | Blower Motor | blower-motor | 1× | 1 | · | part |
| 4.3 | Suction Strainer | dissolved-air-flotation-suction-strainer | 1× | 1 | · | part |
| 4.4 | Discharge Check Valve | dissolved-air-flotation-discharge-valve | 1× | 1 | · | part |
| 4.5 | Pressure Sensor | pressure-sensor | 1× | 1 | · | part |
| 5 | Skimmer 4 parts | dissolved-air-flotation-skimmer | 1× | 1 | 4 | assembly |
| 5.1 | Skimmer Blade | dissolved-air-flotation-skimmer-blade | 1× | 1 | · | part |
| 5.2 | Skimmer Drive | dissolved-air-flotation-skimmer-drive | 1× | 1 | · | part |
| 5.3 | Float Hopper | dissolved-air-flotation-sludge-hopper-top | 1× | 1 | · | part |
| 5.4 | Hopper Discharge Valve | dissolved-air-flotation-hopper-valve | 1× | 1 | · | part |
| 6 | Effluent Control 3 parts | dissolved-air-flotation-effluent-valve | 1× | 1 | 3 | assembly |
| 6.1 | Weir Edge | dissolved-air-flotation-weir-edge | 1× | 1 | · | part |
| 6.2 | Outlet Pipe | dissolved-air-flotation-outlet-pipe | 1× | 1 | · | part |
| 6.3 | Level Sensor | dissolved-air-flotation-level-sensor | 1× | 1 | · | part |
| 7 | Chemical Dosing 5 parts | dissolved-air-flotation-chemical-dosing | 1× | 1 | 5 | assembly |
| 7.1 | Coagulant Tank | dissolved-air-flotation-coagulant-tank | 1× | 1 | · | part |
| 7.2 | Coagulant Pump | dissolved-air-flotation-coagulant-pump | 1× | 1 | · | part |
| 7.3 | Floc Tank | dissolved-air-flotation-floc-tank | 1× | 1 | · | part |
| 7.4 | Floc Pump | dissolved-air-flotation-floc-pump | 1× | 1 | · | part |
| 7.5 | Static Mixer | dissolved-air-flotation-static-mixer | 1× | 1 | · | part |
| 8 | Control System 7 parts | dissolved-air-flotation-control-system | 1× | 1 | 8 | assembly |
| 8.1 | Microcontroller | mcu | 1× | 1 | · | part |
| 8.2 | Bare PCB | pcb-bare | 1× | 1 | · | part |
| 8.3 | Pressure Transducer | dissolved-air-flotation-pressure-transducer | 1× | 1 | · | part |
| 8.4 | Level Transducer | dissolved-air-flotation-level-transducer | 1× | 1 | · | part |
| 8.5 | Flow Meter | dissolved-air-flotation-flow-meter | 1× | 1 | · | part |
| 8.6 | LCD Panel | lcd-panel | 1× | 1 | · | part |
| 8.7 | Relay | relay | 2× | 2 | · | part |
