A van-chassis Type II emergency medical vehicle. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.

Bill of materials

2 top-level lines · 131 rows shown · 793 parts total · indented to 3 levels
# Item / sub-assembly Part no. Qty/assy Ext. qty Parts Type
1 Base Van Chassis 16 parts ambulance-base-chassis 1× 1 601 assembly
1.1 Diesel Engine 6 parts ambulance-engine 1× 1 42 assembly
1.1.1 Engine Block ambulance-engine-block 1× 1 — part
1.1.2 Piston Assembly 3 parts + deeper › ambulance-piston 6× 6 5 assembly
1.1.3 Crankshaft ambulance-crankshaft 1× 1 — part
1.1.4 Turbocharger 2 parts + deeper › ambulance-turbocharger 1× 1 3 assembly
1.1.5 Fuel Injector ambulance-injector 6× 6 — part
1.1.6 Fastener Set fastener-set 1× 1 — part
1.2 Automatic Transmission 4 parts ambulance-transmission 1× 1 7 assembly
1.2.1 Gearbox Housing gearbox-housing 1× 1 — part
1.2.2 Torque Converter ambulance-torque-converter 1× 1 — part
1.2.3 Planetary Gear Set ambulance-planetary-set 1× 1 — part
1.2.4 Ball Bearing ball-bearing 4× 4 — part
1.3 Fuel System 3 parts ambulance-fuel-system 1× 1 3 assembly
1.3.1 Fuel Tank ambulance-fuel-tank 1× 1 — part
1.3.2 Fuel Pump ambulance-fuel-pump 1× 1 — part
1.3.3 Fuel Filter ambulance-fuel-filter 1× 1 — part
1.4 Exhaust System 3 parts ambulance-exhaust-system 1× 1 3 assembly
1.4.1 Exhaust Manifold ambulance-manifold 1× 1 — part
1.4.2 Diesel Particulate Filter ambulance-dpf 1× 1 — part
1.4.3 Muffler ambulance-muffler 1× 1 — part
1.5 Driver Cab 6 parts ambulance-cab 1× 1 340 assembly
1.5.1 Dashboard 4 parts + deeper › dashboard 1× 1 313 assembly
1.5.2 Seat Assembly 5 parts + deeper › seat-assembly 2× 2 7 assembly
1.5.3 Windshield windshield 1× 1 — part
1.5.4 Instrument Cluster instrument-cluster 1× 1 — part
1.5.5 Steering Wheel 3 parts + deeper › steering-wheel 1× 1 4 assembly
1.5.6 HVAC Unit 5 parts + deeper › hvac-unit 1× 1 7 assembly
1.6 Ladder Frame Rails ambulance-frame-rails 1× 1 — part
1.7 Wheel Assembly 5 parts wheel-assembly 4× 4 9 assembly
1.7.1 Alloy Wheel alloy-wheel 1× 4 — part
1.7.2 Tire tire 1× 4 — part
1.7.3 TPMS Sensor tpms-sensor 1× 4 — part
1.7.4 Lug Nut lug-nut 5× 20 — part
1.7.5 Valve Stem valve-stem 1× 4 — part
1.8 Brake Corner 4 parts brake-corner 4× 4 9 assembly
1.8.1 Brake Caliper 4 parts + deeper › brake-caliper 1× 4 6 assembly
1.8.2 Brake Disc (rotor) brake-disc 1× 4 — part
1.8.3 Brake Pad Set brake-pad-set 1× 4 — part
1.8.4 Brake Hose brake-hose 1× 4 — part
1.9 Suspension Corner 5 parts suspension-corner 4× 4 16 assembly
1.9.1 Coil Spring coil-spring 1× 4 — part
1.9.2 Shock Absorber 4 parts + deeper › shock-absorber 1× 4 4 assembly
1.9.3 Control Arm control-arm 2× 8 — part
1.9.4 Ball Joint ball-joint 2× 8 — part
1.9.5 Wheel Hub 3 parts + deeper › wheel-hub 1× 4 7 assembly
1.10 Steering Rack (EPS) 4 parts steering-rack 1× 1 5 assembly
1.10.1 Rack Housing rack-housing 1× 1 — part
1.10.2 Rack & Pinion rack-pinion 1× 1 — part
1.10.3 EPS Motor steering-motor 1× 1 — part
1.10.4 Tie Rod tie-rod 2× 2 — part
1.11 Open Differential 4 parts differential 1× 1 6 assembly
1.11.1 Differential Case diff-case 1× 1 — part
1.11.2 Side Gear side-gear 2× 2 — part
1.11.3 Pinion Gear pinion-gear 2× 2 — part
1.11.4 Cross Pin cross-pin 1× 1 — part
1.12 Radiator radiator 1× 1 — part
1.13 Coolant Pump coolant-pump 1× 1 — part
1.14 Coolant coolant 1× 1 — part
1.15 12 V Battery lv-battery 1× 1 — part
1.16 LV Wiring Harness 4 parts lv-harness 1× 1 54 assembly
1.16.1 Wire Bundle wire-bundle 1× 1 — part
1.16.2 Connector connector 40× 40 — part
1.16.3 Fuse Box fuse-box 1× 1 — part
1.16.4 Relay relay 12× 12 — part
2 Medical Module 13 parts ambulance-medical-module 1× 1 192 assembly
2.1 Box Body Shell 4 parts ambulance-box-body 1× 1 15 assembly
