Overview
A fibreglass water slide is a gravity ride lubricated by a thin pumped film of water. Riders climb the Access Stair Tower to a start platform 10-18 m up, sit into a flooded entry, and descend a continuous fibreglass channel — the Flume Run — carried on a galvanised Support Structure, reaching 20-40 km/h before the Splash Pool Interface brings them to rest. The water is not decoration: without the film fed by the Water Pump System, skin against dry gel coat has far too much friction (and produces burns), so water flow is a safety interlock, not an amenity. EN 1069 in Europe and ASTM F2376 in North America govern design, flow rates, and rider spacing.
Flume construction
The flume is assembled from factory-moulded sections roughly 2-3 m long: Straight Section runs, superelevated Curve Section bends, and Helix Section spiral segments. Each is a glass-reinforced polyester laminate 6-10 mm thick, laid (or vacuum-infused) against a polished mould so the ride surface is a smooth pigmented gel coat. Sections meet at moulded-in Joint Flange rims, bolted with stainless hardware from a Fastener Set through a compressible Joint Gasket. The joint is the critical detail of the whole product: any step, gap, or proud bolt head on the ride surface at 30 km/h lacerates skin, so flanges register the sections flush and standards limit surface misalignment at joints to fractions of a millimetre. Erection crews shim each joint at its Saddle Cradle until a hand drawn along the seam feels nothing.
Geometry does the ride design. Banked curves are superelevated so the resultant of gravity and centripetal acceleration stays inside the channel — open flumes rely on this entirely, since nothing else holds the rider in. Designers control speed by alternating steep drops with flatter sections and friction-rich curves; an average slope around 10-14% gives a family body slide, while speed slides run much steeper and finish in long run-outs.
Structure
The steelwork is a column-and-cradle system: hot-dip galvanised Support Column posts on Footing Anchor bolts cast into concrete footings, with Diagonal Brace members stiffening the grid. Cradles sit under the flume at the joints, where the flanges double as structural ribs. Loads are modest but dynamic — a rider plus water wave is a moving point load — and the controlling cases are usually wind on the empty flume and the helix's eccentric dead load rather than the riders themselves. Galvanising matters because the whole structure lives in chlorinated splash and spray.
Water system
A 15-40 kW Circulation Pump draws from the Surge Tank through a Suction Strainer and lifts 50-150 m³/h up the tower through a PVC Riser Pipe. Most of the flow enters at the Start Tub Feed, a weir box that floods the first section; Spray Nozzle fittings re-wet the surface partway down where the film thins out. Balance Valve throttles apportion the branches. The pump itself is a standard end-suction centrifugal machine — motor Stator Assembly and Rotor Assembly in a Motor Housing, a bronze or composite Pump Impeller in a Pump Volute, a mechanical Oil Seal on the shaft and an O-Ring Set on the casing — selected for high flow at the low head of the tower. A Flow Switch and a discharge Pressure Sensor interlock the ride: if lubrication flow drops below the rated minimum, the dispatch system goes red and the slide closes. The loop is shared with the pool's filtration and chlorination plant, so the same water cycles continuously.
Splash pool and run-out
Deceleration happens in two stages. The Run-Out Section flattens the flume and carries standing braking water that drags the rider's speed down; the rounded Exit Lip then delivers them into a splash pool 1.0-1.2 m deep — deep enough to cushion, shallow enough to stand up in immediately. The entry wave each rider pushes ahead of them spills over the Surge Grating into the surge tank, which buffers the pool level and feeds the pump suction; without it the pool would slosh its level away under heavy throughput. Depth Marker signage at the exit is mandatory under both standards families.
Dispatch and operation
Rider spacing is enforced, not advised. The Dispatch System system holds a red Dispatch Light until the Exit Sensor confirms the previous rider has cleared the run-out, with the Dispatch Controller also gating on pump flow. The Access Stair Tower tower uses grit-surfaced Stair Flight treads and a continuous Handrail Run at two heights, since every user is barefoot and wet. Seasonal maintenance is dominated by the joints and the gel coat: gaskets are inspected, proud hardware re-torqued, and worn gel coat re-polished or re-coated, because surface finish is the ride.
