Portable Inverter Generator Product
Overview
A portable inverter generator solves the central defect of the conventional portable genset: a direct-coupled alternator must spin at exactly 3000 rpm to make 50 Hz, regardless of whether the load is a 40 W lamp or a 1.8 kW heater, so the engine roars at full speed all day and the output frequency wobbles with every load change. The inverter architecture breaks that link. The Alternator generates "wild" AC at whatever frequency the engine happens to turn; the Inverter Module rectifies it to DC and synthesizes a fresh 230 V 50 Hz sine wave electronically. Engine speed becomes a free variable, governed purely by power demand — idling near 2600 rpm under light load, climbing to 5000 rpm only when needed.
The practical results are why these units dominate camping, food trucks, film sets, and backup power for homes: half the fuel burn at partial load, 52–58 dB(A) instead of 70+, a 21 kg one-hand carry, and output clean enough (THD below 3%) for laptops, CPAP machines, and audio gear that a conventional generator's waveform can damage.
How it works
The prime mover is a 79 cc OHV four-stroke in the Engine assembly: a die-cast Crankcase with splash lubrication, Piston Assembly, pushrod valvetrain off the Camshaft, and a float-bowl Carburetor whose throttle is positioned by a stepper under inverter command — this is the eco-throttle governor. Ignition is a maintenance-free transistorized magneto: magnets in the Flywheel sweep past the Ignition Coil each revolution.
Bolted to the crankshaft taper, the alternator is an outer-rotor permanent-magnet machine: twelve Neodymium Magnet poles on the Rotor Assembly spinning around a compact wound Stator Assembly. At 5000 rpm a 12-pole machine generates around 500 Hz — far off grid frequency, which is irrelevant since the output goes straight to rectification. The same rotor carries the Cooling Fan Impeller, which pulls air through the Air Intake Duct, across the Inverter Heatsink and cylinder fins, and out past the muffler.
In the inverter module, Power MOSFET rectifier stages charge the DC Bus Capacitor DC link, and an H-bridge of further MOSFETs chops that DC at around 20 kHz under control of the Microcontroller. The Output Filter Choke filters the PWM into a smooth sine. The same microcontroller runs the whole machine: it measures load power, commands the carburetor stepper to hold the lowest engine speed that sustains the DC bus, trips on overload or low oil, and drives the LCD Panel readout of output watts, runtime, and fuel level.
Fuel, exhaust, and noise
The gravity-fed Fuel System holds 4 litres in a tank moulded into the enclosure top, flowing through a Fuel Petcock and Fuel Filter to the carburetor; the vented Fuel Cap closes its air bleed for spill-free transport. At 25% load in eco mode the engine sips roughly 0.5 L/h, stretching the tank to 8 hours.
Noise control is the product's defining engineering. The Housing is a polypropylene clamshell of two foam-lined Shell Half mouldings; cooling air enters through a labyrinth duct that blocks line-of-sight noise paths, and the engine sits on isolating mounts above Rubber Foot pads. Exhaust passes through the two-chamber Muffler and a mesh Spark Arrestor (mandatory in many forestry jurisdictions), with a Heat Shield protecting the plastic shell. The combination, plus the low eco-throttle engine speed, is what gets a combustion engine down to conversation-level 52 dB(A).
Operation
Starting is manual: the Recoil Starter spins the crank through centrifugal Starter Pawls, with a Coil Spring rewinding the Recoil Reel after each pull. The Main Switch combines ignition, fuel, and choke in one rotary control. Loads plug into two breaker-protected Outlet Receptacles or the USB Ports.
