A fully automatic bean-to-cup espresso machine: integrated conical burr grinder, thermoblock boiler, motorised brew group, milk frother and a touch-display control board. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
10 top-level lines · 80 rows shown · 120 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Chassis & Housing 6 parts | espresso-machine-chassis | 1× | 1 | 6 | assembly |
| 1.1 | Housing Shell | espresso-machine-housing-shell | 1× | 1 | — | part |
| 1.2 | Internal Frame | espresso-machine-frame | 1× | 1 | — | part |
| 1.3 | Drip Tray | espresso-machine-drip-tray | 1× | 1 | — | part |
| 1.4 | Cup Warming Tray | espresso-machine-cup-tray | 1× | 1 | — | part |
| 1.5 | Grounds Drawer | espresso-machine-grounds-drawer | 1× | 1 | — | part |
| 1.6 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Water Tank 4 parts | espresso-machine-water-tank | 1× | 1 | 4 | assembly |
| 2.1 | Tank Vessel | espresso-machine-tank-vessel | 1× | 1 | — | part |
| 2.2 | Float Level Sensor | espresso-machine-float-sensor | 1× | 1 | — | part |
| 2.3 | Water Filter Cartridge | espresso-machine-water-filter | 1× | 1 | — | part |
| 2.4 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 3 | Pump Unit 5 parts | espresso-machine-pump-unit | 1× | 1 | 9 | assembly |
| 3.1 | Vibratory Pump 3 parts | espresso-machine-vibratory-pump | 1× | 1 | 3 | assembly |
| 3.1.1 | Solenoid Coil | espresso-machine-solenoid-coil | 1× | 1 | — | part |
| 3.1.2 | Pump Piston | espresso-machine-pump-piston | 1× | 1 | — | part |
| 3.1.3 | Pump Spring | espresso-machine-pump-spring | 1× | 1 | — | part |
| 3.2 | Pump Head | espresso-machine-pump-head | 1× | 1 | — | part |
| 3.3 | Flow Meter | espresso-machine-flow-meter | 1× | 1 | — | part |
| 3.4 | Check Valve | espresso-machine-check-valve | 2× | 2 | — | part |
| 3.5 | Silicone Water Hose | espresso-machine-water-hose | 2× | 2 | — | part |
| 4 | Thermoblock Boiler 6 parts | espresso-machine-thermoblock | 1× | 1 | 6 | assembly |
| 4.1 | Thermoblock Body | espresso-machine-thermoblock-body | 1× | 1 | — | part |
| 4.2 | Heating Element | heating-element | 1× | 1 | — | part |
| 4.3 | Thermal Fuse | espresso-machine-thermal-fuse | 1× | 1 | — | part |
| 4.4 | NTC Temperature Sensor | espresso-machine-ntc-sensor | 1× | 1 | — | part |
| 4.5 | Overheat Cutoff Thermostat | espresso-machine-overheat-cutoff | 1× | 1 | — | part |
| 4.6 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 5 | Brew Group 7 parts | espresso-machine-brew-group | 1× | 1 | 33 | assembly |
| 5.1 | Brew Chamber | espresso-machine-brew-chamber | 1× | 1 | — | part |
| 5.2 | Brew Piston | espresso-machine-brew-piston | 1× | 1 | — | part |
| 5.3 | Brew Unit Motor 4 parts | espresso-machine-brew-motor | 1× | 1 | 25 | assembly |
| 5.3.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 5.3.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 5.3.3 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 5.3.4 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 5.4 | Reduction Gearset | espresso-machine-gearset | 1× | 1 | — | part |
| 5.5 | Infusion Screen | espresso-machine-infusion-screen | 1× | 1 | — | part |
| 5.6 | 3-Way Solenoid Valve 3 parts | espresso-machine-3way-valve | 1× | 1 | 3 | assembly |
| 5.6.1 | Solenoid Coil | espresso-machine-solenoid-coil | 1× | 1 | — | part |
| 5.6.2 | Valve Body & Plunger | espresso-machine-valve-body | 1× | 1 | — | part |
| 5.6.3 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 5.7 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 6 | Conical Burr Grinder 5 parts | espresso-machine-grinder | 1× | 1 | 30 | assembly |
| 6.1 | Conical Burr Set | espresso-machine-burr-set | 1× | 1 | — | part |
| 6.2 | Grinder Motor 5 parts | espresso-machine-grinder-motor | 1× | 1 | 26 | assembly |
| 6.2.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 6.2.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 6.2.3 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 6.2.4 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 6.2.5 | Reduction Gearset | espresso-machine-gearset | 1× | 1 | — | part |
| 6.3 | Bean Hopper | espresso-machine-hopper | 1× | 1 | — | part |
| 6.4 | Grind Adjuster | espresso-machine-grind-adjuster | 1× | 1 | — | part |
| 6.5 | Dosing Chute | espresso-machine-dosing-chute | 1× | 1 | — | part |
| 7 | Milk Frother 5 parts | espresso-machine-frother | 1× | 1 | 6 | assembly |
| 7.1 | Steam Wand | espresso-machine-steam-wand | 1× | 1 | — | part |
| 7.2 | Steam Valve 2 parts | espresso-machine-steam-valve | 1× | 1 | 2 | assembly |
| 7.2.1 | Solenoid Coil | espresso-machine-solenoid-coil | 1× | 1 | — | part |
| 7.2.2 | Valve Body & Plunger | espresso-machine-valve-body | 1× | 1 | — | part |
| 7.3 | Milk Pump | espresso-machine-milk-pump | 1× | 1 | — | part |
| 7.4 | Milk Carafe | espresso-machine-milk-carafe | 1× | 1 | — | part |
| 7.5 | Silicone Water Hose | espresso-machine-water-hose | 1× | 1 | — | part |
| 8 | Pressure System 4 parts | espresso-machine-pressure-system | 1× | 1 | 8 | assembly |
| 8.1 | Pressure Gauge | espresso-machine-pressure-gauge | 1× | 1 | — | part |
| 8.2 | Pressure Switch | pressure-switch | 1× | 1 | — | part |
| 8.3 | OPV Relief Valve 4 parts | espresso-machine-opv-valve | 1× | 1 | 4 | assembly |
| 8.3.1 | Valve Body & Plunger | espresso-machine-valve-body | 1× | 1 | — | part |
| 8.3.2 | Pump Spring | espresso-machine-pump-spring | 1× | 1 | — | part |
| 8.3.3 | Check Valve | espresso-machine-check-valve | 1× | 1 | — | part |
| 8.3.4 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 8.4 | Silicone Water Hose | espresso-machine-water-hose | 2× | 2 | — | part |
| 9 | Control Board 7 parts | espresso-machine-control-board | 1× | 1 | 17 | assembly |
| 9.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 9.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 9.3 | Triac | triac | 2× | 2 | — | part |
| 9.4 | Relay | relay | 2× | 2 | — | part |
| 9.5 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 9.6 | Rotary Encoder | espresso-machine-encoder | 2× | 2 | — | part |
| 9.7 | Connector | connector | 8× | 8 | — | part |
| 10 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
