Motorcycle Product
Sourcing — likely vendors
Real suppliers (🇮🇳 🇸🇬 🇨🇳); price, MOQ & lead time are estimates| Vendor | HQ | Specialty | Est. unit price | MOQ | Lead time |
|---|---|---|---|---|---|
| 🇨🇳BYD byd.com ↗ | Shenzhen, CN | EV & battery manufacturer | $2,450 | made to order | — |
| tatamotors.com ↗ | Mumbai, IN | Automaker | $2,450 | made to order | — |
| saicmotor.com ↗ | Shanghai, CN | Automaker | $2,550 | made to order | — |
| 🇮🇳Mahindra mahindra.com ↗ | Mumbai, IN | Automaker | $2,600 | made to order | — |
| 🇨🇳Geely global.geely.com ↗ | Hangzhou, CN | Automaker | $2,050 | made to order | — |
A standard internal-combustion motorcycle. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Bill of materials
19 top-level lines · 101 rows shown · 287 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Engine 12 parts | motorcycle-engine | 1× | 1 | 29 | assembly |
| 1.1 | Crankcase | motorcycle-crankcase | 1× | 1 | — | part |
| 1.2 | Piston | motorcycle-piston | 2× | 2 | — | part |
| 1.3 | Crankshaft | motorcycle-crankshaft | 1× | 1 | — | part |
| 1.4 | Cylinder Head 4 parts | motorcycle-cylinder-head | 1× | 1 | 12 | assembly |
| 1.4.1 | Camshaft | motorcycle-camshaft | 2× | 2 | — | part |
| 1.4.2 | Valve | motorcycle-valve | 8× | 8 | — | part |
| 1.4.3 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 1.4.4 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 1.5 | Fuel Injector | motorcycle-fuel-injector | 2× | 2 | — | part |
| 1.6 | Throttle Body | motorcycle-throttle-body | 2× | 2 | — | part |
| 1.7 | Oil Pump | motorcycle-oil-pump | 1× | 1 | — | part |
| 1.8 | Clutch | motorcycle-clutch | 1× | 1 | — | part |
| 1.9 | Gearbox | motorcycle-gearbox | 1× | 1 | — | part |
| 1.10 | Oil Seal | oil-seal | 4× | 4 | — | part |
| 1.11 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 1.12 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Final Drive 2 parts | motorcycle-final-drive | 1× | 1 | 3 | assembly |
| 2.1 | Sprocket | motorcycle-sprocket | 2× | 2 | — | part |
| 2.2 | Chain | chain | 1× | 1 | — | part |
| 3 | Frame 3 parts | motorcycle-frame | 1× | 1 | 4 | assembly |
| 3.1 | Main Frame | motorcycle-main-frame | 1× | 1 | — | part |
| 3.2 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 3.3 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 4 | Front Fork 4 parts | motorcycle-front-fork | 1× | 1 | 7 | assembly |
| 4.1 | Fork Tube | motorcycle-fork-tube | 2× | 2 | — | part |
| 4.2 | Coil Spring | coil-spring | 2× | 2 | — | part |
| 4.3 | Triple Clamp | motorcycle-triple-clamp | 1× | 1 | — | part |
| 4.4 | Oil Seal | oil-seal | 2× | 2 | — | part |
| 5 | Rear Suspension 4 parts | motorcycle-rear-suspension | 1× | 1 | 8 | assembly |
| 5.1 | Swingarm | motorcycle-swingarm | 1× | 1 | — | part |
| 5.2 | Shock Absorber 4 parts | shock-absorber | 1× | 1 | 4 | assembly |
| 5.2.1 | Damper Tube | damper-tube | 1× | 1 | — | part |
| 5.2.2 | Piston Rod | piston-rod | 1× | 1 | — | part |
| 5.2.3 | Oil Seal | oil-seal | 1× | 1 | — | part |
| 5.2.4 | Damper Oil | shock-oil | 1× | 1 | — | part |
| 5.3 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 5.4 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 6 | Front Wheel 4 parts | motorcycle-front-wheel | 1× | 1 | 40 | assembly |
| 6.1 | Rim | motorcycle-rim | 1× | 1 | — | part |
| 6.2 | Spoke | spoke | 36× | 36 | — | part |
| 6.3 | Tire | tire | 1× | 1 | — | part |
| 6.4 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 7 | Rear Wheel 4 parts | motorcycle-rear-wheel | 1× | 1 | 40 | assembly |
| 7.1 | Rim | motorcycle-rim | 1× | 1 | — | part |