2.1.1 Composite Wall Panel ambulance-box-panel 6× 6 — part
2.1.2 Rear Barn Door 2 parts + deeper › ambulance-rear-door 2× 2 2 assembly
2.1.3 Tinted Window ambulance-box-window 4× 4 — part
2.1.4 Fastener Set fastener-set 1× 1 — part
2.2 Interior Cabinetry 4 parts ambulance-interior-cabinetry 1× 1 11 assembly
2.2.1 Cabinet Carcass ambulance-cabinet-box 4× 4 — part
2.2.2 Storage Drawer ambulance-drawer 4× 4 — part
2.2.3 Grab Rail ambulance-grab-rail 2× 2 — part
2.2.4 Fastener Set fastener-set 1× 1 — part
2.3 Powered Stretcher Cot 5 parts ambulance-cot 1× 1 17 assembly
2.3.1 Cot Frame ambulance-cot-frame 1× 1 — part
2.3.2 Cot Mattress ambulance-cot-mattress 1× 1 — part
2.3.3 Lift Actuator 3 parts + deeper › ambulance-cot-actuator 2× 2 4 assembly
2.3.4 Cot Caster Wheel ambulance-cot-wheel 4× 4 — part
2.3.5 Restraint Strap ambulance-restraint-strap 3× 3 — part
2.4 Oxygen System 4 parts ambulance-oxygen-system 1× 1 10 assembly
2.4.1 O2 Cylinder 2 parts + deeper › ambulance-o2-cylinder 2× 2 2 assembly
2.4.2 Oxygen Regulator ambulance-o2-regulator 1× 1 — part
2.4.3 O2 Wall Outlet ambulance-o2-outlet 3× 3 — part
2.4.4 Oxygen Flowmeter ambulance-flowmeter 2× 2 — part
2.5 Suction Unit 3 parts ambulance-suction-unit 1× 1 3 assembly
2.5.1 Vacuum Pump ambulance-vacuum-pump 1× 1 — part
2.5.2 Suction Canister ambulance-suction-canister 1× 1 — part
2.5.3 Suction Tubing ambulance-suction-tubing 1× 1 — part
2.6 Defibrillator/Monitor 5 parts ambulance-defibrillator 1× 1 6 assembly
2.6.1 Bare PCB pcb-bare 1× 1 — part
2.6.2 Microcontroller mcu 1× 1 — part
2.6.3 LCD Panel lcd-panel 1× 1 — part
2.6.4 Energy Storage Capacitor ambulance-defib-capacitor 1× 1 — part
2.6.5 Defib Paddle ambulance-defib-paddle 2× 2 — part
2.7 Patient Monitor 5 parts ambulance-patient-monitor 1× 1 5 assembly
2.7.1 Bare PCB pcb-bare 1× 1 — part
2.7.2 Microcontroller mcu 1× 1 — part
2.7.3 LCD Panel lcd-panel 1× 1 — part
2.7.4 SpO2 Sensor ambulance-spo2-sensor 1× 1 — part
2.7.5 NIBP Cuff ambulance-nibp-cuff 1× 1 — part
2.8 IV Pole Mount 3 parts ambulance-iv-mount 2× 2 4 assembly
2.8.1 IV Pole ambulance-iv-pole 1× 2 — part
2.8.2 IV Hook ambulance-iv-hook 2× 4 — part
2.8.3 Fastener Set fastener-set 1× 2 — part
2.9 Emergency Light Bar 3 parts ambulance-light-bar 1× 1 71 assembly
2.9.1 LED Module 3 parts + deeper › ambulance-led-module 8× 8 8 assembly
2.9.2 Light Bar Lens ambulance-light-lens 1× 1 — part
2.9.3 Flasher Control Board 3 parts + deeper › ambulance-flasher-board 1× 1 6 assembly
2.10 Siren System 2 parts ambulance-siren-system 1× 1 5 assembly
2.10.1 Siren Amplifier 3 parts + deeper › ambulance-siren-amp 1× 1 3 assembly
2.10.2 Siren Speaker ambulance-speaker 2× 2 — part
2.11 Module Electrical System 7 parts ambulance-module-electrical 1× 1 31 assembly
2.11.1 Power Inverter 3 parts + deeper › ambulance-inverter 1× 1 3 assembly
2.11.2 Auxiliary AGM Battery ambulance-aux-battery 1× 1 — part
2.11.3 Shoreline Inlet 2 parts + deeper › ambulance-shoreline 1× 1 2 assembly
2.11.4 Fuse Box fuse-box 1× 1 — part
2.11.5 Wire Bundle wire-bundle 1× 1 — part
2.11.6 Relay relay 8× 8 — part
2.11.7 DC-DC Converter 4 parts + deeper › dcdc-converter 1× 1 15 assembly
2.12 Box Climate Control 4 parts ambulance-box-climate 1× 1 4 assembly
2.12.1 Box Evaporator ambulance-ac-evaporator 1× 1 — part
2.12.2 Box Blower Fan ambulance-box-blower 1× 1 — part
2.12.3 Box Heater Core ambulance-box-heater 1× 1 — part
2.12.4 Coolant coolant 1× 1 — part
2.13 Action Wall 3 parts ambulance-action-wall 1× 1 6 assembly
2.13.1 Action Wall Panel ambulance-action-panel 1× 1 — part
2.13.2 Sharps Container ambulance-sharps-container 1× 1 — part
2.13.3 Supply Bin ambulance-supply-bin 4× 4 — part
