Overview

A metal detector locates buried metal objects by sending electromagnetic energy into the ground and detecting the faint reflections bouncing back from metal. A hobby-grade pulse induction (PI) detector is a popular choice for beginners and treasure hunters because it is relatively immune to ground mineralization (iron-rich soil that confuses other detector types).

The device consists of three main assemblies connected by a single cable: the Search Coil Head (search head) at the end of a Telescoping Shaft, the Armrest Assembly for balance and comfort, and the Control Box containing all electronics. The user sweeps the coil across the ground; when it passes over metal, the Receiver Amplifier detects a transient signal, the Main Board analyzes it, and the Audio Output generates a beep whose pitch indicates signal strength. An LCD Panel (if present) displays estimated depth and target type.

The simplicity and robustness of PI detectors—a high-voltage transmit pulse, a fast receiver, and a microcontroller counting transient decay time—make them popular for beach hunting, archaeological surveys, and amateur treasure seeking.

How it works

Inside the Search Coil Head, two coils sit side by side: a Transmit Coil (transmit) and a Receive Coil (receive). At the start of each pulse cycle, the Pulse Oscillator MOSFET switches on and discharges the Energy Capacitor (charged to 50–200 V) through the TX coil, creating a brief magnetic pulse. This magnetic field propagates downward and outward into the soil.

When the transmit pulse ends, the MOSFET turns off and the TX coil field begins to collapse. If no metal is present, the collapsing field generates a clean, predictable transient in the RX coil. If a metal object is in the field, it absorbs and re-radiates some of the magnetic energy, creating a secondary (delayed) pulse of its own. This secondary pulse overlaps with the collapsing transient, changing its shape and delay.

The RX coil output is sampled by the Receiver Amplifier, a low-noise instrumentation amplifier that boosts the millivolt-scale signal to the ADC input range. The Main Board MCU samples the RX voltage at high speed (tens of kHz) for a few milliseconds after the TX pulse ends. It then applies a matched filter: it compares the observed RX transient to a reference shape (calculated during factory calibration). A mismatch score indicates the presence and depth of metal.

The MCU also implements [[hobby-metal-detector-main-board|ground balance]]: it measures the baseline RX transient in the soil and subtracts it from incoming measurements, filtering out the background iron oxide that would otherwise swamp weak metal signals. The user adjusts balance with pushbuttons on the Control Box until the beep stops, then sweeps the coil to search for buried objects.

When a target is detected, the MCU calculates a confidence metric and depth estimate from the signal shape and amplitude, then commands the Audio Output DAC to synthesize an audio tone. Stronger targets produce higher-pitch beeps; deeper targets produce lower-pitch or slower-cadence beeps. This auditory feedback lets the operator scan large areas quickly without staring at a display. The entire cycle (TX pulse, RX sampling, filtering, tone generation) repeats 25–100 times per second, giving real-time feedback as the coil moves.

Power comes from four alkaline cells in the Battery Holder. The Pulse Oscillator draws peak current (2–5 A) during the TX pulse, but only for a few microseconds; a bulk capacitor provides charge and prevents battery sagging. Between pulses, quiescent current is <10 mA, so a set of fresh AA batteries yields 30–40 hours of continuous searching.
