Patient Monitor Product
Sourcing — likely vendors
Real suppliers (🇮🇳 🇸🇬 🇨🇳); price, MOQ & lead time are estimates| Vendor | HQ | Specialty | Est. unit price | MOQ | Lead time |
|---|---|---|---|---|---|
| 🇨🇳BOE boe.com ↗ | Beijing, CN | Display panels | $5,550 | 1,000 pcs | 6–10 wks |
| 🇨🇳Tianma tianma.com ↗ | Shenzhen, CN | Display panels | $5,100 | 1,000 pcs | 6–10 wks |
| 🇨🇳TCL CSOT szcsot.com ↗ | Shenzhen, CN | Display panels | $4,750 | 1,000 pcs | 6–10 wks |
| truly.net ↗ | Shanwei, CN | Displays & camera modules | $6,450 | 1,000 pcs | 6–10 wks |
| venture.com.sg ↗ | Singapore | Electronics contract mfg | $5,500 | 1,000 pcs | 6–10 wks |
A multiparameter bedside monitor displaying ECG, SpO2, NIBP, temperature, respiration, IBP, and capnography with audible/visual alarms. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.
Build & assembly graph
expand / collapse · shared sub-assemblies converge · links to related products · est. labour product / assembly shared across products atomic part related product
Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.
Bill of materials
17 top-level lines · 103 rows shown · 1,030 parts total · indented to 3 levels| # | Item / sub-assembly | Part no. | Qty/assy | Ext. qty | Parts | Type |
|---|---|---|---|---|---|---|
| 1 | Enclosure 4 parts | patient-monitor-enclosure | 1× | 1 | 4 | assembly |
| 1.1 | Housing Shell | patient-monitor-housing | 1× | 1 | — | part |
| 1.2 | Carry Handle | patient-monitor-handle | 1× | 1 | — | part |
| 1.3 | Stand/VESA Mount | patient-monitor-stand-mount | 1× | 1 | — | part |
| 1.4 | Fastener Set | fastener-set | 1× | 1 | — | part |
| 2 | Display Assembly 4 parts | patient-monitor-display | 1× | 1 | 4 | assembly |
| 2.1 | LCD Panel | lcd-panel | 1× | 1 | — | part |
| 2.2 | Touch Digitizer | touch-digitizer | 1× | 1 | — | part |
| 2.3 | LED Backlight Unit | patient-monitor-backlight | 1× | 1 | — | part |
| 2.4 | Display Bezel | patient-monitor-bezel | 1× | 1 | — | part |
| 3 | Main Board 6 parts | patient-monitor-main-board | 1× | 1 | 294 | assembly |
| 3.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 3.2 | Compute SoC Module | soc-module | 1× | 1 | — | part |
| 3.3 | DDR RAM Module | patient-monitor-ram | 1× | 1 | — | part |
| 3.4 | eMMC Flash Storage | patient-monitor-flash | 1× | 1 | — | part |
| 3.5 | SMD Passive (R/C/L) | smd-passives | 280× | 280 | — | part |
| 3.6 | Connector | connector | 10× | 10 | — | part |
| 4 | Parameter Acquisition Board 6 parts | patient-monitor-acquisition-board | 1× | 1 | 173 | assembly |
| 4.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 4.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 4.3 | Analog Front-End IC | afe-ic | 2× | 2 | — | part |
| 4.4 | Patient Isolation Barrier | patient-monitor-isolation-barrier | 1× | 1 | — | part |
| 4.5 | SMD Passive (R/C/L) | smd-passives | 160× | 160 | — | part |
| 4.6 | Connector | connector | 8× | 8 | — | part |
| 5 | ECG Module 6 parts | patient-monitor-ecg-module | 1× | 1 | 79 | assembly |
| 5.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 5.2 | Analog Front-End IC | afe-ic | 1× | 1 | — | part |
| 5.3 | Patient Isolation Barrier | patient-monitor-isolation-barrier | 1× | 1 | — | part |
| 5.4 | ECG Lead Wire Set | patient-monitor-ecg-leadwire | 1× | 1 | — | part |
| 5.5 | ECG Electrode | patient-monitor-ecg-electrode | 5× | 5 | — | part |
| 5.6 | SMD Passive (R/C/L) | smd-passives | 70× | 70 | — | part |
| 6 | SpO2 Module 4 parts | patient-monitor-spo2-module | 1× | 1 | 56 | assembly |
| 6.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 6.2 | Analog Front-End IC | afe-ic | 1× | 1 | — | part |
| 6.3 | SpO2 Finger Probe 4 parts | patient-monitor-spo2-probe | 1× | 1 | 4 | assembly |
| 6.3.1 | Red/IR LED Emitter | patient-monitor-spo2-led | 1× | 1 | — | part |
| 6.3.2 | Photodiode Detector | patient-monitor-photodiode | 1× | 1 | — | part |
| 6.3.3 | Finger Clip Housing | patient-monitor-probe-clip | 1× | 1 | — | part |
| 6.3.4 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 6.4 | SMD Passive (R/C/L) | smd-passives | 50× | 50 | — | part |
| 7 | NIBP Module 7 parts | patient-monitor-nibp-module | 1× | 1 | 66 | assembly |
| 7.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 7.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 7.3 | Blower Motor | blower-motor | 1× | 1 | — | part |
