A ship-to-shore (STS) gantry crane for loading and unloading containers at a port terminal. A full specification article for this item is being written. Meanwhile its bill of materials and connections are below.

Build & assembly graph

expand / collapse · shared sub-assemblies converge · links to related products · est. labour
product / assembly shared across products atomic part related product

Tap an assembly to expand/collapse · tap a part to open it · use “Open page” for any node · drag to pan, scroll to zoom.

Bill of materials

8 top-level lines · 99 rows shown · 692 parts total · indented to 3 levels
# Item / sub-assembly Part no. Qty/assy Ext. qty Parts Type
1 Steel Structure 7 parts container-crane-structure 1× 1 37 assembly
1.1 Support Leg container-crane-leg 4× 4 — part
1.2 Sill Beam container-crane-sill-beam 2× 2 — part
1.3 Boom 2 parts container-crane-boom 1× 1 5 assembly
1.3.1 Boom Section container-crane-boom-section 1× 1 — part
1.3.2 Boom Hoist Rope container-crane-boom-hoist-rope 4× 4 — part
1.4 Main Girder container-crane-main-girder 1× 1 — part
1.5 A-Frame container-crane-a-frame 1× 1 — part
1.6 Machinery House 2 parts container-crane-machinery-house 1× 1 16 assembly
1.6.1 Cladding Panel container-crane-cladding-panel 12× 12 — part
1.6.2 Fastener Set fastener-set 4× 4 — part
1.7 Fastener Set fastener-set 8× 8 — part
2 Gantry Travel System 3 parts container-crane-gantry-travel 1× 1 378 assembly
2.1 Travel Bogie 3 parts container-crane-bogie 8× 8 14 assembly
2.1.1 Rail Wheel container-crane-rail-wheel 4× 32 — part
2.1.2 Ball Bearing ball-bearing 8× 64 — part
2.1.3 Fastener Set fastener-set 2× 16 — part
2.2 Quay Rail container-crane-travel-rail 2× 2 — part
2.3 Travel Drive Unit 3 parts container-crane-travel-drive 8× 8 33 assembly
2.3.1 AC Drive Motor 4 parts + deeper › container-crane-ac-motor 1× 8 25 assembly
2.3.2 Reduction Gearbox 3 parts + deeper › container-crane-gearbox 1× 8 7 assembly
2.3.3 Encoder encoder 1× 8 — part
3 Trolley 4 parts container-crane-trolley 1× 1 43 assembly
3.1 Trolley Frame container-crane-trolley-frame 1× 1 — part
3.2 Trolley Wheel container-crane-trolley-wheel 4× 4 — part
3.3 Trolley Drive Unit 3 parts container-crane-trolley-drive 1× 1 33 assembly
3.3.1 AC Drive Motor 4 parts + deeper › container-crane-ac-motor 1× 1 25 assembly
3.3.2 Reduction Gearbox 3 parts + deeper › container-crane-gearbox 1× 1 7 assembly
3.3.3 Encoder encoder 1× 1 — part
3.4 Festoon Cable System 2 parts container-crane-festoon-cable 1× 1 5 assembly
3.4.1 Wire Bundle wire-bundle 1× 1 — part
3.4.2 Connector connector 4× 4 — part
4 Hoist System 6 parts container-crane-hoist-system 1× 1 86 assembly
4.1 Hoist Drum 2 parts container-crane-hoist-drum 1× 1 3 assembly
4.1.1 Drum Shell container-crane-drum-shell 1× 1 — part
4.1.2 Ball Bearing ball-bearing 2× 2 — part
4.2 Hoist Wire Rope container-crane-hoist-rope 4× 4 — part
4.3 Sheave Block 2 parts container-crane-sheave-block 4× 4 4 assembly
4.3.1 Rope Sheave container-crane-sheave 2× 8 — part
4.3.2 Ball Bearing ball-bearing 2× 8 — part
4.4 Hoist Motor 5 parts container-crane-hoist-motor 2× 2 26 assembly
4.4.1 Stator Assembly 3 parts + deeper › stator-assembly 1× 2 3 assembly
