Laptop Product
Sourcing — likely vendors
Real suppliers (🇮🇳 🇸🇬 🇨🇳); price, MOQ & lead time are estimates| Vendor | HQ | Specialty | Est. unit price | MOQ | Lead time |
|---|---|---|---|---|---|
| 🇨🇳Foxconn foxconn.com ↗ | Shenzhen, CN | Electronics contract mfg | $244 | 1,000 pcs | 6–10 wks |
| flex.com ↗ | Singapore | Electronics contract mfg | $169 | 1,000 pcs | 6–10 wks |
| dixoninfo.com ↗ | Noida, IN | Electronics contract mfg | $209 | 1,000 pcs | 6–10 wks |
| bydelectronic.com ↗ | Shenzhen, CN | Electronics contract mfg | $168 | 1,000 pcs | 6–10 wks |
| venture.com.sg ↗ | Singapore | Electronics contract mfg | $233 | 1,000 pcs | 6–10 wks |
A thin-and-light aluminium notebook with a soldered SoC, OLED display, and dual-fan vapour-cooled mainboard. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
13 top-level lines · 69 rows shown · 157 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Chassis 4 parts | laptop-chassis | 1× | 1 | 5 | assembly |
| 1.1 | Aluminium Top Cover | laptop-top-cover | 1× | 1 | — | part |
| 1.2 | Bottom Case | laptop-bottom-case | 1× | 1 | — | part |
| 1.3 | Display Hinge | laptop-hinge | 2× | 2 | — | part |
| 1.4 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Display Assembly 7 parts | laptop-display-assembly | 1× | 1 | 10 | assembly |
| 2.1 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 2.2 | LED Backlight | laptop-led-backlight | 1× | 1 | — | part |
| 2.3 | Display Bezel | laptop-display-bezel | 1× | 1 | — | part |
| 2.4 | Lid Housing | laptop-lid-housing | 1× | 1 | — | part |
| 2.5 | Camera Module 3 parts | camera-module | 1× | 1 | 3 | assembly |
| 2.5.1 | CMOS Image Sensor | image-sensor | 1× | 1 | — | part |
| 2.5.2 | Lens Assembly | camera-lens | 1× | 1 | — | part |
| 2.5.3 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 2.6 | Lid Antenna | laptop-wifi-antenna | 2× | 2 | — | part |
| 2.7 | Display Flex Cable | laptop-display-flex | 1× | 1 | — | part |
| 3 | Mainboard 11 parts | laptop-mainboard | 1× | 1 | 16 | assembly |
| 3.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 3.2 | Compute SoC Module | soc-module | 1× | 1 | — | part |
| 3.3 | LPDDR5 Memory Package | laptop-ram-package | 2× | 2 | — | part |
| 3.4 | NVMe SSD | laptop-ssd | 1× | 1 | — | part |
| 3.5 | Platform Controller Hub | laptop-pch | 1× | 1 | — | part |
| 3.6 | VRM Module | laptop-vrm | 1× | 1 | — | part |
| 3.7 | WiFi 6E / BT Module | laptop-wifi-module | 1× | 1 | — | part |
| 3.8 | USB-C Controller | laptop-usbc-controller | 2× | 2 | — | part |
| 3.9 | SMD Passive (R/C/L) | smd-passives | 1× | 1 | — | part |
| 3.10 | EMI Shield | laptop-emi-shield | 1× | 1 | — | part |
| 3.11 | Connector | connector | 4× | 4 | — | part |
| 4 | Keyboard Assembly 6 parts | laptop-keyboard | 1× | 1 | 83 | assembly |
| 4.1 | Scissor Key Switch | laptop-key-switch | 78× | 78 | — | part |
| 4.2 | Key Membrane | laptop-key-membrane | 1× | 1 | — | part |
| 4.3 | Keyboard Backlight | laptop-keyboard-backlight | 1× | 1 | — | part |
| 4.4 | Keyboard Frame | laptop-keyboard-frame | 1× | 1 | — | part |
| 4.5 | Microcontroller | mcu | 1× | 1 | — | part |
| 4.6 | Keyboard Flex Cable | laptop-keyboard-flex | 1× | 1 | — | part |
| 5 | Trackpad 5 parts | laptop-trackpad | 1× | 1 | 8 | assembly |
| 5.1 | Trackpad Glass | laptop-trackpad-glass | 1× | 1 | — | part |
| 5.2 | Force Sensor | laptop-force-sensor | 4× | 4 | — | part |
| 5.3 | Trackpad Controller | laptop-trackpad-controller | 1× | 1 | — | part |
| 5.4 | Haptic Actuator | laptop-haptic-actuator | 1× | 1 | — | part |
| 5.5 | Trackpad Flex Cable | laptop-trackpad-flex | 1× | 1 | — | part |
| 6 | Battery Pack 5 parts | laptop-battery-pack | 1× | 1 | 8 | assembly |
| 6.1 | LiPo Cell | lipo-cell | 4× | 4 | — | part |
| 6.2 | BMS Board | bms-board | 1× | 1 | — | part |
| 6.3 | Battery Housing | laptop-battery-housing | 1× | 1 | — | part |
| 6.4 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 6.5 | Connector | connector | 1× | 1 | — | part |
| 7 | Thermal Module 4 parts | laptop-thermal-module | 1× | 1 | 7 | assembly |
| 7.1 | Heat Pipe | laptop-heat-pipe | 2× | 2 | — | part |
| 7.2 | Blower Motor | blower-motor | 2× | 2 | — | part |
| 7.3 | Heatsink Fin Stack | laptop-heatsink-fins | 2× | 2 | — | part |
| 7.4 | Cold Plate | laptop-vapor-plate | 1× | 1 | — | part |
| 8 | Speaker | speaker | 2× | 2 | — | part |
| 9 | Microphone Array 2 parts | laptop-mic-array | 1× | 1 | 4 | assembly |
| 9.1 | MEMS Microphone | laptop-mems-mic | 3× | 3 | — | part |
| 9.2 | Microphone Flex Cable | laptop-mic-flex | 1× | 1 | — | part |
| 10 | IO Board 6 parts | laptop-io-board | 1× | 1 | 7 | assembly |
| 10.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 10.2 | USB-C Port | laptop-usbc-port | 2× | 2 | — | part |
| 10.3 | HDMI Port | laptop-hdmi-port | 1× | 1 | — | part |
| 10.4 | Audio Jack | laptop-audio-jack | 1× | 1 | — | part |
| 10.5 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 10.6 | Connector | connector | 1× | 1 | — | part |
| 11 | Fingerprint Reader | laptop-fingerprint-reader | 1× | 1 | — | part |
| 12 | Power Adapter 3 parts | laptop-power-adapter | 1× | 1 | 4 | assembly |
| 12.1 | Power Supply | power-supply | 1× | 1 | — | part |
| 12.2 | Charger Housing | laptop-charger-housing | 1× | 1 | — | part |
| 12.3 | USB-C Cable | laptop-usbc-cable | 2× | 2 | — | part |
| 13 | Fastener Set | fastener-set | 2× | 2 | — | part |
