Overview

An instant hot water dispenser keeps one to two and a half litres of water just below boiling inside an insulated tank under the kitchen sink, and serves it through a small dedicated faucet on the counter. Pulling the lever delivers 96–98 °C water immediately, hot enough to brew tea, bloom coffee, make instant soup, or loosen a stuck jar lid, without waiting for a kettle. The element only works hard for the 10–15 minutes after a large draw; the rest of the time the insulated tank idles at 25–35 W of standby loss, comparable to a router.

The architecture is the same across InSinkErator, Quooker-style, and generic units: a Heated Tank Assembly with immersion element under the sink, a Thermostat Group regulating it, a Dispenser Faucet up top, and usually a Filtration Unit in the supply line because near-boiling water concentrates any taste the supply has.

How it works

The defining design decision is that the tank is vented, not pressurized. The Tank Vessel holds water at atmospheric pressure, with an Expansion Chamber headspace connected to the open Spout through the Vent Tube. A vessel that can never build pressure needs no relief valve and no pressure rating, which is how a thin stainless tank can safely hold 98 °C water for years.

Venting dictates how dispensing works, and it is backwards from a normal tap. The Valve Cartridge sits on the cold inlet side: pressing the Dispense Lever admits mains-pressure cold water into the bottom of the tank, which displaces hot water out the top and up to the spout. The hot path itself is never under mains pressure. Release the lever and the spring-return valve closes; a brief after-drip from the spout is normal and is simply thermal expansion finding the open vent, not a leak. Many models make the lever push-and-hold so the near-boiling stream cannot be left running, and the Spout Outlet Insert insert smooths the stream to limit splatter.

Heating is a 750–1,300 W Heating Element in the tank base, switched by the bimetal Tank Thermostat pressed against the tank wall. The user sets the point with the Temperature Dial, typically across a 71–98 °C range; 96 °C suits tea, while lower settings reduce scale and standby loss. Two backups guard the regulation loop: a manual-reset high-limit behind the Manual Reset Button, and a one-shot Thermal Fuse in series with the element. A dispenser that suddenly serves lukewarm water has usually tripped the high limit, often because scale insulated the thermostat from the water it measures.

Water path and filtration

Supply comes off the existing cold angle stop through a Saddle Tee Adapter, then through the Filtration Unit before entering the faucet valve. The activated-carbon Filter Cartridge removes chlorine, taste, and fine sediment, ratings of 2,800 L or six months are typical, and the quarter-turn Filter Head shuts off flow automatically during a swap so no tools or supply shutoff are needed. Filtration matters more here than at a cold tap: heating water drives off none of the chlorophenol taste compounds and scale-forming hardness becomes more aggressive at 98 °C, so unfiltered hard supplies will scale the tank and element within a couple of years. The Drain Plug exists for exactly that maintenance, draining the tank for a citric-acid descale.

All tube runs are 6 mm PEX or copper Supply Tube joined with Compression Fitting ferrules, serviceable with two wrenches.

Installation

The faucet drops through a 35–40 mm hole in the sink deck or counter, clamped by the Mounting Stud & Nut from below, with the brass Faucet Body carrying both the cold-in and hot-out connections. The tank hangs on the cabinet wall or stands on the cabinet floor directly beneath, kept close because every centimetre of hot-out tube is water that cools between uses. Power is a standard grounded Grounded Plug into the under-sink receptacle, GFCI-protected in modern kitchens and often shared with the waste disposer on a split circuit.

Commissioning order matters for the element's survival: fill the tank by holding the lever until water flows steadily from the spout, and only then plug the unit in. Energizing the element dry will blow the Thermal Fuse within seconds. The same logic applies in reverse for service, unplug, then drain. Units certify to UL 499 for the heating appliance and NSF/ANSI 42 for the filter's aesthetic-contaminant claims.
