Hydrogen Dispenser Product

Overview

A hydrogen refueling dispenser is the final station component delivering high-pressure, precooled hydrogen gas from a storage buffer or on-site generation system into fuel cell vehicle (FCV) tanks. Modern dispensers operate at 350 bar (SAE J2601 current standard) or 700 bar (emerging ISO 14687 standard to reduce refueling time and increase vehicle range). The dispenser combines a high-pressure compressor, cryogenic or evaporative cooler, precision metering block, redundant safety relief system, and automated control logic to safely and efficiently meter the exact mass of hydrogen each vehicle requires in 3–5 minutes.

Cooling is critical because high-pressure hydrogen gas naturally heats during adiabatic compression; dispensing gas at –20 to –40 °C maximizes the quantity of hydrogen molecules delivered per unit volume, allowing vehicle tanks to be smaller or store more energy at the same tank volume.

How it works

Multi-Stage Compression

The Compressor Unit steps inlet hydrogen (typically 5–10 bar from storage) to final delivery pressure (350–700 bar) in 2–3 stages. A Compressor Motor (10–50 kW electric) drives either a reciprocating piston compressor or screw element. Between each stage, a Intercooler rejects compression work heat to minimize power consumption and reduce final outlet temperature.

$$P_\text{outlet} = P_\text{inlet} \times \Pi_\text{stage}^n$$

where n = number of stages and $\Pi_\text{stage}$ = pressure ratio per stage (typically 3–5:1 for reciprocating, up to 8:1 for screw). The Valve Block integrates inlet and discharge check valves preventing backflow and a relief valve protecting against overpressure during compressor shutdown.

Cryogenic Precooling

Hydrogen exiting the compressor is warm (80–120 °C) due to polytropic compression. The Cooler Skid cools it to –20 to –40 °C before metering. The Chiller Unit circulates hydrofluoroolefin (HFO-1234ze) or similar refrigerant through a Cooler Core aluminum or stainless plate-fin heat exchanger. The Temperature Controller modulates the chiller compressor or expansion valve to maintain outlet set-point, typically –35 °C.

Cold hydrogen is routed through Coldbox Insulation vacuum-jacketed or foam-insulated piping to the Metering Block, minimizing reheating.

Precision Metering and Control

The Metering Block contains a Pressure Regulator that pilots down from 350–700 bar to ~50 bar (the metering pressure). A Flow Meter (turbine or oval-gear type) measures mass flow in real time, integrating flow over time to yield total dispensed mass in kilograms.

When a vehicle nozzle connects via Hose Assembly and SAE J2601 coupling, the Control Cabinet (PLC + analog conditioning) begins a fill sequence:

1. Pre-pressurization: Ramp inlet pressure from 0 to ~50 bar at a controlled rate (e.g., 1 bar/second) to minimize thermal shock to the vehicle tank.
2. Flow phase: Open the Final Shutoff solenoid valve and allow hydrogen to flow into the vehicle at constant mass rate (e.g., 0.3 kg/min).
3. Back-pressure detection: As the vehicle tank fills, back-pressure rises. The dispenser modulates compressor speed via the VFD Drive to maintain constant outlet pressure (~350 bar) and thus constant drive (pressure difference) across the metering valve.
4. Termination: When vehicle tank reaches setpoint (e.g., 5.0 kg total dispensed), the PLC closes the Final Shutoff and signals end-of-fill.

Safety Systems

The Safety Manifold provides dual-redundant overpressure protection:

• Primary relief: Relief Valve (Primary), a pilot-operated cartridge set at 700–750 bar, vents hydrogen to atmosphere or a collection tank.
• Secondary relief: Relief Valve (Secondary), a direct-acting spring-loaded valve at 750–800 bar, acts as independent backup.

Additionally, the Back-Check Valve in the nozzle body prevents hydrogen backflow during vehicle disconnect. If a vehicle pulls away while the hose is still connected, the Breakaway Coupling automatically separates the nozzle from hose, isolating both sides.

Vehicle-Side Interface

The Hose Assembly consists of EN 286 4SP–rated Hose Line (700 bar working pressure), swaged JIC fittings, and a Nozzle Body compliant with SAE J2601 (350 bar) or ISO 14687 (700 bar) standards. Hydrogen enters the vehicle PEM Electrolyzer Stack or storage tank through the vehicle's on-board pressure regulator and check valve assembly.

Control and Monitoring

The Control Cabinet logs each fill: start time, end time, mass dispensed, peak pressure, and outlet temperature. Over-pressure, over-temperature, or disconnection events trigger alarms or fail-safe shutdown. The PLC Module executes fill algorithms optimized for the specific vehicle type (SAE J2601 vs. ISO 14687) via VFD modulation of compressor motor speed and solenoid valve timing.

Energy Efficiency

Typical compressor work = 0.8–1.2 kWh per kg of H₂ delivered, depending on compression ratio, intercooling effectiveness, and motor efficiency. At 90% motor efficiency and 80% compressor isentropic efficiency, dispensing 5 kg of hydrogen (25 kWh energy content) requires ~5–6 kWh of electrical input, for a round-trip well-to-tank efficiency of ~80%.
