A frost-free top-freezer fridge-freezer with auto-defrost and ice/water dispenser. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
9 top-level lines · 57 rows shown · 95 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Cabinet 5 parts | refrigerator-cabinet | 1× | 1 | 17 | assembly |
| 1.1 | Outer Steel Shell | refrigerator-outer-shell | 1× | 1 | — | part |
| 1.2 | Inner ABS Liner | refrigerator-inner-liner | 1× | 1 | — | part |
| 1.3 | Polyurethane Foam Insulation | refrigerator-foam-insulation | 1× | 1 | — | part |
| 1.4 | Door 3 parts | refrigerator-door | 2× | 2 | 5 | assembly |
| 1.4.1 | Door Panel | refrigerator-door-panel | 1× | 2 | — | part |
| 1.4.2 | Magnetic Door Gasket | refrigerator-door-gasket | 1× | 2 | — | part |
| 1.4.3 | Door Storage Bin | refrigerator-door-bin | 3× | 6 | — | part |
| 1.5 | Door Hinge | refrigerator-hinge | 4× | 4 | — | part |
| 2 | Refrigeration Circuit 6 parts | refrigerator-refrigeration-circuit | 1× | 1 | 31 | assembly |
| 2.1 | Reciprocating Compressor 6 parts | refrigerator-compressor | 1× | 1 | 26 | assembly |
| 2.1.1 | Stator Assembly 3 parts + deeper › | stator-assembly | 1× | 1 | 3 | assembly |
| 2.1.2 | Rotor Assembly 4 parts + deeper › | rotor-assembly | 1× | 1 | 19 | assembly |
| 2.1.3 | Compressor Pump (Piston/Cylinder) | refrigerator-compressor-pump | 1× | 1 | — | part |
| 2.1.4 | Motor Housing | motor-housing | 1× | 1 | — | part |
| 2.1.5 | Start Relay | refrigerator-start-relay | 1× | 1 | — | part |
| 2.1.6 | Overload Protector | refrigerator-overload-protector | 1× | 1 | — | part |
| 2.2 | Condenser Coil | refrigerator-condenser-coil | 1× | 1 | — | part |
| 2.3 | Evaporator Coil | refrigerator-evaporator-coil | 1× | 1 | — | part |
| 2.4 | Capillary Tube | refrigerator-capillary-tube | 1× | 1 | — | part |
| 2.5 | Filter Drier | refrigerator-filter-drier | 1× | 1 | — | part |
| 2.6 | Refrigerant Charge (R600a) | refrigerator-refrigerant | 1× | 1 | — | part |
| 3 | Defrost System 3 parts | refrigerator-defrost-system | 1× | 1 | 5 | assembly |
| 3.1 | Heating Element | heating-element | 1× | 1 | — | part |
| 3.2 | Defrost Thermostat | refrigerator-defrost-thermostat | 1× | 1 | — | part |
| 3.3 | Defrost Timer Board 3 parts | refrigerator-defrost-timer | 1× | 1 | 3 | assembly |
| 3.3.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 3.3.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 3.3.3 | Relay | relay | 1× | 1 | — | part |
| 4 | Interior 3 parts | refrigerator-interior | 1× | 1 | 8 | assembly |
| 4.1 | Tempered Glass Shelf | refrigerator-glass-shelf | 4× | 4 | — | part |
| 4.2 | Crisper Drawer | refrigerator-crisper-drawer | 2× | 2 | — | part |
| 4.3 | LED Interior Light | refrigerator-led-light | 2× | 2 | — | part |
| 5 | Ice & Water System 4 parts | refrigerator-ice-water-system | 1× | 1 | 6 | assembly |
| 5.1 | Water Inlet Valve | refrigerator-water-valve | 1× | 1 | — | part |
| 5.2 | Ice Maker Mold 3 parts | refrigerator-ice-mold | 1× | 1 | 3 | assembly |
| 5.2.1 | Ice Mold Tray | refrigerator-ice-tray | 1× | 1 | — | part |
| 5.2.2 | Heating Element | heating-element | 1× | 1 | — | part |
| 5.2.3 | Ice Ejector Motor | refrigerator-ice-motor | 1× | 1 | — | part |
| 5.3 | Auger Motor | refrigerator-auger-motor | 1× | 1 | — | part |
| 5.4 | Water Filter Cartridge | refrigerator-water-filter | 1× | 1 | — | part |
| 6 | Main Control Board 8 parts | refrigerator-control-board | 1× | 1 | 20 | assembly |
| 6.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 6.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 6.3 | Relay | relay | 4× | 4 | — | part |
| 6.4 | Triac | triac | 1× | 1 | — | part |
| 6.5 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 6.6 | Thermistor (NTC) | refrigerator-thermistor | 3× | 3 | — | part |
| 6.7 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 6.8 | Connector | connector | 8× | 8 | — | part |
| 7 | Evaporator Fan 2 parts | refrigerator-evaporator-fan | 1× | 1 | 2 | assembly |
| 7.1 | Blower Motor | blower-motor | 1× | 1 | — | part |
| 7.2 | Fan Blade | refrigerator-fan-blade | 1× | 1 | — | part |
| 8 | Condenser Fan 2 parts | refrigerator-condenser-fan | 1× | 1 | 2 | assembly |
| 8.1 | Blower Motor | blower-motor | 1× | 1 | — | part |
| 8.2 | Fan Blade | refrigerator-fan-blade | 1× | 1 | — | part |
| 9 | Leveling Foot | refrigerator-leveling-foot | 4× | 4 | — | part |
