Game Console Product

Sourcing — likely vendors

Real suppliers (🇮🇳 🇸🇬 🇨🇳); price, MOQ & lead time are estimates
VendorHQSpecialtyEst. unit priceMOQLead time
🇨🇳Foxconn
foxconn.com ↗ 		Shenzhen, CN Electronics contract mfg $155 1,000 pcs 6–10 wks
🇸🇬Flex (Singapore)
flex.com ↗ 		Singapore Electronics contract mfg $131 1,000 pcs 6–10 wks
🇮🇳Dixon Technologies
dixoninfo.com ↗ 		Noida, IN Electronics contract mfg $163 1,000 pcs 6–10 wks
🇨🇳BYD Electronics
bydelectronic.com ↗ 		Shenzhen, CN Electronics contract mfg $123 1,000 pcs 6–10 wks
🇸🇬Venture Corp
venture.com.sg ↗ 		Singapore Electronics contract mfg $107 1,000 pcs 6–10 wks

A home game console with a custom APU mainboard, vapor-chamber cooling, optical disc drive, and a wireless controller. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.

Build & assembly graph

expand / collapse · shared sub-assemblies converge · links to related products · est. labour
product / assembly shared across products atomic part related product

Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.

Bill of materials

10 top-level lines · 82 rows shown · 114 parts total · indented to 3 levels
# Item / sub-assembly Part no. Qty/assy Ext. qty Parts Type
1 Enclosure & Chassis 5 parts game-console-enclosure 1× 1 10 assembly
1.1 Outer Shell Panel game-console-outer-shell 2× 2 — part
1.2 Chassis Frame game-console-chassis-frame 1× 1 — part
1.3 EMI Shield Can game-console-emi-shield 2× 2 — part
1.4 Rubber Foot game-console-rubber-foot 4× 4 — part
1.5 Fastener Set fastener-set 1× 1 — part
2 Mainboard 10 parts game-console-mainboard 1× 1 37 assembly
2.1 Bare PCB pcb-bare 1× 1 — part
2.2 Compute SoC Module soc-module 1× 1 — part
2.3 GDDR6 Memory IC game-console-gddr 8× 8 — part
2.4 NAND Flash Package game-console-nand-flash 4× 4 — part
2.5 NVMe SSD Controller game-console-ssd-controller 1× 1 — part
2.6 Southbridge IC game-console-southbridge 1× 1 — part
2.7 VRM Module 2 parts game-console-vrm 1× 1 11 assembly
2.7.1 Power Stage IC game-console-power-stage 10× 10 — part
2.7.2 SMD Passive (R/C/L) smd-passives 1× 1 — part
2.8 WiFi 6 / BT Module 3 parts game-console-wireless-module 1× 1 3 assembly
2.8.1 Microcontroller mcu 1× 1 — part
2.8.2 SMD Passive (R/C/L) smd-passives 1× 1 — part
2.8.3 RF Shield Can game-console-rf-shield 1× 1 — part
2.9 SMD Passive (R/C/L) smd-passives 1× 1 — part
2.10 Connector connector 6× 6 — part
3 Thermal Solution 4 parts game-console-thermal 1× 1 6 assembly
3.1 Vapor Chamber game-console-vapor-chamber 1× 1 — part
3.2 Blower Fan Assembly 3 parts game-console-blower-fan 1× 1 3 assembly
3.2.1 Blower Motor blower-motor 1× 1 — part
3.2.2 Blower Impeller game-console-fan-impeller 1× 1 — part
3.2.3 Fan Housing game-console-fan-housing 1× 1 — part
3.3 Liquid-Metal TIM game-console-liquid-metal 1× 1 — part
3.4 Fastener Set fastener-set 1× 1 — part
4 Internal Power Supply 3 parts game-console-psu 1× 1 3 assembly
4.1 Power Supply power-supply 1× 1 — part
4.2 AC Mains Inlet game-console-ac-inlet 1× 1 — part
4.3 Fastener Set fastener-set 1× 1 — part
5 Optical Disc Drive 5 parts game-console-disc-drive 1× 1 6 assembly
5.1 Laser Pickup Unit game-console-laser-pickup 1× 1 — part
5.2 Spindle Motor game-console-spindle-motor 1× 1 — part
5.3 Loading Motor game-console-loading-motor 1× 1 — part
5.4 Disc Tray & Sled game-console-disc-tray 1× 1 — part
5.5 Drive Control Board 2 parts game-console-drive-pcb 1× 1 2 assembly
5.5.1 Bare PCB pcb-bare 1× 1 — part
5.5.2 Microcontroller mcu 1× 1 — part
6 Front IO Board 4 parts game-console-front-io 1× 1 6 assembly
6.1 Bare PCB pcb-bare 1× 1 — part
6.2 USB Port Connector game-console-usb-port 2× 2 — part
6.3 Tact Button game-console-tact-button 2× 2 — part
6.4 Connector connector 1× 1 — part
7 Rear Port Cluster 4 parts game-console-rear-ports 1× 1 5 assembly
7.1 HDMI Port game-console-hdmi-port 1× 1 — part
7.2 Ethernet Jack game-console-ethernet-port 1× 1 — part
7.3 USB Port Connector game-console-usb-port 2× 2 — part
7.4 Connector connector 1× 1 — part
8 Antenna Kit 2 parts game-console-antenna-kit 1× 1 3 assembly
8.1 Antenna Element game-console-antenna 2× 2 — part
8.2 Wire Bundle wire-bundle 1× 1 — part
9 Wire Bundle wire-bundle 1× 1 — part
10 Wireless Controller 12 parts game-console-controller 1× 1 37 assembly
10.1 Controller Shell game-console-ctrl-shell 1× 1 — part
10.2 Controller Mainboard 4 parts game-console-ctrl-mainboard 1× 1 6 assembly
10.2.1 Bare PCB pcb-bare 1× 1 — part
10.2.2 Microcontroller mcu 1× 1 — part
10.2.3 SMD Passive (R/C/L) smd-passives 1× 1 — part
10.2.4 Connector connector 3× 3 — part
10.3 Analog Stick Module 3 parts game-console-analog-stick 2× 2 5 assembly
10.3.1 Stick Potentiometer game-console-stick-pot 2× 4 — part
10.3.2 Hall Sensor hall-sensor 2× 4 — part
10.3.3 Tact Button game-console-tact-button 1× 2 — part
10.4 Button & Membrane Set 2 parts game-console-button-set 1× 1 6 assembly
10.4.1 Button Cap game-console-button-cap 5× 5 — part
10.4.2 Rubber Membrane game-console-membrane 1× 1 — part
10.5 Analog Trigger 2 parts game-console-trigger 2× 2 2 assembly
10.5.1 Trigger Lever game-console-trigger-lever 1× 2 — part
10.5.2 Hall Sensor hall-sensor 1× 2 — part
10.6 Rumble Motor 2 parts game-console-rumble-motor 2× 2 2 assembly
10.6.1 Coreless DC Motor game-console-erm-motor 1× 2 — part
10.6.2 Neodymium Magnet neodymium-magnet 1× 2 — part
10.7 LiPo Cell lipo-cell 1× 1 — part
10.8 BMS Board bms-board 1× 1 — part
10.9 USB-C Port game-console-usbc-port 1× 1 — part
10.10 Speaker speaker 1× 1 — part
10.11 RGB Light Bar game-console-light-bar 1× 1 — part
10.12 Fastener Set fastener-set 1× 1 — part
