Thickness Planer Product

Overview

A thickness planer brings a board to a precise, uniform thickness with two parallel flat faces. The operator sets the head height to a hair below the current thickness, switches on, and pushes the board into the in-feed side; powered rollers take over, pull it under a spinning knife drum, and a thin shaving lifts off the top face. Each pass lowers the head a little more until the board reaches the target. Unlike a jointer, the planer references the bottom face against a flat bed, so it controls thickness rather than flatness.

This is a benchtop unit that planes stock up to 330 mm wide. The Thickness Planer is built around the Base & Frame, a folded steel frame whose guide rails carry the cutterhead carriage. The board rides across the Bed Table, a machined cast surface with fold-down wings that support long stock. The Height-Adjust Column lead screws, turned together by the Depth Handwheel, raise and lower the whole head to set the depth of cut, and the Chip Ejection Hood hood channels the heavy stream of shavings to an extractor.

How it works

Power from the Switch & Control Board runs the Universal Motor, a high-speed universal motor. A belt off its shaft spins the Knife Cutterhead — a balanced steel drum holding three high-speed-steel knives — at around 10,000 rpm. The knives sweep in an arc; because the head turns far faster than the board moves, each knife takes many small bites per centimetre, leaving a smooth surface measured as cuts per inch.

Feeding is automatic. A second reduction off the motor drives the Feed Roller Set: a serrated steel in-feed roller bites the rough top and pulls the board in, while a smooth rubber out-feed roller carries the finished board clear without bruising it. Spring pressure holds both rollers down on stock of varying thickness. The roller speed sets the feed rate, and a two-speed gearing trades feed rate against finish — slow for a glass-smooth final pass, fast for hogging.

To set thickness, the operator winds the handwheel. Both Height-Adjust Column screws turn in step, lifting or dropping the cutterhead carriage along the base rails while the bed stays fixed, so the gap between knives and bed equals the finished thickness. Anti-snipe design and the supported bed keep the cut even from end to end. Shavings thrown forward by the knives hit the chip hood and exit the dust port, where loss of extraction would quickly bury the machine.

Build & assembly graph

expand / collapse · shared sub-assemblies converge · links to related products · est. labour
product / assembly shared across products atomic part related product

Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.

Bill of materials

11 top-level lines · 54 rows shown · 79 parts total · indented to 3 levels
# Item / sub-assembly Part no. Qty/assy Ext. qty Parts Type
1 Base & Frame 3 parts planer-base 1 4 assembly
1.1 Base Pan planer-base-pan 1 part
1.2 Column Guide Rail planer-column-rail 2 part
1.3 Fastener Set fastener-set 1 part
2 Bed Table 3 parts planer-bed-table 1 5 assembly
2.1 Bed Casting planer-bed-casting 1 part
2.2 Extension Wing planer-extension-wing 2 part
2.3 Bed Roller planer-bed-roller 2 part
3 Knife Cutterhead 5 parts planer-cutterhead 1 10 assembly
3.1 Cutterhead Drum planer-head-drum 1 part
3.2 HSS Planer Knife planer-knife 3 part
3.3 Knife Gib planer-gib 3 part
3.4 Ball Bearing ball-bearing 2 part
3.5 Cutterhead Pulley planer-head-pulley 1 part
4 Universal Motor 7 parts planer-motor 1 30 assembly
4.1 Stator Assembly 3 parts stator-assembly 1 3 assembly
4.1.1 Stator Core (laminations) stator-core 1 part
4.1.2 Copper Winding copper-winding 1 part
4.1.3 Slot Insulation stator-insulation 1 part
4.2 Rotor Assembly 4 parts rotor-assembly 1 19 assembly
4.2.1 Rotor Shaft rotor-shaft 1 part
4.2.2 Rotor Core rotor-core 1 part
4.2.3 Neodymium Magnet neodymium-magnet 16× 16 part
4.2.4 Ball Bearing ball-bearing 1 part
4.3 Copper Winding copper-winding 2 part
4.4 Motor Housing motor-housing 1 part
4.5 Ball Bearing ball-bearing 2 part
4.6 Carbon Brush planer-carbon-brush 2 part
4.7 Drive Belt drive-belt 1 part
5 Feed Roller Set 6 parts planer-feed-rollers 1 10 assembly
5.1 In-feed Roller planer-infeed-roller 1 part
5.2 Out-feed Roller planer-outfeed-roller 1 part
5.3 Helical Gear Pair gear-pair 1 part
5.4 Drive Belt drive-belt 1 part
5.5 Roller Pressure Spring 1 parts planer-roller-spring 2 part
5.5.1 Coil Spring coil-spring 2 part
5.6 Ball Bearing ball-bearing 4 part
6 Height-Adjust Column 3 parts planer-height-column 2 3 assembly
6.1 Ball Screw ball-screw 2 part
6.2 Lift Nut planer-lift-nut 2 part
6.3 Coil Spring coil-spring 2 part
7 Depth Handwheel planer-handwheel 1 part
8 Chip Ejection Hood 2 parts planer-dust-port 1 2 assembly
8.1 Chip Hood planer-chip-hood 1 part
8.2 Dust Spout planer-dust-spout 1 part
9 Switch & Control Board 3 parts planer-switch-board 1 5 assembly
9.1 On/Off Switch planer-onoff-switch 1 part
9.2 Bare PCB pcb-bare 1 part
9.3 Connector connector 3 part
10 Power Cord & Wiring 3 parts planer-power-cord 1 4 assembly
10.1 Mains Cord planer-cord 1 part
10.2 Wire Bundle wire-bundle 1 part
10.3 Connector connector 2 part
11 Fastener Set fastener-set 2 part