When 1.8 kW is not enough, the Parallel Port links two units: their inverters synchronize digitally and share load, delivering 3.6 kW combined — a capability impossible for conventional generators, whose mechanical governors cannot hold two engines in phase. Routine service is engine-side only: oil changes every 50–100 hours through the Maintenance Cover, plus spark plug, air filter, and valve-lash checks; the power electronics are sealed and unserviceable.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labourTap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
8 top-level lines · 62 rows shown · 96 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Engine 8 parts | inverter-generator-engine | 1× | 1 | 9 | assembly |
| 1.1 | Crankcase | inverter-generator-crankcase | 1× | 1 | — | part |
| 1.2 | Piston Assembly | inverter-generator-piston-assembly | 1× | 1 | — | part |
| 1.3 | Cylinder Head | inverter-generator-cylinder-head | 1× | 1 | — | part |
| 1.4 | Camshaft | inverter-generator-camshaft | 1× | 1 | — | part |
| 1.5 | Carburetor | inverter-generator-carburetor | 1× | 1 | — | part |
| 1.6 | Flywheel | inverter-generator-flywheel | 1× | 1 | — | part |
| 1.7 | Ignition Coil | inverter-generator-ignition-coil | 1× | 1 | — | part |
| 1.8 | Oil Seal | oil-seal | 2× | 2 | — | part |
| 2 | Alternator 5 parts | inverter-generator-alternator | 1× | 1 | 36 | assembly |
| 2.1 | Stator Assembly 3 parts | stator-assembly | 1× | 1 | 3 | assembly |
| 2.1.1 | Stator Core (laminations) | stator-core | 1× | 1 | — | part |
| 2.1.2 | Copper Winding | copper-winding | 1× | 1 | — | part |
| 2.1.3 | Slot Insulation | stator-insulation | 1× | 1 | — | part |
| 2.2 | Rotor Assembly 4 parts | rotor-assembly | 1× | 1 | 19 | assembly |
| 2.2.1 | Rotor Shaft | rotor-shaft | 1× | 1 | — | part |
| 2.2.2 | Rotor Core | rotor-core | 1× | 1 | — | part |
| 2.2.3 | Neodymium Magnet | neodymium-magnet | 16× | 16 | — | part |
| 2.2.4 | Ball Bearing | ball-bearing | 1× | 1 | — | part |
| 2.3 | Neodymium Magnet | neodymium-magnet | 12× | 12 | — | part |
| 2.4 | Ball Bearing | ball-bearing | 1× | 1 | — | part |
| 2.5 | Cooling Fan Impeller | inverter-generator-cooling-fan-impeller | 1× | 1 | — | part |
| 3 | Inverter Module 7 parts | inverter-generator-inverter-module | 1× | 1 | 17 | assembly |
| 3.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 3.2 | Power MOSFET | mosfet | 8× | 8 | — | part |
| 3.3 | Microcontroller | mcu | 1× | 1 | — | part |
| 3.4 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 3.5 | DC Bus Capacitor | inverter-generator-bus-capacitor | 4× | 4 | — | part |
| 3.6 | Output Filter Choke | inverter-generator-output-choke | 1× | 1 | — | part |
| 3.7 | Inverter Heatsink | inverter-generator-inverter-heatsink | 1× | 1 | — | part |
| 4 | Fuel System 6 parts | inverter-generator-fuel-system | 1× | 1 | 6 | assembly |
| 4.1 | Fuel Tank | inverter-generator-fuel-tank | 1× | 1 | — | part |
| 4.2 | Fuel Cap | inverter-generator-fuel-cap | 1× | 1 | — | part |
| 4.3 | Fuel Petcock | inverter-generator-fuel-petcock | 1× | 1 | — | part |
| 4.4 | Fuel Line | inverter-generator-fuel-line | 1× | 1 | — | part |
| 4.5 | Fuel Filter | inverter-generator-fuel-filter | 1× | 1 | — | part |
| 4.6 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 5 | Exhaust System 4 parts | inverter-generator-exhaust-system | 1× | 1 | 4 | assembly |
| 5.1 | Muffler | inverter-generator-muffler | 1× | 1 | — | part |
| 5.2 | Spark Arrestor | inverter-generator-spark-arrestor | 1× | 1 | — | part |
| 5.3 | Exhaust Gasket | inverter-generator-exhaust-gasket | 1× | 1 | — | part |
| 5.4 | Heat Shield | inverter-generator-heat-shield | 1× | 1 | — | part |
| 6 | Control Panel 6 parts | inverter-generator-control-panel | 1× | 1 | 8 | assembly |
| 6.1 | Outlet Receptacle | inverter-generator-outlet-receptacle | 2× | 2 | — | part |
| 6.2 | USB Port | inverter-generator-usb-port | 2× | 2 | — | part |
| 6.3 | Main Switch | inverter-generator-main-switch | 1× | 1 | — | part |
| 6.4 | Parallel Port | inverter-generator-parallel-port | 1× | 1 | — | part |
| 6.5 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 6.6 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 7 | Recoil Starter 5 parts | inverter-generator-recoil-starter | 1× | 1 | 6 | assembly |
| 7.1 | Recoil Reel | inverter-generator-recoil-reel | 1× | 1 | — | part |
| 7.2 | Recoil Rope | inverter-generator-recoil-rope | 1× | 1 | — | part |
| 7.3 | Coil Spring | coil-spring | 1× | 1 | — | part |
| 7.4 | Starter Pawl | inverter-generator-starter-pawl | 2× | 2 | — | part |
| 7.5 | Recoil Handle | inverter-generator-recoil-handle | 1× | 1 | — | part |
| 8 | Housing 6 parts | inverter-generator-housing | 1× | 1 | 10 | assembly |
| 8.1 | Shell Half | inverter-generator-shell-half | 2× | 2 | — | part |
| 8.2 | Carry Handle | inverter-generator-carry-handle | 1× | 1 | — | part |
| 8.3 | Rubber Foot | inverter-generator-rubber-foot | 4× | 4 | — | part |
| 8.4 | Maintenance Cover | inverter-generator-maintenance-cover | 1× | 1 | — | part |
| 8.5 | Air Intake Duct | inverter-generator-air-intake-duct | 1× | 1 | — | part |
| 8.6 | Fastener Set | fastener-set | 1× | 1 | — | part |