| 7.2 | Spoke | spoke | 36× | 36 | — | part |
| 7.3 | Tire | tire | 1× | 1 | — | part |
| 7.4 | Ball Bearing | ball-bearing | 2× | 2 | — | part |
| 8 | Front Brakes 5 parts | motorcycle-front-brakes | 1× | 1 | 19 | assembly |
| 8.1 | Brake Disc (rotor) | brake-disc | 2× | 2 | — | part |
| 8.2 | Brake Pad Set | brake-pad-set | 2× | 2 | — | part |
| 8.3 | Brake Caliper 4 parts | brake-caliper | 2× | 2 | 6 | assembly |
| 8.3.1 | Caliper Body | caliper-body | 1× | 2 | — | part |
| 8.3.2 | Caliper Piston | caliper-piston | 2× | 4 | — | part |
| 8.3.3 | O-Ring Set | oring-set | 2× | 4 | — | part |
| 8.3.4 | Bleed Screw | bleed-screw | 1× | 2 | — | part |
| 8.4 | Master Cylinder | motorcycle-master-cylinder | 1× | 1 | — | part |
| 8.5 | Brake Hose | brake-hose | 2× | 2 | — | part |
| 9 | Rear Brake 5 parts | motorcycle-rear-brake | 1× | 1 | 10 | assembly |
| 9.1 | Brake Disc (rotor) | brake-disc | 1× | 1 | — | part |
| 9.2 | Brake Pad Set | brake-pad-set | 1× | 1 | — | part |
| 9.3 | Brake Caliper 4 parts | brake-caliper | 1× | 1 | 6 | assembly |
| 9.3.1 | Caliper Body | caliper-body | 1× | 1 | — | part |
| 9.3.2 | Caliper Piston | caliper-piston | 2× | 2 | — | part |
| 9.3.3 | O-Ring Set | oring-set | 2× | 2 | — | part |
| 9.3.4 | Bleed Screw | bleed-screw | 1× | 1 | — | part |
| 9.4 | Master Cylinder | motorcycle-master-cylinder | 1× | 1 | — | part |
| 9.5 | Brake Hose | brake-hose | 1× | 1 | — | part |
| 10 | Fuel Tank 2 parts | motorcycle-fuel-tank | 1× | 1 | 2 | assembly |
| 10.1 | Fuel Pump | motorcycle-fuel-pump | 1× | 1 | — | part |
| 10.2 | O-Ring Set | oring-set | 1× | 1 | — | part |
| 11 | Exhaust System 4 parts | motorcycle-exhaust | 1× | 1 | 4 | assembly |
| 11.1 | Header | motorcycle-header | 1× | 1 | — | part |
| 11.2 | Catalytic Converter | motorcycle-cat-converter | 1× | 1 | — | part |
| 11.3 | Muffler | motorcycle-muffler | 1× | 1 | — | part |
| 11.4 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 12 | Seat | motorcycle-seat | 1× | 1 | — | part |
| 13 | Handlebar 6 parts | motorcycle-handlebar | 1× | 1 | 7 | assembly |
| 13.1 | Handlebar Tube | motorcycle-handlebar-tube | 1× | 1 | — | part |
| 13.2 | Grip | motorcycle-grip | 1× | 1 | — | part |
| 13.3 | Throttle Grip | motorcycle-throttle-grip | 1× | 1 | — | part |
| 13.4 | Clutch Lever | motorcycle-clutch-lever | 1× | 1 | — | part |
| 13.5 | Brake Lever | motorcycle-brake-lever | 1× | 1 | — | part |
| 13.6 | Switchgear | motorcycle-switchgear | 2× | 2 | — | part |
| 14 | Instrument Cluster | instrument-cluster | 1× | 1 | — | part |
| 15 | Headlight | motorcycle-headlight | 1× | 1 | — | part |
| 16 | Taillight | motorcycle-taillight | 1× | 1 | — | part |
| 17 | Electrical System 7 parts | motorcycle-electrical | 1× | 1 | 108 | assembly |
| 17.1 | 12 V Battery | lv-battery | 1× | 1 | — | part |
| 17.2 | Electronic Control Unit 4 parts | ecu | 1× | 1 | 93 | assembly |
| 17.2.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 17.2.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 17.2.3 | CAN Transceiver | can-transceiver | 1× | 1 | — | part |
| 17.2.4 | SMD Passive (R/C/L) | smd-passives | 90× | 90 | — | part |
| 17.3 | Regulator/Rectifier | motorcycle-regulator-rectifier | 1× | 1 | — | part |
| 17.4 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 17.5 | Fuse Box | fuse-box | 1× | 1 | — | part |
| 17.6 | Relay | relay | 3× | 3 | — | part |
| 17.7 | Connector | connector | 8× | 8 | — | part |
| 18 | Radiator | radiator | 1× | 1 | — | part |
| 19 | Coolant | coolant | 1× | 1 | — | part |
