Desktop PC Product
Sourcing — likely vendors
Real suppliers (🇮🇳 🇸🇬 🇨🇳); price, MOQ & lead time are estimates| Vendor | HQ | Specialty | Est. unit price | MOQ | Lead time |
|---|---|---|---|---|---|
| 🇨🇳Foxconn foxconn.com ↗ | Shenzhen, CN | Electronics contract mfg | $174 | 1,000 pcs | 6–10 wks |
| flex.com ↗ | Singapore | Electronics contract mfg | $176 | 1,000 pcs | 6–10 wks |
| dixoninfo.com ↗ | Noida, IN | Electronics contract mfg | $225 | 1,000 pcs | 6–10 wks |
| bydelectronic.com ↗ | Shenzhen, CN | Electronics contract mfg | $171 | 1,000 pcs | 6–10 wks |
| venture.com.sg ↗ | Singapore | Electronics contract mfg | $186 | 1,000 pcs | 6–10 wks |
A gaming desktop tower: steel/tempered-glass case, ATX motherboard, discrete GPU, AIO liquid CPU cooler, and a modular power supply. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
14 top-level lines · 77 rows shown · 146 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Case / Chassis 7 parts | desktop-pc-case | 1× | 1 | 19 | assembly |
| 1.1 | Sheet Metal Panel | sheet-panel | 4× | 4 | — | part |
| 1.2 | Tempered Glass Panel | desktop-pc-glass-panel | 1× | 1 | — | part |
| 1.3 | Front Mesh Panel | desktop-pc-front-panel | 1× | 1 | — | part |
| 1.4 | Rear IO Shield | desktop-pc-io-shield | 1× | 1 | — | part |
| 1.5 | Drive Cage | desktop-pc-drive-cage | 2× | 2 | — | part |
| 1.6 | Motherboard Standoff | desktop-pc-standoff | 9× | 9 | — | part |
| 1.7 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Motherboard 11 parts | desktop-pc-motherboard | 1× | 1 | 23 | assembly |
| 2.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 2.2 | CPU Socket | desktop-pc-cpu-socket | 1× | 1 | — | part |
| 2.3 | Platform Chipset | desktop-pc-chipset | 1× | 1 | — | part |
| 2.4 | VRM Power Stage | desktop-pc-vrm | 1× | 1 | — | part |
| 2.5 | DDR5 DIMM Slot | desktop-pc-dimm-slot | 4× | 4 | — | part |
| 2.6 | PCIe Slot | desktop-pc-pcie-slot | 3× | 3 | — | part |
| 2.7 | M.2 Socket | desktop-pc-m2-slot | 3× | 3 | — | part |
| 2.8 | BIOS Flash Chip | desktop-pc-bios-chip | 1× | 1 | — | part |
| 2.9 | Rear IO Cluster | desktop-pc-rear-io | 1× | 1 | — | part |
| 2.10 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 2.11 | Connector | connector | 6× | 6 | — | part |
| 3 | CPU 3 parts | desktop-pc-cpu | 1× | 1 | 3 | assembly |
| 3.1 | CPU Die | desktop-pc-cpu-die | 1× | 1 | — | part |
| 3.2 | CPU Substrate | desktop-pc-cpu-substrate | 1× | 1 | — | part |
| 3.3 | Integrated Heat Spreader | desktop-pc-ihs | 1× | 1 | — | part |
| 4 | DDR5 Memory Module 4 parts | desktop-pc-ram-module | 2× | 2 | 11 | assembly |
| 4.1 | Bare PCB | pcb-bare | 1× | 2 | — | part |
| 4.2 | DDR5 DRAM Chip | desktop-pc-dram-chip | 8× | 16 | — | part |
| 4.3 | RAM Heat Spreader | desktop-pc-ram-heatspreader | 1× | 2 | — | part |
| 4.4 | SMD Passive (R/C/L) | smd-passives | 1× | 2 | — | part |
| 5 | Graphics Card 7 parts | desktop-pc-gpu | 1× | 1 | 16 | assembly |
| 5.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 5.2 | GPU Die | desktop-pc-gpu-die | 1× | 1 | — | part |
| 5.3 | GDDR Memory Chip | desktop-pc-vram-chip | 8× | 8 | — | part |
| 5.4 | GPU Cooler | desktop-pc-gpu-cooler | 1× | 1 | — | part |
| 5.5 | Blower Motor | blower-motor | 3× | 3 | — | part |
| 5.6 | GPU Backplate | desktop-pc-gpu-backplate | 1× | 1 | — | part |
| 5.7 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 6 | NVMe SSD | desktop-pc-nvme-ssd | 1× | 1 | — | part |
| 7 | AIO Liquid Cooler 5 parts | desktop-pc-cpu-cooler | 1× | 1 | 8 | assembly |
| 7.1 | Pump Block 2 parts | desktop-pc-pump-block | 1× | 1 | 2 | assembly |
| 7.1.1 | CPU Cold Plate | desktop-pc-cold-plate | 1× | 1 | — | part |
| 7.1.2 | Ball Bearing | ball-bearing | 1× | 1 | — | part |
| 7.2 | Radiator | desktop-pc-radiator | 1× | 1 | — | part |
| 7.3 | Blower Motor | blower-motor | 2× | 2 | — | part |
| 7.4 | Coolant Tube | desktop-pc-coolant-tube | 2× | 2 | — | part |
| 7.5 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 8 | Power Supply Unit 7 parts | desktop-pc-psu | 1× | 1 | 13 | assembly |
| 8.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 8.2 | Switching Transformer | desktop-pc-psu-transformer | 1× | 1 | — | part |
| 8.3 | Bulk Capacitor | desktop-pc-psu-bulk-cap | 2× | 2 | — | part |
| 8.4 | Blower Motor | blower-motor | 1× | 1 | — | part |
| 8.5 | PSU Housing | desktop-pc-psu-housing | 1× | 1 | — | part |
| 8.6 | Connector | connector | 6× | 6 | — | part |
| 8.7 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 9 | Case Fan 2 parts | desktop-pc-case-fan | 3× | 3 | 2 | assembly |
| 9.1 | Blower Motor | blower-motor | 1× | 3 | — | part |
| 9.2 | Fan Frame | desktop-pc-fan-frame | 1× | 3 | — | part |
| 10 | Front IO Board 4 parts | desktop-pc-front-io-board | 1× | 1 | 5 | assembly |
| 10.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 10.2 | Front USB Port | desktop-pc-usb-port | 2× | 2 | — | part |
| 10.3 | Power / Reset Cluster | desktop-pc-power-button | 1× | 1 | — | part |
| 10.4 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 11 | RGB / Fan Controller 4 parts | desktop-pc-rgb-controller | 1× | 1 | 13 | assembly |
| 11.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 11.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 11.3 | Connector | connector | 10× | 10 | — | part |
| 11.4 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 12 | WiFi / BT Card 4 parts | desktop-pc-wifi-card | 1× | 1 | 5 | assembly |
| 12.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 12.2 | WiFi/BT Radio SoC | desktop-pc-wifi-soc | 1× | 1 | — | part |
| 12.3 | WiFi Antenna | desktop-pc-wifi-antenna | 2× | 2 | — | part |
| 12.4 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 13 | Cabling Kit 3 parts | desktop-pc-cabling-kit | 1× | 1 | 11 | assembly |
| 13.1 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 13.2 | SATA Data Cable | desktop-pc-sata-cable | 2× | 2 | — | part |
| 13.3 | Connector | connector | 8× | 8 | — | part |
| 14 | Fastener Set | fastener-set | 1× | 1 | — | part |