4.4.2 Rotor Assembly 4 parts + deeper › rotor-assembly 1× 2 19 assembly
4.4.3 Motor Housing motor-housing 1× 2 — part
4.4.4 Ball Bearing ball-bearing 2× 4 — part
4.4.5 Encoder encoder 1× 2 — part
4.5 Reduction Gearbox 3 parts container-crane-gearbox 1× 1 7 assembly
4.5.1 Gearbox Housing gearbox-housing 1× 1 — part
4.5.2 Helical Gear Pair gear-pair 2× 2 — part
4.5.3 Ball Bearing ball-bearing 4× 4 — part
4.6 Hoist Brake 2 parts container-crane-hoist-brake 2× 2 2 assembly
4.6.1 Brake Disc container-crane-brake-disc 1× 2 — part
4.6.2 Brake Caliper container-crane-brake-caliper 1× 2 — part
5 Telescopic Spreader 4 parts container-crane-spreader 1× 1 18 assembly
5.1 Head Block 2 parts container-crane-head-block 1× 1 5 assembly
5.1.1 Rope Sheave container-crane-sheave 4× 4 — part
5.1.2 Connector connector 1× 1 — part
5.2 Telescopic Beam container-crane-telescopic-beam 1× 1 — part
5.3 Twistlock 2 parts container-crane-twistlock 4× 4 2 assembly
5.3.1 Twistlock Cone container-crane-twistlock-cone 1× 4 — part
5.3.2 Limit Switch limit-switch 1× 4 — part
5.4 Corner Flipper container-crane-flipper 4× 4 — part
6 Electrical System 4 parts container-crane-electrical 1× 1 96 assembly
6.1 VFD Drive 4 parts container-crane-vfd-drive 4× 4 10 assembly
6.1.1 IGBT Power Module igbt-module 6× 24 — part
6.1.2 DC-Link Capacitor dc-link-cap 2× 8 — part
6.1.3 Bare PCB pcb-bare 1× 4 — part
6.1.4 Microcontroller mcu 1× 4 — part
6.2 PLC Control Cabinet 5 parts container-crane-plc-cabinet 1× 1 25 assembly
6.2.1 Bare PCB pcb-bare 2× 2 — part
6.2.2 Microcontroller mcu 2× 2 — part
6.2.3 Relay relay 12× 12 — part
6.2.4 Wire Bundle wire-bundle 1× 1 — part
6.2.5 Connector connector 8× 8 — part
6.3 Power Transformer 2 parts container-crane-transformer 1× 1 4 assembly
6.3.1 Transformer Core container-crane-transformer-core 1× 1 — part
6.3.2 Transformer Winding container-crane-transformer-winding 3× 3 — part
6.4 Power Cable Reel 3 parts container-crane-cable-reel 1× 1 27 assembly
6.4.1 AC Drive Motor 4 parts + deeper › container-crane-ac-motor 1× 1 25 assembly
6.4.2 Reel Drum container-crane-reel-drum 1× 1 — part
6.4.3 Wire Bundle wire-bundle 1× 1 — part
7 Operator Cabin 4 parts container-crane-cabin 1× 1 10 assembly
7.1 Cabin Shell container-crane-cabin-shell 1× 1 — part
7.2 Operator Seat container-crane-operator-seat 1× 1 — part
7.3 Control Joystick 3 parts container-crane-joystick 2× 2 3 assembly
7.3.1 Joystick Grip container-crane-joystick-grip 1× 2 — part
7.3.2 Encoder encoder 1× 2 — part
7.3.3 Bare PCB pcb-bare 1× 2 — part
7.4 LCD Panel lcd-panel 2× 2 — part
8 Safety System 4 parts container-crane-safety-system 1× 1 24 assembly
8.1 Anti-Collision Sensor 3 parts container-crane-anticollision-sensor 4× 4 3 assembly
8.1.1 Bare PCB pcb-bare 1× 4 — part
8.1.2 Microcontroller mcu 1× 4 — part
8.1.3 Connector connector 1× 4 — part
8.2 Load Cell container-crane-load-cell 4× 4 — part
8.3 Snag Protection Unit 2 parts container-crane-snag-protection 1× 1 2 assembly
8.3.1 Snag Cylinder container-crane-snag-cylinder 1× 1 — part
8.3.2 Load Cell container-crane-load-cell 1× 1 — part
8.4 Limit Switch limit-switch 6× 6 — part