| 7.4 | NIBP Solenoid Valve | patient-monitor-nibp-valve | 1× | 1 | — | part |
| 7.5 | Pressure Sensor | patient-monitor-pressure-sensor | 1× | 1 | — | part |
| 7.6 | Blood Pressure Cuff | patient-monitor-nibp-cuff | 1× | 1 | — | part |
| 7.7 | SMD Passive (R/C/L) | smd-passives | 60× | 60 | — | part |
| 8 | Temperature Module 3 parts | patient-monitor-temp-module | 1× | 1 | 32 | assembly |
| 8.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 8.2 | Thermistor Temperature Probe | patient-monitor-temp-probe | 1× | 1 | — | part |
| 8.3 | SMD Passive (R/C/L) | smd-passives | 30× | 30 | — | part |
| 9 | Respiration Module 3 parts | patient-monitor-resp-module | 1× | 1 | 42 | assembly |
| 9.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 9.2 | Analog Front-End IC | afe-ic | 1× | 1 | — | part |
| 9.3 | SMD Passive (R/C/L) | smd-passives | 40× | 40 | — | part |
| 10 | IBP Module 5 parts | patient-monitor-ibp-module | 1× | 1 | 49 | assembly |
| 10.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 10.2 | Analog Front-End IC | afe-ic | 1× | 1 | — | part |
| 10.3 | Patient Isolation Barrier | patient-monitor-isolation-barrier | 1× | 1 | — | part |
| 10.4 | Disposable Pressure Transducer | patient-monitor-ibp-transducer | 1× | 1 | — | part |
| 10.5 | SMD Passive (R/C/L) | smd-passives | 45× | 45 | — | part |
| 11 | EtCO2 Capnography Module 6 parts | patient-monitor-etco2-module | 1× | 1 | 60 | assembly |
| 11.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 11.2 | Microcontroller | mcu | 1× | 1 | — | part |
| 11.3 | NDIR CO2 Optical Bench | patient-monitor-co2-bench | 1× | 1 | — | part |
| 11.4 | Sample Aspiration Pump | patient-monitor-co2-pump | 1× | 1 | — | part |
| 11.5 | CO2 Sampling Line + Water Trap | patient-monitor-co2-sampling-line | 1× | 1 | — | part |
| 11.6 | SMD Passive (R/C/L) | smd-passives | 55× | 55 | — | part |
| 12 | Alarm Unit 4 parts | patient-monitor-alarm-unit | 1× | 1 | 30 | assembly |
| 12.1 | Speaker | speaker | 1× | 1 | — | part |
| 12.2 | Alarm Indicator LED | patient-monitor-alarm-led | 3× | 3 | — | part |
| 12.3 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 12.4 | SMD Passive (R/C/L) | smd-passives | 25× | 25 | — | part |
| 13 | Connectivity Board 5 parts | patient-monitor-connectivity-board | 1× | 1 | 57 | assembly |
| 13.1 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 13.2 | WiFi/Bluetooth Module | patient-monitor-wifi-module | 1× | 1 | — | part |
| 13.3 | Ethernet PHY + RJ45 Jack | patient-monitor-ethernet-phy | 1× | 1 | — | part |
| 13.4 | SMD Passive (R/C/L) | smd-passives | 50× | 50 | — | part |
| 13.5 | Connector | connector | 4× | 4 | — | part |
| 14 | Strip Recorder 5 parts | patient-monitor-recorder | 1× | 1 | 34 | assembly |
| 14.1 | Thermal Print Head | patient-monitor-thermal-printhead | 1× | 1 | — | part |
| 14.2 | Blower Motor | blower-motor | 1× | 1 | — | part |
| 14.3 | Thermal Paper Roll | patient-monitor-paper-roll | 1× | 1 | — | part |
| 14.4 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 14.5 | SMD Passive (R/C/L) | smd-passives | 30× | 30 | — | part |
| 15 | Power System 4 parts | patient-monitor-power-system | 1× | 1 | 17 | assembly |
| 15.1 | Medical AC-DC Power Supply | patient-monitor-power-supply | 1× | 1 | — | part |
| 15.2 | Backup Battery Pack 3 parts | patient-monitor-battery-pack | 1× | 1 | 9 | assembly |
| 15.2.1 | Li-ion Cell, 18650 | li-cell-18650 | 6× | 6 | — | part |
| 15.2.2 | BMS Board | bms-board | 1× | 1 | — | part |
| 15.2.3 | Connector | connector | 2× | 2 | — | part |
| 15.3 | Wire Bundle | wire-bundle | 1× | 1 | — | part |
| 15.4 | Connector | connector | 6× | 6 | — | part |
| 16 | Control Panel 4 parts | patient-monitor-control-panel | 1× | 1 | 23 | assembly |
| 16.1 | Membrane Keypad | patient-monitor-keypad | 1× | 1 | — | part |
| 16.2 | Rotary Encoder Knob | patient-monitor-encoder-knob | 1× | 1 | — | part |
| 16.3 | Bare PCB | pcb-bare | 1× | 1 | — | part |
| 16.4 | SMD Passive (R/C/L) | smd-passives | 20× | 20 | — | part |
| 17 | Ports Panel 3 parts | patient-monitor-ports-panel | 1× | 1 | 10 | assembly |
| 17.1 | Connector Port Block | patient-monitor-port-block | 1× | 1 | — | part |
| 17.2 | Connector | connector | 8× | 8 | — | part |
| 17.3 | Patient Isolation Barrier | patient-monitor-isolation-barrier | 1× | 1 | — | part |
